AFL-W19A/W19B/17D/W15A-N270 Panel PC
IEI Technology Corp.
MODEL:
AFL-W19A/W19B/17D/W15A-N270
Panel PC with Touch Screen Intel® CPU
Gigabit Ethernet, USB, Audio, RS-232/422/485, SATA
RoHS Compliant, IP 64 Protection

User Manual

Page i
Rev. 1.04 – 19 November 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFL-W19A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology AFL-W19A

Summary of Contents for IEI Technology AFL-W19A

  • Page 1: User Manual

    AFL-W19A/W19B/17D/W15A-N270 Panel PC IEI Technology Corp. MODEL: AFL-W19A/W19B/17D/W15A-N270 Panel PC with Touch Screen Intel® CPU Gigabit Ethernet, USB, Audio, RS-232/422/485, SATA RoHS Compliant, IP 64 Protection User Manual Page i Rev. 1.04 – 19 November 2009...
  • Page 2 AFL-W19A/W19B/17D/W15A-N270 Panel PC Revision Date Version Changes 19 November 2009 1.04 Updated I/O diagrams 3 November 2009 1.03 Changed jumper settings section 26 May 2009 1.02 Minor updates 8 April 2009 1.01 Added 15" 18 March 2009 1.00 Initial release...
  • Page 3 AFL-W19A/W19B/17D/W15A-N270 Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    1.6 S ......................5 PECIFICATIONS 1.7 D ....................... 7 IMENSIONS 1.7.1 AFL-W15A-N270 Dimensions................7 1.7.2 AFL-17D-N270 Dimensions ................8 1.7.3 AFL-W19A-N270 Dimensions................9 1.7.4 AFL-W19B-N270 Dimensions................10 2 INSTALLATION ......................11 2.1 U PC.................... 12 NPACK THE ANEL 2.2 P ......................13 ACKING 2.3 H...
  • Page 5 YSTEM 2.6.1 Monitor Stand ....................27 2.6.2 Cabinet and Rack..................... 28 2.6.3 Arm Mounting ....................30 2.6.4 Wall Mounting....................32 2.6.5 Panel Mounting (AFL-17D-N270 / AFL-W19A-N270 / AFL-W19B-N270) ..35 2.6.6 Panel Mounting (AFL-W15A-N270)..............37 2.7 B ................. 39 OTTOM...
  • Page 6 AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.4 PCI/P P........................74 3.5 B ........................77 3.5.1 Boot Settings Configuration................77 3.5.2 Boot Device Priority ..................80 3.5.3 Hard Disk Drives ..................... 81 3.5.4 Removable Drives .................... 81 3.5.5 CD/DVD Drives ....................82 3.6 S .........................
  • Page 7 Figure 1-3: Rear Panel........................4 Figure 1-4: Bottom Panel .......................5 Figure 1–5: AFL-W15A-N270 Dimensions ..................7 Figure 1–6: AFL-17D-N270 Dimensions ..................8 Figure 1–7: AFL-W19A-N270 Dimensions ..................9 Figure 1–8: AFL-W19B-N270 Dimensions ..................10 Figure 2-1: Aluminum Back Cover Retention Screws ..............15 Figure 2-2: HDD Bracket Retention Screws................15 Figure 2-3: HDD Retention Screws .....................16...
  • Page 8 AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-23: AFL-17D-N270 Cutout .....................36 Figure 2-24: AFL-W19A-N270 and AFL-W19B-N270 Cutout .............36 Figure 2-25: Tighten the Panel Mounting Clamp Screws ............37 Figure 2-26: AFL-W15A-N270 Cutout..................38 Figure 2-27: Tighten the Panel Mounting Clamp Screws ............39 Figure 2-28: Connectors ......................39 Figure 2-29: LAN Connection ......................40...
  • Page 9 AFL-W19A/W19B/17D/W15A-N270 Panel PC List of Tables Table 1-1: System Specifications....................6 Table 2-1: Packing List.........................14 Table 2-2: Jumpers ........................19 Table 2-3: Preconfigured Jumpers .....................19 Table 2-4: CF Card Setup Jumper Settings ................20 Table 2-5: Clear CMOS Jumper Settings..................21 Table 2-6: COM1 Pin 9 Setting Jumper Settings ...............22 Table 2-7: COM3 Pin 9 Setting Jumper Settings ...............22...
  • Page 10 AFL-W19A/W19B/17D/W15A-N270 Panel PC BIOS Menus BIOS Menu 1: Main ........................48 BIOS Menu 2: Advanced ......................49 BIOS Menu 3: CPU Configuration ....................50 BIOS Menu 4: IDE Configuration....................51 BIOS Menu 5: IDE Master and IDE Slave Configuration ............52 BIOS Menu 6: Super IO Configuration..................57 BIOS Menu 7: Hardware Health Configuration ................60...

