AFL2-W15A-N270/L325 Panel PC
IEI Technology Corp.
MODEL:
AFL2-W15A-N270/L325
Panel PC with Touch Screen Intel® or AMD CPU
Gigabit Ethernet, USB, Audio, RS-232/422/485, SATA
RoHS Compliant, IP 64 Protection
Rev. 1.01 – 28 June 2013

User Manual

Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFL2-W15A-N270/L325 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology AFL2-W15A-N270/L325

Summary of Contents for IEI Technology AFL2-W15A-N270/L325

  • Page 1: User Manual

    AFL2-W15A-N270/L325 Panel PC IEI Technology Corp. MODEL: AFL2-W15A-N270/L325 Panel PC with Touch Screen Intel® or AMD CPU Gigabit Ethernet, USB, Audio, RS-232/422/485, SATA RoHS Compliant, IP 64 Protection User Manual Page i Rev. 1.01 – 28 June 2013...
  • Page 2 AFL2-W15A-N270/L325 Panel PC Revision Date Version Changes 28 June 2013 1.01 Updated Section 2.8: Mounting the System 28 March, 2011 1.00 Initial release Page ii...
  • Page 3 AFL2-W15A-N270/L325 Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    AFL2-W15A-N270/L325 Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 M ....................3 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 E ....................4 XTERNAL VERVIEW 1.4.1 Front Panel ......................4 1.4.2 Rear Panel ......................4 1.4.3 Bottom Panel......................
  • Page 5 AFL2-W15A-N270/L325 Panel PC 2.8 M ..................36 OUNTING THE YSTEM 2.8.1 Arm Mounting ....................36 2.8.2 Panel Mounting....................38 2.8.3 Stand Mounting ....................40 2.8.4 Wall Mounting....................41 2.9 B ................. 44 OTTOM ANEL ONNECTORS 2.9.1 LAN Connection....................45 2.9.2 Serial Device Connection ................46 2.9.3 USB Device Connection...................
  • Page 6 AFL2-W15A-N270/L325 Panel PC 3.3.7 USB Configuration................... 77 3.3.7.1 USB Mass Storage Device Configuration..........78 3.4 PCI/P P........................80 3.5 B ........................82 3.5.1 Boot Settings Configuration................83 3.5.2 Boot Device Priority ..................85 3.5.3 Hard Disk Drives ..................... 86 3.5.4 Removable Drives .................... 86 3.5.5 CD/DVD Drives ....................
  • Page 7 AFL2-W15A-N270/L325 Panel PC B.2 S .................110 ETUP ROCEDURE FOR INDOWS B.2.1 Hardware and BIOS Setup ................110 B.2.2 Create Partitions .................... 111 B.2.3 Install Operating System, Drivers and Applications ........114 B.2.4 Build-up Recovery Partition................115 B.2.5 Create Factory Default Image................117 B.3 S ................
  • Page 8 AFL2-W15A-N270/L325 Panel PC List of Figures Figure 1-1: AFL2-W15A-N270/L325 ....................2 Figure 1-2: Front Panel ........................4 Figure 1-3: Rear Panel........................5 Figure 1-4: AFL2-W15A-N270 Bottom Panel................6 Figure 1-5: AFL2-W15A-L325 Bottom Panel ................6 Figure 1–6: Dimensions .........................9 Figure 2-1: Plastic Back Cover Retention Screws ..............14 Figure 2-2: HDD/CF Card Brackets (shown with all plastic covers removed)......14...
  • Page 9 AFL2-W15A-N270/L325 Panel PC Figure 2-30: AFL2-W15A-N270 Bottom Panel................44 Figure 2-31: AFL2-W15A-L325 Bottom Panel ................45 Figure 2-32: LAN Connection ......................45 Figure 2-33: Serial Device Connector..................46 Figure 2-34: USB Device Connection ..................47 Figure 2-35: VGA Connector .......................48 Figure 2-36: RFID Serial Port Settings..................50 Figure 4-1: Back Cover Retention Screws .................99...
  • Page 10 AFL2-W15A-N270/L325 Panel PC Figure B-26: Recovery Tool Main Menu .................. 126 Figure B-27: Restore Factory Default ..................127 Figure B-28: Recovery Complete Window ................127 Figure B-29: Backup System....................128 Figure B-30: System Backup Complete Window ..............128 Figure B-31: Restore Backup ....................129 Figure B-32: Restore System Backup Complete Window .............
  • Page 11 AFL2-W15A-N270/L325 Panel PC List of Tables Table 1-1: Model Variations ......................3 Table 1-2: System Specifications....................8 Table 2-1: Packing List.........................13 Table 2-2: Slot 1 and Slot 2 Pinouts (for Type A Module)............20 Table 2-3: Slot 3 Pinouts (for Type B Module)................21 Table 2-4: AFL2-W15A-N270 Jumpers..................23...
  • Page 12 AFL2-W15A-N270/L325 Panel PC BIOS Menus BIOS Menu 1: Main ........................55 BIOS Menu 2: Advanced ......................56 BIOS Menu 3: CPU Configuration ....................57 BIOS Menu 4: IDE Configuration....................58 BIOS Menu 5: IDE Master and IDE Slave Configuration ............59 BIOS Menu 6: Super IO Configuration..................64 BIOS Menu 7: Hardware Health Configuration ................68...

  • Page 13: Introduction

    AFL2-W15A-N270/L325 Panel PC Chapter Introduction Page 1...

  • Page 14: Overview

    AFL2-W15A-N270/L325 Panel PC 1.1 Overview Figure 1-1: AFL2-W15A-N270/L325 The Afolux panel PCs are all-in-one panel PCs with all the elements of a desktop computer contained in a single, slim package, no bigger than a thick monitor. The Afolux panel PCs can be mounted on a desktop monitor stand and save a huge amount of desktop space by including all the computer components behind the screen.

  • Page 15: Model Variations

    AFL2-W15A-N270/L325 Panel PC 1.2 Model Variations There are six models of the AFL2-W15A-N270/L325 series. The model variations are listed below. AFL2-W15A- RFID Reader 1.6 GHz Intel® Atom N270/R/1G-R10 processor N270 1.6 GHz Intel® Atom EM card reader. N270/R-EM/1G-R10 processor N270 1.6 GHz Intel®...

