The quality name in water heating
Installation and User Instructions
Wall Mounted Vented Water
Please read and understand these instructions before starting
Please leave this leaflet with the user following installation
TRAE SADIA
TRAE SADIA
TRAE SADIA
TRAE SADIA
for the
B3/C3 M Range
Heaters
work.
36 00 5722 Issue 1
1
Advertisement
Table of Contents
Related Manuals for Heatrae Sadia B3 M
Summary of Contents for Heatrae Sadia B3 M
- Page 1 TRAE SADIA TRAE SADIA HEA TRAE SADIA TRAE SADIA TRAE SADIA The quality name in water heating Installation and User Instructions for the B3/C3 M Range Wall Mounted Vented Water Heaters Please read and understand these instructions before starting work. Please leave this leaflet with the user following installation 36 00 5722 Issue 1...
-