  • Page 11: Introduction

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Chapter Introduction Page 1...

  • Page 12: Overview

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 1.1 Overview Figure 1-1: AFL-W19A/W19B/17D/W15A-N270 The Afolux panel PCs are all-in-one panel PCs with all the elements of a desktop computer contained in a single, slim package, no bigger than a thick monitor. The Afolux panel PCs can be mounted on a desktop monitor stand and save a huge amount of desktop space by including all the computer components behind the screen.

  • Page 13: Features

    The rear panel contains a smaller access panel, all the cable connections and the mounting holes. 1.4.1 Front Panel The front side of the AFL-W19A/W19B/17D/W15A-N270 is a flat panel LCD screen surrounded by a plastic frame. Page 3...

  • Page 14: Rear Panel

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 1-2: Front Panel 1.4.2 Rear Panel The rear panel provides access to retention screw holes that support the wall mounting. Refer to Figure 1-3. Figure 1-3: Rear Panel Page 4...

  • Page 15: Bottom Panel

    Optionally, an HSDPA module can be installed in any of the models. The AFL-W19B-N270 also supports an optical disk drive. 1.6 Specifications The technical specifications for the AFL-W19A/W19B/17D/W15A-N270 systems are listed in Table 1-1. SPECIFICATION...

  • Page 16: Table 1-1: System Specifications

    AFL-W19A/W19B/17D/W15A-N270 Panel PC SPECIFICATION AFL-W15A-N270 AFL-17D-N270 AFL-W19A-N270 AFL-W19B-N270 1.6GHz Intel® Atom LCD Panel 15.6" 17" 19" 19" Resolution 1366 x 768 1280 x 1024 1440 x 900 1440 x 900 Brightness Contrast Ratio 500:1 800:1 850:1 850:1 LCD Colors 16.2 million 16.7 million...

  • Page 17: Dimensions

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 1.7 Dimensions 1.7.1 AFL-W15A-N270 Dimensions Figure 1–5: AFL-W15A-N270 Dimensions Page 7...

  • Page 18: Afl-17D-N270 Dimensions

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 1.7.2 AFL-17D-N270 Dimensions Figure 1–6: AFL-17D-N270 Dimensions Page 8...

  • Page 19: Afl-W19A-N270 Dimensions

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 1.7.3 AFL-W19A-N270 Dimensions Figure 1–7: AFL-W19A-N270 Dimensions Page 9...

  • Page 20: Afl-W19B-N270 Dimensions

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 1.7.4 AFL-W19B-N270 Dimensions Figure 1–8: AFL-W19B-N270 Dimensions Page 10...

  • Page 21: Installation

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Chapter Installation Page 11...

  • Page 22: Unpack The Panel Pc

    AFL-W19A/W19B/17D/W15A-N270 Panel PC WARNING: When installing the AFL-W19A/W19B/17D/W15A-N270, make sure to: Turn the power off: Chance of electrocution. Turn off the monitor  and unplug it from the power supply.  Only let certified engineers change the hardware settings: Incorrect settings can cause irreparable damage to the product.

  • Page 23: Packing List

    Lift the monitor out of the boxes. Step 5: Remove the peripheral parts box from the main box. Step 6: S t e p 0 : 2.2 Packing List The AFL-W19A/W19B/17D/W15A-N270 flat panel PC is shipped with the following components: Quantity Item Image AFL-W19A/W19B/17D/W15A-N270...