  • Page 16: External Overview

    The rear panel contains a smaller access panel, all the cable connections and the mounting holes. 1.4.1 Front Panel The front side of the AFL2-W15A-N270/L325 is a flat panel LCD screen surrounded by a plastic frame. Figure 1-2: Front Panel 1.4.2 Rear Panel...

  • Page 17: Bottom Panel

    AFL2-W15A-N270/L325 Panel PC Figure 1-3: Rear Panel 1.4.3 Bottom Panel The bottom panel has the following slots, buttons and switches (Figure 1-5): 1 x RJ-45 jack for Gigabit LAN 1 x Audio Line-out jack 1 x OSD keypad 1 x Power switch...

  • Page 18: Internal Overview

    AFL2-W15A-N270/L325 Panel PC Figure 1-4: AFL2-W15A-N270 Bottom Panel Figure 1-5: AFL2-W15A-L325 Bottom Panel 1.5 Internal Overview All the components are contained under the rear panel. The internal components include the touch panel module and the motherboard. The motherboard has memory, a wireless module, a SATA hard drive bay, and three expansion interfaces.

  • Page 19: Specifications

    AFL2-W15A-N270/L325 Panel PC 1.6 Specifications The technical specifications for the AFL2-W15A-N270/L325 systems are listed in Table 1-2. SPECIFICATIONS AFL2-W15A-N270 AFL2-W15A-L325 Mainboard AFLMB2-945GSE-N270 AFL2MB-780E-R10 1.6 GHz Intel® Atom processor N270 1.6GHz AMD™ ASB1 dual core L325 Chipset Intel® 945GSE + ICH7M...

  • Page 20: Table 1-2: System Specifications

    AFL2-W15A-N270/L325 Panel PC SPECIFICATIONS AFL2-W15A-N270 AFL2-W15A-L325 Bluetooth Bluetooth V2.1+EDR Bluetooth V2.1+EDR HSUPA Optional HSUPA Mobile Module (supports Optional HSUPA Mobile Module GSM 850, EGSM 900, DCS 1800 & 1900) (supports GSM 850, EGSM 900, DCS 1800 & 1900) RFID Reader...

  • Page 21: Dimensions

    AFL2-W15A-N270/L325 Panel PC 1.7 Dimensions Width: 400 mm; Height: 267 mm; Depth: 54 mm. Figure 1–6: Dimensions Page 9...

  • Page 22: Installation

    AFL2-W15A-N270/L325 Panel PC Chapter Installation Page 10...
  • Page 23 AFL2-W15A-N270/L325 Panel PC WARNING: When installing the AFL2-W15A-N270/L325, make sure to: Turn the power off: Chance of electrocution. Turn off the monitor and unplug it from the power supply. Only let certified engineers change the hardware settings: Incorrect settings can cause irreparable damage to the product.

  • Page 24: Unpack The Panel Pc

    Lift the monitor out of the boxes. Step 5: Remove the peripheral parts box from the main box. Step 6: S t e p 0 : 2.2 Packing List The AFL2-W15A-N270/L325 flat panel PC is shipped with the following components: Quantity Item Image AFL2-W15A-N270/L325 Power adapter...

  • Page 25: Hard Drive Installation

    If any of these items are missing or damaged, contact the distributor or sales representative immediately. 2.3 Hard Drive Installation This section outlines the installation of the hard drive in the AFL2-W15A-N270/L325. To install the hard drive, please follow the steps below: Unfasten the right plastic side access panel (SATA/CF card/USB dongle access...

  • Page 26: Figure 2-1: Plastic Back Cover Retention Screws

    AFL2-W15A-N270/L325 Panel PC Figure 2-1: Plastic Back Cover Retention Screws Locate the HDD/CF card brackets. Unfasten screws and removed brackets (See Step 2: figure below). Figure 2-2: HDD/CF Card Brackets (shown with all plastic covers removed) Page 14...

  • Page 27: Compactflash® Installation

    AFL2-W15A-N270/L325 Panel PC Insert the SATA connector end of the HDD into the bracket to connect the Step 3: motherboard SATA connector to the hard drive SATA connector as shown in the figure below. Figure 2–3: HDD Installation (shown with all covers removed) Replace the brackets, covers and screws.S t e p 0 :...

  • Page 28: Figure 2-4: Compactflash® Slot Location (Shown With All Covers Removed)

    AFL2-W15A-N270/L325 Panel PC Figure 2–4: CompactFlash® Slot Location (shown with all covers removed) Install the CompactFlash® card into the slot (see figure below). Step 3: Page 16...

  • Page 29: Expansion Module Installation

    AFL2-W15A-N270/L325. To install the modules, please follow the steps below: Unfasten the left plastic side access panel (Expansion module access panel) Step 1: retention screws and remove the left plastic side access panel (See figure below).

  • Page 30: Figure 2-6: Plastic Back Cover Retention Screws

    AFL2-W15A-N270/L325 Panel PC Figure 2-6: Plastic Back Cover Retention Screws Locate the two bracket retention screws. Unfasten screws and remove the Step 2: bracket (See figure below, indicated in yellow). If a serial port expansion module is installed, then remove the serial port retention screws before removing the bracket.

  • Page 31: Figure 2-7: Expansion Module Installation (Shown With All Covers Removed)

    AFL2-W15A-N270/L325 Panel PC Figure 2-7: Expansion module installation (shown with all covers removed) Insert the expansion module connector end of the expansion module into the Step 3: motherboard module connector to connect the module (See above). Fasten the expansion module retention screws.

  • Page 32: Expansion Module Slot Pinouts

    AFL2-W15A-N270/L325 Panel PC 2.5.1 Expansion Module Slot Pinouts There are three connector for two kinds of expansion modules, Type A module and Type B module. Slot 1 and Slot 2 are for installing Type A module and Slot 3 is for Type B module.

  • Page 33: Table 2-3: Slot 3 Pinouts (For Type B Module)

    AFL2-W15A-N270/L325 Panel PC Description Description DCD-5 DSR-5 Serial RXD-5 RTS-5 Ports TXD-5 CTS-5 DTR-5 RI-5 DCD-6 DSR-6 RXD-6 RTS-6 TXD-6 CTS-6 DTR-6 RI-6 Parallel Port -STB -AFD -ERR -INIT -SLIN -ACK BUSY SLCT VCC5 VCC12 VCC5 VCC12 VCC5 VCC12 Table 2-3: Slot 3 Pinouts (for Type B Module) For the dimensions of the Type A and Type B expansion modules, please refer to Appendix C.

