  • Page 1 Classic PC1565 Unit C51 Winfrith Technology Centre Control Panels Winfrith Newburgh Dorchester DT2 8DH Telephone 01305 851700 01305 851660 Email: Sales@dscuk.co.uk Web-Site: www.dscuk.co.uk Unit 21 Hull Business Centre Guildhall Road Hull HU1 1HJ Technical Support Telephone 01482 322228/329911...
  • Page 2: Table Of Contents

    Installation Manual. Power Up ..........11 Initial Start Up ......11 Common Start-Up Problems ..17 Default Settings ........15 Classic PC1565 Expansion Flowchart ... 16 [*] Commands ........18 Clearing Troubles ......... 21 Basic Programming ......24 Programming Using an LED Keypad ......
  • Page 3: Features

    Using the Big Books Features are the options that you need to Features programme in order to have the features work appropriately. Now look at page 27. This is the • 6 on-board zones beginning of the Programming • Expandable to 8 zones via wireless Worksheets.
  • Page 4: Installation

    3. Fit the remote keypad, detectors and internal & external sounders in the areas described on the specification. 4. Connect the mains cable to the unswitched fuse spur and to the control panel. DO NOT POWER UP YET. Features Installing the Classic PC1565 Control Panel...
  • Page 5 Section 1 is the basic overview of the and communications if pro- panel specifications including AUX, grammed. Bell and PGM output current ratings, battery and transformer requirements and a quick description of some of the more common features. Section 1 Features Installing the Classic PC1565 Control Panel...
  • Page 6: Wiring

    (02) Delay 2 = Final Exit 2 tant part of the installation process of (03) Instant = Normal Zone the Classic PC1565 and its associated (05) Interior Stay/Away = (Part Set) Zone will be omitted if no Final exit modules. The Keybus is a simple 4- zone is activated.
  • Page 7: Wiring 24-Hr Devices

    Using a LCD Keypad The diagram below shows how to connect door contacts, break glass detectors and panic attack buttons to the Classic PC1565 using double end of line resistors (DEOL). Always follow the manufacturer’s instructions when installing such devices.
  • Page 8: Wiring Pirs

    Wiring Basic Programming Be sure to record your new Master Wiring PIRs Code on the “System Information” Although zones can be wired as page in this booklet. NOTE: We double end of line (DEOL), single end recommend that the factory default of line (SEOL) or normally closed, we or obvious codes such as [1111] or recommend DEOL for all intrusion...
  • Page 9: Wiring Fire Detectors

    Press [2] and the dash is detectors should be connected to the replaced by the number, indicating Classic PC1565 control panel. the option is now “ON”. Press [2] again and the number is replaced with Always check the manufacturer’s a dash, indicating the option is now instructions for the detector.
  • Page 10: Wiring Sab

    If you want to exit strobe connection. engineering mode, simply press [#] The bell circuit on the Classic PC1565 once more and the keypad will revert is always supervised with a 1K resistor. to normal mode.
  • Page 11 Now let’s look at how to change some of the default settings listed on the previous page. If you are using the Classic PC1565 as a “bells only” system, this could be the only pro- gramming you need to do.
  • Page 12: Telephones

    If [1] comes ON, push [1] again for specific trouble present. LED lit Telephone Connections after pushing [1] again will indicate The Classic PC1565 is a powerful type of trouble. communications device and it is Low Battery important that you make the correct Check Battery.
  • Page 13: Power Up

    Clearing Troubles Features Failure to Communicate Power Up Panel unable to send information to central station. Check telephone line, telephone number of Central Initial Start Up Station, format and reporting Before turning on the mains power, codes. Dial number from handset and listen for tones to ensure make sure that all electrical connec- tions are completed and all devices...
  • Page 14 LCD keypad. Scroll You may be using a wireless module through the display using the [<][>] with the Classic PC1565. Always keys to see if more than one trouble repower the control panel after adding condition is present.
  • Page 15 [*] Commands Power Up [*][8] Access to Engineering Functions Press [*][8][Engineer Code] to enter engineering functions (Installation Manual, page 12). [*][9] Arming without Entry Delay Press [*][9][Access Code] the panel will remove the entry delay from the partition. [*][0] Quick Arm/Quick Exit Press [*][0] to quick arm the system.
  • Page 16: Common Start-Up Problems

    Power Up [*] Commands [*][5] Programming Access Codes Common Start-Up Problems Press [*][5][Master Code]. The keypad Loss of Clock – Panel needs to have will flash the program light and turn time and date set. To do this press on the zone light for any codes [*][6][Master Code][1], then enter already programmed.
  • Page 17: Default Settings

    Features Features [*] Commands Default Settings The Classic PC1565 allows for the 001 Zone Definitions access of information and outputs by Zone 1 Entry/Exit using [*] commands. These com- Zone 2 Interior Delay mands are very similar on all DSC products.
  • Page 18: Classic Pc1565 Expansion Flowchart

    Features Features Classic PC1565 Expansion Flowchart Features Classic PC1565 Expansion Flowchart...