  • Page 24: Hard Drive Installation

    This section outlines installation hard drive AFL-W19A/W19B/17D/W15A-N270. To install the hard drive, please follow the steps below: Remove the plastic back cover. Step 1: Unfasten the four silver retention screws. The screws will not separate from the Step 2: cover, just loosen as much as possible (Figure 2-1).

  • Page 25: Figure 2-1: Aluminum Back Cover Retention Screws

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-1: Aluminum Back Cover Retention Screws Slide the cover down, then lift to remove. Step 3: Remove the four HDD bracket retention screws (Figure 2-2) and lift the HDD Step 4: brackets out of the panel PC.

  • Page 26: Figure 2-3: Hdd Retention Screws

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Attach the HDD brackets to the HDD. The brackets are different for each side. Step 5: Make sure the side with the hard drive screw hole further from the end goes at the SATA connector end as shown in Figure 2-3.

  • Page 27: Compactflash® Installation

    0 : 2.4 CompactFlash® Installation The installation for the AFL-17D-N270 is shown in this section. The CompactFlash® card installation for the AFL-W19A-N270 and AFL-W19B-N270 is shown in the hard drive installation section above. Undo the CompactFlash® slot screw.

  • Page 28: Jumper Settings

    The following jumpers can be found on the motherboard installed in the AFL-W19A/W19B/17D/W15A-N270. Before the AFL-W19A/W19B/17D/W15A-N270 is installed, the jumpers must be set in accordance with the desired configuration. The jumpers on the AFL-W19A/W19B/17D/W15A-N270 motherboard are listed in Table 2-2. Page 18...

  • Page 29: Access The Jumpers

    2.5.2 Preconfigured Jumpers WARNING: Do not change the settings on the jumpers in described here. Doing so may disable or damage the system. The following jumpers are preconfigured for the AFL-W19A/W19B/17D/W15A-N270. Users should no change these jumpers (Table 2-3). Jumper Name Label...

  • Page 30: Cf Card Setup

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 2.5.3 CF Card Setup Jumper Label: JCF1 2-pin header Jumper Type: See Table 2-4 Jumper Settings: See Figure 2-7 Jumper Location: The CF Card Setup jumper sets the CF Type I card or CF Type II cards as either the slave device or the master device.

  • Page 31: Figure 2-8: Clear Cmos Jumper

    See Figure 2-8 Jumper Location: If the AFL-W19A/W19B/17D/W15A-N270 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close the pins for a few seconds then remove the jumper clip.

  • Page 32: Com Port Pin 9 Select

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 2.5.5 COM Port Pin 9 Select Jumper Label: JP6 and JP7 See Table 2-6 Jumper Settings: 6-pin header Jumper Type: See Figure 2-9 Jumper Location: Two jumpers (JP6 and JP7) configure pin 9 on COM1 and COM3 DB-9 connectors. Pin 9 on the COM1 and the COM3 DB-9 connectors can be set as the ring (RI) signal, +5 V or +12 V.

  • Page 33: Com3 Rx Function Select Jumper

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-9: COM1 and COM3 Pin 9 Setting Jumper Locations 2.5.6 COM3 RX Function Select Jumper Jumper Label: 8-pin header Jumper Type: See Table 2-8 Jumper Settings: See Figure 2-10 Jumper Location: The COM3 RX Function Select jumper sets the communication protocol used by the RX serial communications port COM3 as RS-232, RS-422 or RS-485.

  • Page 34: Com3 Tx Function Select Jumper

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-10: COM3 RX Function Select Jumper Location 2.5.7 COM3 TX Function Select Jumper Jumper Label: JP11 6-pin header Jumper Type: See Table 2-9 Jumper Settings: See Figure 2-11 Jumper Location: The COM3 TX Function Select jumper configures the TX pin on COM3 serial port connector as RS-422 as an RS-485.

  • Page 35: Com3 Rs-232/422/485 Serial Port Select Jumper

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-11: COM3 TX Function Select Jumper Pinout Locations 2.5.8 COM3 RS-232/422/485 Serial Port Select Jumper Jumper Label: JP10 12-pin header (four 3-pin headers combined) Jumper Type: See Table 2-10 Jumper Settings: See Figure 2-12 Jumper Location: The COM3 RS-232/422/485 Serial Port Select jumper sets the communication protocol used by the second serial communications port (COM3) as RS-232, RS-422 or RS-485.