  • Page 34: Usb Dongle Installation (Afl2-W15A-N270 Only)

    AFL2-W15A-N270/L325 Panel PC 2.6 USB Dongle Installation (AFL2-W15A-N270 only) The installation for an USB dongle is described in this section. Remove the access panel and brackets as described in the HDD installation Step 1: instructions. Locate the USB dongle connector and install the USB dongle as shown below.

  • Page 35: Jumper Settings

    The following jumpers can be found on the motherboard installed in the AFL2-W15A-N270/L325. Before the AFL2-W15A-N270/L325 is installed, the jumpers must be set in accordance with the desired configuration. The jumpers on the AFL2-W15A-N270/L325 motherboard are listed in Table 2-4.

  • Page 36: Access The Jumpers

    AFL2-W15A-N270/L325 Panel PC Description Label Type CF card setup 2-pin header Clear CMOS J_CMOS1 3-pin header COM1 Pin 9 setting 10-pin header COM3 Pin 9 setting 6-pin header COM3 RX RS-232/422/485 select JP11 8-pin header COM3 RS-232/422/485 select 12-pin header...

  • Page 37: Clear Cmos Jumper

    AFL2-W15A-N270/L325 Panel PC AFL2-W15A-N270 AFL2-W15A-L325 Figure 2-9: CF Card Setup Jumper Location 2.7.3 Clear CMOS Jumper Jumper Label: J_CMOS1 3-pin header Jumper Type: See Table 2-7 Jumper Settings: See Figure 2-10 Jumper Location: Page 25...

  • Page 38: Table 2-7: Clear Cmos Jumper Settings

    AFL2-W15A-N270/L325 Panel PC If the AFL2-W15A-N270/L325 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close the pins for a few seconds then remove the jumper clip.

  • Page 39: Com 1 Port Pin 9 Select

    AFL2-W15A-N270/L325 Panel PC AFL2-W15A-L325 Figure 2-10: Clear CMOS Jumper 2.7.4 COM 1 Port Pin 9 Select Jumper Label: JP5 (AFL2-W15A-N270) JP7 (AFL2-W15A-L325) 10-pin header Jumper Type: See Table 2-8 Jumper Settings: See Figure 2-11 Jumper Location: The jumper configures pin 9 on COM1 connector. Pin 9 on the COM1 connector can be set as the ring (RI) signal, +5 V or +12 V.

  • Page 40: Figure 2-11: Com1 Pin 9 Setting Jumper Locations

    AFL2-W15A-N270/L325 Panel PC AFL2-W15A-N270 AFL2-W15A-L325 Figure 2-11: COM1 Pin 9 Setting Jumper Locations Page 28...

  • Page 41: Com 3 Port Pin 9 Select

    AFL2-W15A-N270/L325 Panel PC 2.7.5 COM 3 Port Pin 9 Select Jumper Label: JP7 (AFL2-W15A-N270) JP8 (AFL2-W15A-L325) 6-pin header Jumper Type: See Table 2-9 Jumper Settings: See Figure 2-12 Jumper Location: The jumper configures pin 9 on COM3 DB-9 connectors. Pin 9 on the COM3 DB-9 connector can be set as the ring (RI) signal, +5 V or +12 V.

  • Page 42: Com3 Rx Function Select Jumper

    AFL2-W15A-N270/L325 Panel PC AFL2-W15A-L325 Figure 2-12: COM3 Pin 9 Setting Jumper Locations 2.7.6 COM3 RX Function Select Jumper Jumper Label: JP8 (AFL2-W15A-N270) JP11 (AFL2-W15A-L325) 8-pin header Jumper Type: See Table 2-10 Jumper Settings: See Figure 2-13 Jumper Location: The COM3 RX Function Select jumper sets the communication protocol used by the RX serial communications port COM3 as RS-232, RS-422 or RS-485.

  • Page 43: Figure 2-13: Com3 Rx Function Select Jumper Location

    AFL2-W15A-N270/L325 Panel PC The COM3 RX Function Select jumper location is shown in Figure 2-13. AFL2-W15A-N270 AFL2-W15A-L325 Figure 2-13: COM3 RX Function Select Jumper Location Page 31...

  • Page 44: Com3 Rs-232/422/485 Serial Port Select Jumper

    AFL2-W15A-N270/L325 Panel PC 2.7.7 COM3 RS-232/422/485 Serial Port Select Jumper Jumper Label: JP10 (AFL2-W15A-N270) JP9 (AFL2-W15A-L325) 12-pin header (four 3-pin headers combined) Jumper Type: See Table 2-11 Jumper Settings: See Figure 2-14 Jumper Location: The COM3 RS-232/422/485 Serial Port Select jumper sets the communication protocol used by the second serial communications port (COM3) as RS-232, RS-422 or RS-485.

  • Page 45: Figure 2-14: Com3 Rs-232/422/485 Serial Port Select Jumper Location

    AFL2-W15A-N270/L325 Panel PC AFL2-W15A-N270 AFL2-W15A-L325 Figure 2-14: COM3 RS-232/422/485 Serial Port Select Jumper Location Page 33...

  • Page 46: Com3 Tx Function Select Jumper

    AFL2-W15A-N270/L325 Panel PC 2.7.8 COM3 TX Function Select Jumper Jumper Label: JP11 (AFL2-W15A-N270) JP10 (AFL2-W15A-L325) 6-pin header Jumper Type: See Table 2-12 Jumper Settings: See Figure 2-15 Jumper Location: The COM3 TX Function Select jumper configures the TX pin on COM3 serial port connector as RS-422 as an RS-485.

  • Page 47: Com3 Rs-422 And Rs-485 Pinouts

    AFL2-W15A-N270/L325 Panel PC AFL2-W15A-L325 Figure 2-15: COM3 TX Function Select Jumper Pinout Locations 2.7.8.1 COM3 RS-422 and RS-485 Pinouts The pinouts for RS-422 and RS-485 operation of external serial port COM 3 are detailed below. COM 3 RS-422 Description Pin 1...

  • Page 48: Mounting The System

    The AFL2-W15A-N270/L325 is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 100 mm interface pad. To mount the AFL2-W15A-N270/L325 on an arm, please follow the steps below. The arm is a separately purchased item. Please correctly mount the arm onto Step 1: the surface it uses as a base.

