- Page 2 About Your Security System Your DSC security equipment has been designed to give you the greatest possible flexibility and convenience. The LCD5500 Security Station will guide you through each operation with English language prompts.
- Page 3 Your security system is made up of a DSC control panel, one or more LCD5500 security stations and various detectors and sensors. The DSC control panel will be mounted out of the way in a utility room or basement. The metal cabinet contains the system electronics, fuses and stand-by battery. There is normally no reason for anyone but the installer or service person to have access to the control panel.
- Page 4 System Information This system includes: Control Panel model LCD5500 Security Station(s) model Remote keypad(s) model Master Security Code: 40 There are codes available on this system. Additional Security Codes There are active zones on this system. Protected Area Zone Type Zone...
- Page 5 Zone Protected Area Zone Type FIRE Keypad Fire Zone Keypad Auxiliary Zone Keypad Panic Zone Monitoring Station Information Account # Telephone # Installer Information Company Telephone #...
- Page 6 Arming If this display is showing, check to see that all zones are secure by closing all doors/windows and stopping motion in areas covered by motion detectors. If a zone will not clear, it may be bypassed to allow partial arming. NOTE:: A bypassed zone reduces your protect/on.
- Page 7 Disarming Enter the premises only through the door(s) designated by your installer as the entry door(s). Entering by any other door will sound an immediate alarm. Upon entering through the designated entry door, the keypad display will begin to sound an audible warning and display the following message..
- Page 9 LCD5500 Controls and Display Liquid Crystal Display (LCD) ’ 1 Keypad displays prompts and system Press keys as prompted by the information on two 16 LCD display to view alarms or troubles, to Arm/Disarm the character lines. If "< >" appears, it indicates system or to shunt zones.
- Page 15 Fire Safety in the Home Most fires occur in the home and to minimize this danger it is recommended that a household fire safety audit be conducted and a family escape plan be developed. Household Fire Safety Audit 1. Are all electrical appliances and outlets in a safe condition e.g. frayed cords, over-loaded lighting circuits? If you are uncertain about the condition of your electrical appliances or household service, have a professional evaluation.
- Page 16 Make sure your fire warning system is operational by conducting weekly tests as noted elsewhere in this manual. If you are unsure about system operation, contact your installing dealer. It is recommended that you contact your local fire department and request further information on home fire safety and escape planning.