  • Page 36: Com3 Rs-422 And Rs-485 Pinouts

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Short 5-6 RS-422/485 Short 8-9 RS-422/485 Short 11-12 RS-422/485 Table 2-10: COM3 RS-232/422/485 Serial Port Select Jumper Settings The COM3 RS-232/422/485 Serial Port Select jumper location is shown in Figure 2-12. Figure 2-12: COM3 RS-232/422/485 Serial Port Select Jumper Location 2.5.8.1 COM3 RS-422 and RS-485 Pinouts...

  • Page 37: Mounting The System

    2.6.2 Cabinet and Rack ................28 2.6.3 Arm Mounting ..................30 2.6.4 Wall Mounting ..................32 2.6.5 Panel Mounting (AFL-17D-N270 / AFL-W19A-N270 / AFL-W19B-N270) ....................... 35 2.6.6 Panel Mounting (AFL-W15A-N270)............. 37 The installation instructions are included with the stand, arm or mount.

  • Page 38: Cabinet And Rack

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-13: Monitor Stand 2.6.2 Cabinet and Rack The AFL-W19A/W19B/17D/W15A-N270 flat panel PC can be installed into a cabinet or rack. The installation procedures are similar to the panel mounting installation. To do this, please follow the steps below:...

  • Page 39: Figure 2-14: The Rack/Cabinet Bracket

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-14: The Rack/Cabinet Bracket Insert the rack mounting clamps into the pre-formed holes along the edges of Step 2: the flat panel PC, behind the ABS/PC plastic frame. Tighten the screws that pass through the rack mounting clamps until the plastic...

  • Page 40: Arm Mounting

    (Figure 2-16).Step 0: 2.6.3 Arm Mounting The AFL-W19A/W19B/17D/W15A-N270 can be installed on any arm that supports the standard VESA mounting interface. An example wall arm is shown below. Figure 2-17: Wall Arm Page 30...

  • Page 41: Figure 2-18: Arm Mounting Retention Screw Holes

    AFL-W19A/W19B/17D/W15A-N270 Panel PC To install the AFL-W19A/W19B/17D/W15A-N270 on the arm, follow the directions below. NOTE: Make sure the arm supports standard VESA mounting. The AFL-W19A/W19B/17D/W15A-N270 uses a VESA mounting to attach to the arm. The arm is purchased separately. Follow the instructions in the arm's user Step 1: manual to securely attach the arm to the wall.

  • Page 42: Wall Mounting

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 2.6.4 Wall Mounting To mount the flat panel PC onto the wall, please follow the steps below. Figure 2-19: Wall Mount Select the location on the wall for the wall-mounting bracket. Step 1: Carefully mark the locations of the four brackets screw holes on the wall.

  • Page 43: Figure 2-20: Wall-Mounting Bracket

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-20: Wall-mounting Bracket Insert the four monitor mounting screws provided in the wall mounting kit into the Step 6: four screw holes on the real panel of the flat panel PC and tighten until the screw shank is secured against the rear panel (Figure 2-21).

  • Page 44: Figure 2-21: Chassis Support Screws

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-21: Chassis Support Screws NOTE: In the diagram below the bracket is already installed on the wall. Secure the panel PC by fastening the retention screw of the wall-mounting Step 9: bracket. (Figure 2-22). Step 0:...

  • Page 45: Panel Mounting (Afl-17D-N270 / Afl-W19A-N270 / Afl-W19B-N270)

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-22: Secure the Panel PC 2.6.5 Panel Mounting (AFL-17D-N270 / AFL-W19A-N270 / AFL-W19B-N270) To mount the panel PC into a panel, please follow the steps below. Select the position on the panel to mount the flat panel PC.

  • Page 46: Figure 2-23: Afl-17D-N270 Cutout

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-23: AFL-17D-N270 Cutout Figure 2-24: AFL-W19A-N270 and AFL-W19B-N270 Cutout Slide the flat panel PC through the hole until the aluminum frame is flush against Step 3: the panel. Page 36...