  • Page 49: Figure 2-16: Arm Mount Retention Screw Holes

    AFL2-W15A-N270/L325. The AFL2-W15A-N270/L325 arm mount retention screw holes are shown in Figure 2-16. Figure 2-16: Arm Mount Retention Screw Holes Secure the AFL2-W15A-N270/L325 to the interface pad by inserting four Step 4: retention screws through the mounting arm interface pad and into the AFL2-W15A-N270/L325.

  • Page 50: Panel Mounting

    AFL2-W15A-N270/L325 Panel PC Figure 2-17: Arm Mounting (ARM-11-RS) 2.8.2 Panel Mounting To mount the panel PC into a panel, please follow the steps below. Select the position on the panel to mount the flat panel PC. Step 1: Cut out a section corresponding to the size shown below. The size must be Step 2: smaller then the outer edge.

  • Page 51: Figure 2-18: Cutout

    Step 6: of the panel mounting brackets (Figure 2-19 ). There are a total of 4 panel mounting clamps for the AFL2-W15A-N270/L325. Tighten the screws that pass through the panel mounting clamps until the plastic Step 7: caps at the front of all the screws are firmly secured to the panel...

  • Page 52: Stand Mounting

    2.8.3 Stand Mounting To mount the AFL2-W15A-N270/L325 using the stand mounting kit, please follow the steps below. Locate the screw holes on the rear of the AFL2-W15A-N270/L325. This is where Step 1: the bracket will be attached. Align the bracket with the screw holes.

  • Page 53: Wall Mounting

    AFL2-W15A-N270/L325 Panel PC Figure 2-20: Stand Mounting (Stand-A19) 2.8.4 Wall Mounting To mount the flat panel PC onto the wall, please follow the steps below. Figure 2-21: Wall Mount Select the location on the wall for the wall-mounting bracket. Step 1: Carefully mark the locations of the four brackets screw holes on the wall.

  • Page 54: Figure 2-22: Wall-Mounting Bracket

    AFL2-W15A-N270/L325 Panel PC Drill four pilot holes at the marked locations on the wall for the bracket retention Step 3: screws. Align the wall-mounting bracket screw holes with the pilot holes. Step 4: Secure the mounting-bracket to the wall by inserting the retention screws into Step 5: the four pilot holes and tightening them (Figure 2-22).

  • Page 55: Figure 2-23: Chassis Support Screws

    AFL2-W15A-N270/L325 Panel PC Figure 2-23: Chassis Support Screws NOTE: In the diagram below the bracket is already installed on the wall. Secure the panel PC by fastening the retention screw of the wall-mounting Step 9: bracket. (Figure 2-24). Page 43...

  • Page 56: Bottom Panel Connectors

    AFL2-W15A-N270/L325 Panel PC Figure 2-24: Secure the Panel PC 2.9 Bottom Panel Connectors The bottom panel connectors extend the capabilities of the panel PC but are not essential for operation (except power). Figure 2-25: AFL2-W15A-N270 Bottom Panel Page 44...

  • Page 57: Lan Connection

    AFL2-W15A-N270/L325. Align the connectors. Align the RJ-45 connector on the LAN cable with one of Step 2: the RJ-45 connectors on the bottom panel of the AFL2-W15A-N270/L325. See Figure 2-27. Figure 2-27: LAN Connection Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN Step 3: cable RJ-45 connector into the onboard RJ-45 port.

  • Page 58: Serial Device Connection

    AFL2-W15A-N270/L325. Follow the steps below to connect a serial device to the AFL2-W15A-N270/L325 panel PC. Locate the DB-9 connector. The location of the DB-9 connector is shown in Step 1: Chapter 2. Insert the serial connector. Insert the DB-9 connector of a serial device into Step 2: the DB-9 connector on the bottom panel.

  • Page 59: Vga Monitor Connection

    2.9.4 VGA Monitor Connection The VGA output can be connected to an external VGA monitor. To connect the VGA monitor to the AFL2-W15A-N270/L325, please follow the instructions below. Locate the female DB-15 connector. The location of the female DB-15 Step 1: connector is shown in Chapter 3.

  • Page 60: Power Connection

    S t e p 0 : 2.11 RFID Reader Specs and Setup (Optional) Some of the AFL2-W15A-N270/L325 models include RFID reader. There are two types of RFID modules and the specifications of the RFID modules are listed below. 2.11.1 RFID Module for EM Models...

  • Page 61: Rfid Module For Mf Model

    AFL2-W15A-N270/L325 Panel PC Frequency 125 KHz, ASK Interface Wiegand 26 bits, ABA Track2, Serial TTL 9600bps, 8N1 Resolution > 8cm Transponders Supported Read only Dimensions L90.00x W22.5xH24.00 mm with cover Table 2-15: RFID Module Specifications for EM Models 2.11.2 RFID Module for MF Model...

  • Page 62: Figure 2-36: Rfid Serial Port Settings

    AFL2-W15A-N270/L325 Panel PC Setup the port properties as shown below. Step 2: Bits per second: 9600 Data bits: 8 Parity: None Stop bits: 1 Flow control: None Figure 2-31: RFID Serial Port Settings Page 50...

  • Page 63: Driver Installation

    AFL2-W15A-N270/L325 Panel PC 2.12 Driver Installation NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates.

  • Page 64: Bios Setup

    AFL2-W15A-N270/L325 Panel PC Chapter BIOS Setup Page 52...

  • Page 65: Introduction

    AFL2-W15A-N270/L325 Panel PC 3.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 3.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 66: Getting Help

    AFL2-W15A-N270/L325 Panel PC Function F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 3-1: BIOS Navigation Keys 3.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.

  • Page 67: Main

    AFL2-W15A-N270/L325 Panel PC 3.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 68: Advanced

    AFL2-W15A-N270/L325 Panel PC The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.

  • Page 69: Cpu Configuration

    AFL2-W15A-N270/L325 Panel PC 3.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications and configure the CPU. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit CPU Configuration Module Version: 13.55 AGESA Version: 3.3.2.4...

  • Page 70: Ide Configuration

    AFL2-W15A-N270/L325 Panel PC 3.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit IDE Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 71: Ide Master, Ide Slave

    AFL2-W15A-N270/L325 Panel PC 3.3.2.1 IDE Master, IDE Slave Use the IDE Master and IDE Slave configuration menu to view both primary and secondary IDE device details and configure the IDE devices connected to the system. BIOS SETUP UTILITY Main Advanced...

  • Page 72: Type [Auto]

    AFL2-W15A-N270/L325 Panel PC Async DMA: Indicates the highest Asynchronous DMA Mode that is supported. Ultra DMA: Indicates the highest Synchronous DMA Mode that is supported. S.M.A.R.T.: Indicates whether or not the Self-Monitoring Analysis and Reporting Technology protocol is supported. 32Bit Data Transfer: Enables 32-bit data transfer.

  • Page 73: Block (Multi Sector Transfer) [Auto]

    AFL2-W15A-N270/L325 Panel PC BIOS auto detects the LBA mode control on the specified Auto EFAULT channel. Block (Multi Sector Transfer) [Auto] Use the Block (Multi Sector Transfer) to disable or enable BIOS to auto detect if the device supports multi-sector transfers.

  • Page 74: Dma Mode [Auto]

    AFL2-W15A-N270/L325 Panel PC DMA Mode [Auto] Use the DMA Mode BIOS selection to adjust the DMA mode options. BIOS auto detects the DMA mode. Use this value if the IDE Auto EFAULT disk drive support cannot be determined. Single Word DMA mode 0 selected with a maximum data SWDMA0 transfer rate of 2.1 MB/s...

  • Page 75: Auto]

    AFL2-W15A-N270/L325 Panel PC Ultra DMA mode 5 selected with a maximum data transfer UDMA5 rate of 99.9 MB/s (To use this mode, it is required that an 80-conductor ATA cable is used.) S.M.A.R.T [Auto] Use the S.M.A.R.T option to auto-detect, disable or enable Self-Monitoring Analysis and Reporting Technology (SMART) on the drive on the specified channel.

  • Page 76: Super Io Configuration

    AFL2-W15A-N270/L325 Panel PC 3.3.3 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 6) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 77: Parallel Port Address [Disabled]

    AFL2-W15A-N270/L325 Panel PC Parallel Port Address [Disabled] Use the Parallel Port Address option to select the parallel port base address. No base address is assigned to the Parallel Port Disabled EFAULT Parallel Port I/O port address is 378 Parallel Port I/O port address is 278...

  • Page 78: Parallel Port Irq [Irq7]

    AFL2-W15A-N270/L325 Panel PC The parallel port operates in the extended EPP+ECP capabilities port (ECP) mode. The ECP mode supports bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster than the Normal mode...

  • Page 79: Serial Port5 Address [338]

    AFL2-W15A-N270/L325 Panel PC Serial Port 2 signaling mode is RS-232 RS232 EFAULT Serial Port 2 signaling mode is RS-485 RS485 Serial Port 2 signaling mode is RS-422 RS422 Serial Port5 Address [338] Selects the serial port base address. No base address...

  • Page 80: Hardware Health Configuration

    AFL2-W15A-N270/L325 Panel PC IRQ address 11 EFAULT 3.3.4 Hardware Health Configuration The Hardware Health Configuration menu (BIOS Menu 7) shows the operating temperature, fan speeds and system voltages. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Hardware Health Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 81: Icp Power Configuration

    AFL2-W15A-N270/L325 Panel PC 1.8V 1.2V 5V Dual VBAT 3.3.5 ICP Power Configuration The ICP Power Configuration menu (BIOS Menu 8) allows the advanced power management options to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit...

  • Page 82: Acpi Settings

    AFL2-W15A-N270/L325 Panel PC 3.3.5.1 ACPI Settings Use the ACPI Settings menu (BIOS Menu 9) to select the ACPI state when the system is suspended. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit ACPI Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Suspend Mode...

  • Page 83: Power Configuration

    AFL2-W15A-N270/L325 Panel PC 3.3.5.2 Power Configuration The Power Configuration menu (BIOS Menu 10) allows the advanced power management options to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Power Button Mode [On/Off] If the AT/ATX jumper...

  • Page 84: Resume On Ring [Disabled]

    AFL2-W15A-N270/L325 Panel PC Resume on Ring [Disabled] Use the Resume on Ring BIOS option to enable activity on the RI (ring in) modem line to rouse the system from a suspend or standby state. That is, the system will be roused by an incoming call on a modem.

  • Page 85: Remote Access Configuration

    AFL2-W15A-N270/L325 Panel PC 3.3.6 Remote Access Configuration Use the Remote Access Configuration menu (BIOS Menu 11) to configure remote access parameters. The Remote Access Configuration is an AMIBIOS feature and allows a remote host running a terminal program to display and configure the BIOS settings.

  • Page 86: Serial Port Number [Com1]

    AFL2-W15A-N270/L325 Panel PC Remote access configuration options shown below Enabled appear: Serial Port Number Serial Port Mode Flow Control Redirection after BIOS POST Terminal Type VT-UTF8 Combo Key Support These configuration options are discussed below. Serial Port Number [COM1] Use the Serial Port Number option allows to select the serial port used for remote access.

  • Page 87: Flow Control [None]

    AFL2-W15A-N270/L325 Panel PC NOTE: Identical baud rate setting musts be set on the host (a management computer running a terminal software) and the slave Flow Control [None] Use the Flow Control option to report the flow control method for the console redirection application.

  • Page 88: Vt-Utf8 Combo Key Support [Disabled]

    AFL2-W15A-N270/L325 Panel PC VT-UTF8 Combo Key Support [Disabled] Use the VT-UFT8 Combo Key Support option to enable additional keys that are not provided by VT100 for the PC 101 keyboard. The VT100 Terminal Definition is the standard convention used to configure and conduct emergency management tasks with UNIX-based servers.

  • Page 89: Usb Configuration

    AFL2-W15A-N270/L325 Panel PC 3.3.7 USB Configuration Use the USB Configuration menu (BIOS Menu 12) to read USB configuration information and configure the USB settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit USB Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Disabled Module Version –...

  • Page 90: Usb Mass Storage Device Configuration

    AFL2-W15A-N270/L325 Panel PC Legacy USB support disabled Disabled Legacy USB support enabled Enabled EFAULT Legacy USB support disabled if no USB devices are Auto connected USB2.0 Controller Mode [HiSpeed] Use the USB2.0 Controller Mode option to set the speed of the USB2.0 controller.

  • Page 91: Device

    AFL2-W15A-N270/L325 Panel PC POST waits 10 seconds for the USB mass storage 10 Sec device after the start unit command. POST waits 20 seconds for the USB mass storage 20 Sec EFAULT device after the start unit command. POST waits 30 seconds for the USB mass storage 30 Sec device after the start unit command.