  • Page 47: Panel Mounting (Afl-W15A-N270)

    Step 0: Figure 2-25: Tighten the Panel Mounting Clamp Screws 2.6.6 Panel Mounting (AFL-W15A-N270) To mount the AFL-W19A/W19B/17D/W15A-N270 flat panel PC into a panel, please follow the steps below. Select the position on the panel to mount the flat panel PC.

  • Page 48: Figure 2-26: Afl-W15A-N270 Cutout

    AFL-W19A/W19B/17D/W15A-N270 Panel PC large enough for the rear panel of the flat panel PC to fit through. Recommended cutout size shown below. Figure 2-26: AFL-W15A-N270 Cutout Slide the flat panel PC through the hole until the aluminum frame is flush against Step 3: the panel.

  • Page 49: Bottom Panel Connectors

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-27: Tighten the Panel Mounting Clamp Screws 2.7 Bottom Panel Connectors The bottom panel connectors extend the capabilities of the panel PC but are not essential for operation (except power). Figure 2-28: Connectors 2.7.1 LAN Connection The RJ-45 connectors enable connection to an external network.

  • Page 50: Serial Device Connection

    AFL-W19A/W19B/17D/W15A-N270. Follow the steps below to connect a serial device to the AFL-W19A/W19B/17D/W15A-N270 panel PC. Locate the DB-9 connector. The location of the DB-9 connector is shown in Step 1: Chapter 2. Insert the serial connector. Insert the DB-9 connector of a serial device into Step 2: the DB-9 connector on the bottom panel.

  • Page 51: Usb Device Connection

    Step 0: 2.7.3 USB Device Connection To connect USB devices to the AFL-W19A/W19B/17D/W15A-N270, please follow the instructions below. Located the USB connectors. The locations of the USB connectors are shown Step 1: in Chapter 2.

  • Page 52: Vga Monitor Connection

    2.7.4 VGA Monitor Connection The VGA output can be connected to an external VGA monitor. To connect the VGA monitor to the AFL-W19A/W19B/17D/W15A-N270, please follow the instructions below. Locate the female DB-15 connector. The location of the female DB-15 Step 1: connector is shown in Chapter 3.

  • Page 53: Power Connection

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 2-32: VGA Connector Secure the connector. Secure the DB-15 VGA connector from the VGA Step 4: monitor to the external interface by tightening the two retention screws on either side of the connector. Step 0: 2.8 Power Connection The power cable connects the panel PC to the power supply.
  • Page 54 AFL-W19A/W19B/17D/W15A-N270 Panel PC  Chipset driver  Graphics driver LAN driver  Audio driver   Touch panel driver  Keypad utility driver  Wireless LAN card driver  Bluetooth driver Page 44...

  • Page 55: Bios Setup

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Chapter BIOS Setup Page 45...

  • Page 56: Introduction

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 3.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 57: Getting Help

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Function F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 3-1: BIOS Navigation Keys 3.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.

  • Page 58: Main

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 59: Advanced

    AFL-W19A/W19B/17D/W15A-N270 Panel PC The System Overview field also has two user configurable fields:  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.

  • Page 60: Cpu Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications and configure the CPU. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Configure Advanced CPU Settings Module Version:3F.12 ...

  • Page 61: Ide Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit IDE Configuration Options ...

  • Page 62: Ide Master, Ide Slave

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Only the IDE drives are enabled. SATA drives are PATA Only disabled  Configure SATA as [IDE] Use the Configure SATA as option to configure SATA devices as normal IDE devices.  Configures SATA devices as normal IDE device.

  • Page 63: Type [Auto]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Type: Indicates the type of devices a user can manually select  Vendor: Lists the device manufacturer Size: List the storage capacity of the device.  LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method ...

  • Page 64: Lba/Large Mode [Auto]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  This option specifies an ATAPI Removable Media ARMD Device. These include, but are not limited to: LS-120  LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing).

  • Page 65: Dma Mode [Auto]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  BIOS auto detects the PIO mode. Use this value if the IDE disk Auto EFAULT drive support cannot be determined.  PIO mode 0 selected with a maximum transfer rate of 3.3 MB/s  PIO mode 1 selected with a maximum transfer rate of 5.2 MB/s ...