  • Page 92: Pci/Pnp

    AFL2-W15A-N270/L325 Panel PC 3.4 PCI/PnP Use the PCI/PnP menu (BIOS Menu 14) to configure advanced PCI and PnP settings. WARNING! Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause the system to malfunction. BIOS SETUP UTILITY...

  • Page 93: Dma Channel# [Available]

    AFL2-W15A-N270/L325 Panel PC The specified IRQ is reserved for use by Legacy ISA Reserved devices Available IRQ addresses are: IRQ3 IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device.

  • Page 94: Boot

    AFL2-W15A-N270/L325 Panel PC Reserved Memory Size [Disabled] Use the Reserved Memory Size BIOS option to specify the amount of memory that should be reserved for legacy ISA devices. No memory block reserved for legacy ISA devices Disabled EFAULT 16 KB reserved for legacy ISA devices...

  • Page 95: Boot Settings Configuration

    AFL2-W15A-N270/L325 Panel PC 3.5.1 Boot Settings Configuration Use the Boot Settings Configuration menu (BIOS Menu 16) to configure advanced system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Boot Settings Configuration Allows BIOS to skip ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 96: Addon Rom Display Mode [Force Bios]

    AFL2-W15A-N270/L325 Panel PC AddOn ROM Display Mode [Force BIOS] Use the AddOn ROM Display Mode option to allow add-on ROM (read-only memory) messages to be displayed. The system forces third party BIOS to display Force BIOS EFAULT during system boot.

  • Page 97: Boot Device Priority

    AFL2-W15A-N270/L325 Panel PC Spread Spectrum Mode [Disabled] The Spread Spectrum Mode option can help to improve CPU EMI issues. The spread spectrum mode is disabled Disabled EFAULT The spread spectrum mode is enabled Enabled 3.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 17) to specify the boot sequence from the available devices.

  • Page 98: Hard Disk Drives

    AFL2-W15A-N270/L325 Panel PC 3.5.3 Hard Disk Drives Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs. Only installed hard drives are shown. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 99: Cd/Dvd Drives

    AFL2-W15A-N270/L325 Panel PC 3.5.5 CD/DVD Drives Use the CD/DVD Drives menu to specify the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system are listed as shown below:...

  • Page 100: Security

    AFL2-W15A-N270/L325 Panel PC 3.6 Security Use the Security menu (BIOS Menu 21) to set system and user passwords. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Security Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Supervisor Password :Not Installed User Password :Not Installed...

  • Page 101: Advanced Chipset Settings

    AFL2-W15A-N270/L325 Panel PC 3.7 Advanced Chipset Settings Use the Advanced Chipset Settings menu (BIOS Menu 22) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 102: Northbridge Configuration

    AFL2-W15A-N270/L325 Panel PC 3.7.1 Northbridge Configuration Use the Northbridge Chipset Configuration menu (BIOS Menu 25) to configure the Northbridge chipset. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Northbridge Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ > ECC Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Memory CLK...

  • Page 103: Dram Ecc Enable [Enabled]

    AFL2-W15A-N270/L325 Panel PC DRAM ECC Enable [Enabled] Use the DRAM ECC Enable option to enable the hardware to report and correct memory errors and thereby automatically maintain the system. System cannot report and correct memory errors Disabled System can report and correct memory errors...

  • Page 104: Data Cache Bg Scrub [Disabled]

    AFL2-W15A-N270/L325 Panel PC The following configuration options are available: Disabled (Default), 40ns, 80ns, 160ns, 320ns, 640ns, 1.28us, 2.56us, 5.12us, 10.2us, 20.5us, 41.0us, 81.9us, 163.8us, 327.7us, 655.4us, 1.31ms, 2.62ms, 5.24ms, 10.49ms, 20.97ms, 42.00ms, 84.00ms. Data Cache BG Scrub [Disabled] Use the Data Cache BG Scrub option to enable the system to correct the L1 Data cache when idle.

  • Page 105: Northbridge2 Configuration

    AFL2-W15A-N270/L325 Panel PC 3.7.3 Northbridge2 Configuration Use the Northbridge2 Chipset Configuration menu (BIOS Menu 25) to configure the Northbridge chipset. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Northbridge2 Chipset Configuration RS780 CIMx Version : 4.6.0 ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 106: Southbridge Configuration

    AFL2-W15A-N270/L325 Panel PC UMA Buffer Size [Auto] Use the UMA Buffer Size option to specify the memory to be reserved for the integrated graphics. The following configuration options are available: Auto Default 32 MB 64 MB 128 MB 256 MB...

  • Page 107: Exit

    AFL2-W15A-N270/L325 Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Southbridge Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Auto Audio Controller [Auto] Azalia AC'97 Audio Only All Disabled Select Screen ↑ ↓ Select Item Enter Go to SubScreen General Help...

  • Page 108: Bios Menu 27:Exit

    AFL2-W15A-N270/L325 Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Exit Options Exit system setup after ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ saving the changes. Save Changes and Exit F10 key can be used for Discard Changes and Exit this operation...

  • Page 109: System Maintenance

    AFL2-W15A-N270/L325 Panel PC Chapter System Maintenance Page 97...

  • Page 110: System Maintenance Introduction

    AFL2-W15A-N270/L325 Panel PC 4.1 System Maintenance Introduction If the components of the AFL2-W15A-N270/L325 fail they must be replaced, such as the wireless LAN module or the motherboard. Please contact the system reseller or vendor to purchase the replacement parts. Back cover removal instructions and jumper settings for the AFL2-W15A-N270/L325 are described below.

  • Page 111: Memory Module Replacement

    AFL2-W15A-N270/L325 Panel PC Figure 4-1: Back Cover Retention Screws 4.4 Memory Module Replacement The flat panel PC has a preinstalled memory module. If the memory module fails, take the steps below to replace it. Remove the back cover. See Section 4.3 above.

  • Page 112: Figure 4-2: Afl2-W15A-L325 So-Dimm Slots (Shown With All Covers Removed)

    AFL2-W15A-N270/L325 Panel PC Figure 4-2: AFL2-W15A-L325 SO-DIMM Slots (shown with all covers removed) Remove the memory module by pulling both the spring retainer clips outward Step 3: from the socket. Grasp the memory module by the edges and carefully pull it out of the socket.

  • Page 113: A Safety Precautions

    AFL2-W15A-N270/L325 Panel PC Appendix Safety Precautions Page 101...

  • Page 114: Safety Precautions

    DO NOT strike or exert excessive force onto the LCD panel. DO NOT touch any of the LCD panels with a sharp object DO NOT use the AFL2-W15A-N270/L325 in a site where the ambient temperature exceeds the rated temperature Page 102...

  • Page 115: Anti-Static Precautions

    AFL2-W15A-N270/L325 and sever injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFL2-W15A-N270/L325. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFL2-W15A-N270/L325 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 116: Product Disposal

    Please follow the national guidelines for electrical and electronic product disposal. A.2 Maintenance and Cleaning Precautions When maintaining or cleaning the AFL2-W15A-N270/L325, please follow the guidelines below. A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the AFL2-W15A-N270/L325, please read the details below. Page 104...

  • Page 117: Cleaning Tools

    AFL2-W15A-N270/L325 Panel PC Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth. The interior does not require cleaning. Keep fluids away from the interior.

  • Page 118: B One Key Recovery

    AFL2-W15A-N270/L325 Panel PC Appendix One Key Recovery Page 106...

  • Page 119: One Key Recovery Introduction

    AFL2-W15A-N270/L325 Panel PC B.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. The one key recovery provides quick and easy shortcuts for creating a backup and reverting to that backup or for reverting to the factory default settings.

  • Page 120: System Requirement

    AFL2-W15A-N270/L325 Panel PC B.1.1 System Requirement NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware. To create the system backup, the main storage device must be split into two partitions (three partitions for Linux).

  • Page 121: Supported Operating System

    AFL2-W15A-N270/L325 Panel PC NOTE: Specialized tools are required to change the partition size if the operating system is already installed. B.1.2 Supported Operating System The recovery CD is compatible with both Microsoft Windows and Linux operating system (OS). The supported OS versions are listed below.

  • Page 122: Setup Procedure For Windows

    AFL2-W15A-N270/L325 Panel PC NOTE: Installing unsupported OS versions may cause the recovery tool to fail. B.2 Setup Procedure for Windows Prior to using the recovery tool to backup or restore Windows system, a few setup procedures are required. Hardware and BIOS setup (see Section Step 1: B .2.1)

  • Page 123: Create Partitions

    AFL2-W15A-N270/L325 Panel PC Turn on the system. Step 4: Press the <DELETE> key as soon as the system is turned on to enter the BIOS. Step 5: Select the connected optical disk drive as the 1 boot device. (Boot Step 6:...

  • Page 124: Figure B-3: Recovery Tool Setup Menu

    AFL2-W15A-N270/L325 Panel PC The recovery tool setup menu is shown as below. Step 3: Figure B-3: Recovery Tool Setup Menu Press <5> then <Enter>. Step 4: Figure B-4: Command Mode The command prompt window appears. Type the following commands (marked Step 5: in red) to create two partitions.

  • Page 125: Figure B-5: Partition Creation Commands

    AFL2-W15A-N270/L325 Panel PC system32>format F: /fs:ntfs /q /v:Recovery /y system32>exit Figure B-5: Partition Creation Commands Page 113...

  • Page 126: Install Operating System, Drivers And Applications

    AFL2-W15A-N270/L325 Panel PC NOTE: Use the following commands to check if the partitions were created successfully. Press any key to exit the recovery tool and automatically reboot the system. Step 6: Please continue to the following procedure: Build-up Recovery Partition.S t e p 0 : B.2.3 Install Operating System, Drivers and Applications...

  • Page 127: Build-Up Recovery Partition

    AFL2-W15A-N270/L325 Panel PC B.2.4 Build-up Recovery Partition Put the recover CD in the optical drive. Step 1: Start the system. Step 2: Boot the system from recovery CD. When prompted, press any key to boot Step 3: from the recovery CD. It will take a while to launch the recovery tool. Please be...

  • Page 128: Figure B-8: Build-Up Recovery Partition

    AFL2-W15A-N270/L325 Panel PC recovery files in Section B .2.2 is hidden and the recovery tool is saved in this partition. Figure B-8: Build-up Recovery Partition After completing the system configuration, press any key in the following window Step 6: to reboot the system.

  • Page 129: Create Factory Default Image

    AFL2-W15A-N270/L325 Panel PC B.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 130: Figure B-12: About Symantec Ghost Window

    AFL2-W15A-N270/L325 Panel PC Figure B-12: About Symantec Ghost Window Use mouse to navigate to the option shown below ( Step 4: F igure B-13). Figure B-13: Symantec Ghost Path Select the local source drive (Drive 1) as shown in F igure B-14. Then click OK.

  • Page 131: Figure B-14: Select A Local Source Drive

    AFL2-W15A-N270/L325 Panel PC Figure B-14: Select a Local Source Drive Select a source partition (Part 1) from basic drive as shown in Step 6: F igure B-15. Then click OK. Figure B-15: Select a Source Partition from Basic Drive Select 1.2: [Recovery] NTFS drive and enter a file name called Step 7: F igure B-16).

  • Page 132: Figure B-16: File Name To Copy Image To

    AFL2-W15A-N270/L325 Panel PC Figure B-16: File Name to Copy Image to When the Compress Image screen in F igure B-17 prompts, click High to make Step 8: the image file smaller. Figure B-17: Compress Image Page 120...

  • Page 133: Figure B-18: Image Creation Confirmation

    AFL2-W15A-N270/L325 Panel PC The Proceed with partition image creation window appears, click Yes to Step 9: continue. Figure B-18: Image Creation Confirmation The Symantec Ghost starts to create the factory default image ( Step 10: F igure B-19). Figure B-19: Image Creation Process...

  • Page 134: Setup Procedure For Linux

    AFL2-W15A-N270/L325 Panel PC The recovery tool main menu window is shown as below. Press any key to Step 12: reboot the system. S t e p 0 : Figure B-21: Press Any Key to Continue B.3 Setup Procedure for Linux The initial setup procedures for Linux system are mostly the same with the procedure for Microsoft Windows.

  • Page 135: Figure B-22: Partitions For Linux

    AFL2-W15A-N270/L325 Panel PC NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure B-22: Partitions for Linux Create a recovery partition. Insert the recovery CD into the optical disk drive. Step 3: Follow described in Section B .2.2. Then type the following...