  • Page 66: Auto]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Ultra DMA mode 1 selected with a maximum data transfer UDMA1 rate of 25 MB/s  Ultra DMA mode 2 selected with a maximum data transfer UDMA2 rate of 33.3 MB/s  Ultra DMA mode 3 selected with a maximum data transfer...

  • Page 67: Super Io Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.3 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 6) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 68: Serial Port3 Address [3E8]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Serial Port3 Address [3E8] Selects the serial port base address.  No base address Disabled  I/O address 3E8 EFAULT  I/O address 2E8  I/O address 2F0  I/O address 2E0  Serial Port3 IRQ [11] Selects the serial port interrupt address.

  • Page 69: Serial Port5 Address [2F0]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  IRQ address 11 EFAULT  Serial Port5 Address [2F0] Selects the serial port base address.  No base address Disabled  I/O address 2F0 EFAULT  Serial Port5 IRQ [10] Use the Serial Port5 IRQ option to select the interrupt address for serial port 5.

  • Page 70: Hardware Health Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.4 Hardware Health Configuration The Hardware Health Configuration menu (BIOS Menu 7) shows the operating temperature, fan speeds and system voltages. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Hardware Health Event Monitoring ...

  • Page 71: Temp. Limit Of Off [000]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  The fan adjusts its speed using these settings: Automatic mode Temp. Limit of OFF Temp. Limit of Start Fan Start PWM Slope PWM 1  The fan spins at the speed set in: PWM Manual mode Fan PWM control ...

  • Page 72: Slope Pwm [1 Pwm]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  PWM Maximum Mode: 127  Slope PWM [1 PWM] A bigger value will increase the fan speed in big amounts. A smaller value will increase the speed more gradually.  0 PWM 1 PWM  ...

  • Page 73: Power Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC +3.30V +5.00V +12.0V +1.5V +1.8V 3.3.5 Power Configuration The Power Configuration menu (BIOS Menu 8) allows the advanced power management options to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit > ACPI Configuration >...

  • Page 74: Acpi Settings

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.5.1 ACPI Settings Use the ACPI Settings menu (BIOS Menu 9) to select the ACPI state when the system is suspended. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit ACPI Settings  Suspend Mode [S1 (POS)] ...

  • Page 75: Apm Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.5.2 APM Configuration The APM Configuration menu (BIOS Menu 10) allows the advanced power management options to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit APM Configuration If the AT/ATX jumper ...

  • Page 76: Resume On Keyboard/Mouse [Disabled]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  When the power button is pressed the system goes into Suspend suspend mode  Resume on Keyboard/Mouse [Disabled] Use the Resume on Keyboard/Mouse BIOS option to enable activity on either the keyboard or mouse to rouse the system from a suspend or standby state. That is, the system is roused when the mouse is moved or a button on the keyboard is pressed.

  • Page 77: Remote Access Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  The real time clock (RTC) cannot generate a wake Disabled EFAULT event  If selected, the following appears with values that Enabled can be selected: RTC Alarm Date (Days) System Time After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off.

  • Page 78: Serial Port Number [Com1]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Remote access is disabled. Disabled EFAULT  Remote access configuration options shown below Enabled appear: Serial Port Number Serial Port Mode Flow Control Redirection after BIOS POST Terminal Type VT-UTF8 Combo Key Support These configuration options are discussed below.

  • Page 79: Flow Control [None]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  19200 8,n,1  09600 8,n,1 NOTE: Identical baud rate setting musts be set on the host (a management computer running a terminal software) and the slave  Flow Control [None] Use the Flow Control option to report the flow control method for the console redirection application.

  • Page 80: Vt-Utf8 Combo Key Support [Disabled]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  The target terminal type is VT-UTF8 VT-UTF8  VT-UTF8 Combo Key Support [Disabled] Use the VT-UFT8 Combo Key Support option to enable additional keys that are not provided by VT100 for the PC 101 keyboard. The VT100 Terminal Definition is the standard convention used to configure and conduct emergency management tasks with UNIX-based servers.

  • Page 81: Usb Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.7 USB Configuration Use the USB Configuration menu (BIOS Menu 12) to read USB configuration information and configure the USB settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit USB Configuration Options  Disabled Module Version –...