  • Page 136: Figure B-23: System Configuration For Linux

    AFL2-W15A-N270/L325 Panel PC Figure B-23: System Configuration for Linux Access the recovery tool main menu by modifying the “menu.lst”. To first Step 5: access the recovery tool main menu, the menu.lst must be modified. In Linux system, enter Administrator (root). When prompt appears, type: cd /boot/grub vi menu.lst...

  • Page 137: Recovery Tool Functions

    AFL2-W15A-N270/L325 Panel PC The recovery tool menu appears. ( Step 7: F igure B-25) Figure B-25: Recovery Tool Menu Create a factory default image. Follow described in Section Step 8: Step 2 Step 12 B .2.5 to create a factory default image.

  • Page 138: Figure B-26: Recovery Tool Main Menu

    AFL2-W15A-N270/L325 Panel PC Figure B-26: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section B .2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 139: Factory Restore

    AFL2-W15A-N270/L325 Panel PC B.4.1 Factory Restore To restore the factory default image, please follow the steps below. Type <1> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears and starts to restore the factory default. A Step 2: factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 140: Backup System

    AFL2-W15A-N270/L325 Panel PC B.4.2 Backup System To backup the system, please follow the steps below. Type <2> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears and starts to backup the system. A Step 2: backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 141: Restore Your Last Backup

    AFL2-W15A-N270/L325 Panel PC B.4.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Type <3> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears and starts to restore the last backup Step 2: image (iei_user.GHO).

  • Page 142: Manual

    AFL2-W15A-N270/L325 Panel PC B.4.4 Manual To restore the last system backup, please follow the steps below. Type <4> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears. Use the Ghost program to backup or Step 2: recover the system manually.

  • Page 143: Other Information

    AFL2-W15A-N270/L325 Panel PC B.5 Other Information B.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 144 AFL2-W15A-N270/L325 Panel PC When the following window appears, press <S> to select “Specify Additional Step 5: Device”. In the following window, select a SATA controller mode used in the system. Then Step 6: press <Enter>. The user can now start using the SATA HDD.

  • Page 145: System Memory Requirement

    AFL2-W15A-N270/L325 Panel PC After pressing <Enter>, the system will get into the recovery tool setup menu. Step 7: Continue to follow the setup procedure from in Section Step 4 B .2.2 Create Partitions to finish the whole setup process. S t e p 7 : B.5.2 System Memory Requirement...

  • Page 146: Cbios Options

    AFL2-W15A-N270/L325 Panel PC Appendix BIOS Options Page 134...
  • Page 147 AFL2-W15A-N270/L325 Panel PC Below is a list of BIOS configuration options in the BIOS chapter. 　 System Overview .........................55 　 System Time [xx:xx:xx] .......................56 　 System Date [xx/xx/xx] ......................56 　 OnChip SATA Channel [Enabled] ..................58 　 OnChip SATA Type [Native IDE]..................58 　...
  • Page 148 AFL2-W15A-N270/L325 Panel PC 　 RTC Resume [Disabled] ......................72 　 Remote Access [Disabled]....................73 　 Serial Port Number [COM1]....................74 　 Base Address, IRQ [2F8h,3]....................74 　 Serial Port Mode [115200 8,n,1]..................74 　 Flow Control [None]......................75 　 Redirection After BIOS POST [Always] ................75 　...
  • Page 149 AFL2-W15A-N270/L325 Panel PC 　 Internal Graphics Mode [UMA] ...................93 　 UMA Buffer Size [Auto] .......................94 　 Flat Panel Type........................94 　 Current Jumper Setting.......................94 　 HD Audio Azalia Device [Auto] ...................95 　 Save Changes and Exit .......................96 　 Discard Changes and Exit....................96 　...

  • Page 150: D Expansion Module Dimensions

    AFL2-W15A-N270/L325 Panel PC Appendix Expansion Module Dimensions Page 138...

  • Page 151: Typea Module Dimensions ( For Slot 1 And Slot 2)

    AFL2-W15A-N270/L325 Panel PC D.1 Type A Module Dimensions (for Slot 1 and Slot 2) The dimensions of Type A module are listed below. Figure 4-34: Type A Module Dimensions (for Slot 1 and Slot 2) Page 139...

  • Page 152: Typeb Module Dimensions ( For Slot 3)

    AFL2-W15A-N270/L325 Panel PC D.2 Type B Module Dimensions (for Slot 3) The dimensions of Type B module are listed below. Figure 4-35: Type B Module Dimensions (for Slot 3) Page 140...

  • Page 153: E Terminology

    AFL2-W15A-N270/L325 Panel PC Appendix Terminology Page 141...
  • Page 154 AFL2-W15A-N270/L325 Panel PC Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® AC ’97 in 1997. Advanced Configuration and Power Interface (ACPI) is an OS-directed ACPI configuration, power management, and thermal management interface. Advanced Host Controller Interface (AHCI) is a SATA Host controller AHCI register-level interface.
  • Page 155 AFL2-W15A-N270/L325 Panel PC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. Dual Inline Memory Modules are a type of RAM that offer a 64-bit data DIMM bus and have separate electrical contacts on each side of the module.
  • Page 156 AFL2-W15A-N270/L325 Panel PC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. Low-voltage differential signaling (LVDS) is a dual-wire, high-speed LVDS differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 157: F Watchdog Timer

    AFL2-W15A-N270/L325 Panel PC Appendix Watchdog Timer Page 145...
  • Page 158 AFL2-W15A-N270/L325 Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 159: Example Program

    AFL2-W15A-N270/L325 Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 160: G Hazardous Materials Disclosure

    AFL2-W15A-N270/L325 Panel PC Appendix Hazardous Materials Disclosure Page 148...

  • Page 161: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    AFL2-W15A-N270/L325 Panel PC G.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 162 AFL2-W15A-N270/L325 Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 163 AFL2-W15A-N270/L325 Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

  • Page 164: H International Standards Compliance

    AFL2-W15A-N270/L325 Panel PC Appendix International Standards Compliance Page 152...

  • Page 165: Fcc

    AFL2-W15A-N270/L325 Panel PC H.1 EN 60601-1, EN 60601-2 The LCD monitor complies with the EN 60601-1 and EN 60601-2 of related European standards. H.2 FCC We hereby declare that the equipment specified above conforms to the technical standards as specified in the FCC Rules.

Table of Contents