  • Page 82: Usb 2.0 Controller [Enabled]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  USB 2.0 Controller [Enabled] Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller  USB 2.0 controller disabled Disabled  USB 2.0 controller enabled Enabled EFAULT  Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support.

  • Page 83: Usb Mass Storage Device Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.3.7.1 USB Mass Storage Device Configuration Use the USB Mass Storage Device Configuration menu (BIOS Menu 13) to configure USB mass storage class devices. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit USB Mass Storage Device Configuration ...

  • Page 84: Pci/Pnp

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Emulation Type [Auto] Use the Emulation Type BIOS option to specify the type of emulation BIOS has to provide for the USB device.  BIOS auto-detects the current USB. Auto EFAULT  The USB device will be emulated as a floppy drive.

  • Page 85: Bios Menu 14: Pci/Pnp Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Advanced PCI/PnP Settings Available: Specified IRQ  is available to be use the PCI/PnP devices IRQ3 [Reserved] Reserved: Specified IRQ IRQ4 [Reserved] is reserved for use by...

  • Page 86: Dma Channel# [Available]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  IRQ 11  IRQ 14 IRQ 15   DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device.  The specified DMA is available to be used by...

  • Page 87: Boot

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.5 Boot Use the Boot menu (BIOS Menu 15) to configure system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Boot Settings Configure settings  during system boot. > Boot Settings Configuration >...

  • Page 88: Quick Boot [Enabled]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process.  No POST procedures are skipped Disabled  Some POST procedures are skipped to decrease Enabled EFAULT the system boot time ...

  • Page 89: Boot From Lan Support [Disabled]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Allows the Number Lock on the keyboard to be enabled EFAULT automatically when the computer system boots up. This allows the immediate use of the 10-key numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard is lit.

  • Page 90: Boot Device Priority

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 17) to specify the boot sequence from the available devices. The drive sequence also depends on the boot sequence in the individual device section. BIOS SETUP UTILITY...

  • Page 91: Hard Disk Drives

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.5.3 Hard Disk Drives Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs. Only installed hard drives are shown. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Hard Disk Drives Specifies the boot ...

  • Page 92: Cd/Dvd Drives

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.5.5 CD/DVD Drives Use the CD/DVD Drives menu to specify the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system are listed as shown below: ...

  • Page 93: Security

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.6 Security Use the Security menu (BIOS Menu 21) to set system and user passwords. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Security Settings  Supervisor Password :Not Installed User Password :Not Installed...

  • Page 94: Chipset

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.7 Chipset Use the Chipset menu (BIOS Menu 22) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 95: Northbridge Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 3.7.1 Northbridge Configuration Use the Northbridge Chipset Configuration menu (BIOS Menu 23) to configure the Northbridge chipset. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Northbridge Configuration  Memory Hole [Disabled] Internal Graphics Mode Select...

  • Page 96: Dvmt Mode Select [Dvmt Mode]

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Dedicates 1 MB of main memory for graphics Enable, 1 MB  Dedicated 8 MB of main memory for graphics Enable, 8 MB EFAULT  DVMT Mode Select [DVMT Mode] Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology (DVMT) operating mode.

  • Page 97: Southbridge Configuration

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  LVDS  Panel Type Use the Panel Type to determine the LCD panel resolution. Configuration options are listed below:  1024x768 24b 1280x1024 48b   1366x768 24b  1440x900 48b BY HARDWARE  EFAULT ...

  • Page 98: Exit

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Audio Controller [Auto] Use the HDA Controller option to enable or disable High Definition audio codec.  Auto EFAULT  Enabled High Definition audio Azalia  Enable AC'97 audio AC'97 Audio Only  No audio All disabled 3.8 Exit...

  • Page 99: Discard Changes

    AFL-W19A/W19B/17D/W15A-N270 Panel PC  Discard Changes Use the Discard Changes option to discard the changes and remain in the BIOS configuration setup program.  Load Optimal Defaults Use the Load Optimal Defaults option to load the optimal default values for each of the parameters on the Setup menus.

  • Page 100: System Maintenance

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Chapter System Maintenance Page 90...

  • Page 101: System Maintenance Introduction

    AFL-W19A/W19B/17D/W15A-N270 Panel PC 4.1 System Maintenance Introduction If the components of the AFL-W19A/W19B/17D/W15A-N270 fail they must be replaced, such as the wireless LAN module or the motherboard. Please contact the system reseller or vendor to purchase the replacement parts. Back cover removal instructions and jumper settings for the AFL-W19A/W19B/17D/W15A-N270 are described below.

  • Page 102: Memory Module Replacement

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 4-1: Back Cover Retention Screws 4.4 Memory Module Replacement The flat panel PC has a preinstalled memory module. If the memory module fails, take the steps below to replace it. Remove the back cover. See Section 4.3 above.

  • Page 103: Figure 4-2: Ddr So-Dimm Module Installation

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Figure 4-2: DDR SO-DIMM Module Installation Page 93...

  • Page 104: A Safety Precautions

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Appendix Safety Precautions Page 94...

  • Page 105: Safety Precautions

    Follow the electrostatic precautions outlined below whenever the AFL-W19A/W19B/17D/W15A-N270 is opened.  Make sure the power is turned off and the power cord is disconnected whenever the AFL-W19A/W19B/17D/W15A-N270 is being installed, moved or modified.  Do not apply voltage levels that exceed the specified voltage range.

  • Page 106: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFL-W19A/W19B/17D/W15A-N270. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFL-W19A/W19B/17D/W15A-N270 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 107: Maintenance And Cleaning

    AFL-W19A/W19B/17D/W15A-N270 Panel PC A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the AFL-W19A/W19B/17D/W15A-N270, please read the details below.  Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth.

  • Page 108: Bbios Options

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Appendix BIOS Options Page 98...
  • Page 109 AFL-W19A/W19B/17D/W15A-N270 Panel PC Below is a list of BIOS configuration options in the BIOS chapter.  System Overview .........................48  System Time [xx:xx:xx] .......................49  System Date [xx/xx/xx] ......................49  ATA/IDE Configuration [Compatible].................51  Legacy IDE Channels [SATA Pri, PATA Sec] ..............51 ...
  • Page 110 AFL-W19A/W19B/17D/W15A-N270 Panel PC  Resume on Keyboard/Mouse [Disabled] ................66  Resume on Ring [Disabled] ....................66  Resume on PCI-Express WAKE# [Enabled]..............66  Resume On RTC Alarm [Disabled]..................66  Remote Access [Disabled]....................67  Serial Port Number [COM1]....................68  Base Address, IRQ [2F8h,3]....................68 ...
  • Page 111 AFL-W19A/W19B/17D/W15A-N270 Panel PC  DVMT Mode Select [DVMT Mode]..................86  DVMT/FIXED Memory [128 MB] ..................86  Boot Display Device [Auto]....................86  Panel Type ..........................87  Current Jumper Setting.......................87  Audio Controller [Auto] .......................88  Save Changes and Exit .......................88 ...

  • Page 112: C Terminology

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Appendix Terminology Page 102...
  • Page 113 AFL-W19A/W19B/17D/W15A-N270 Panel PC Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® AC ’97 in 1997. Advanced Configuration and Power Interface (ACPI) is an OS-directed ACPI configuration, power management, and thermal management interface. Advanced Host Controller Interface (AHCI) is a SATA Host controller AHCI register-level interface.
  • Page 114 AFL-W19A/W19B/17D/W15A-N270 Panel PC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. Dual Inline Memory Modules are a type of RAM that offer a 64-bit data DIMM bus and have separate electrical contacts on each side of the module.
  • Page 115 AFL-W19A/W19B/17D/W15A-N270 Panel PC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. Low-voltage differential signaling (LVDS) is a dual-wire, high-speed LVDS differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 116: D Watchdog Timer

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Appendix Watchdog Timer Page 106...
  • Page 117 AFL-W19A/W19B/17D/W15A-N270 Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 118: Example Program

    AFL-W19A/W19B/17D/W15A-N270 Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 119: E Hazardous Materials Disclosure

    AFL-W19A/W19B/17D/W15A-N270 Panel PC Appendix Hazardous Materials Disclosure Page 109...

  • Page 120: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    AFL-W19A/W19B/17D/W15A-N270 Panel PC E.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 121 AFL-W19A/W19B/17D/W15A-N270 Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
