INSTALL LEVELING LEGS

1.
Prepare dryer for leveling legs
To avoid damaging floor, use a large flat piece of cardboard from
dryer carton; place under entire back edge of dryer. Firmly grasp
dryer body (not console panel) and gently lay dryer down on
cardboard.
2.
Screw in leveling legs
Using a wrench and tape measure, screw legs into leg holes until
bottom of foot is approximately 1/2" (13 mm) (to match height of 3.6
cu. ft. capacity washer) or 1½" (38 mm) (to match height of 3.8 cu. ft.
capacity washer) from bottom of dryer.
Now stand the dryer on its legs. Slide the dryer until it is close to its
final location. Leave enough room for electrical connection and to
connect the exhaust vent.

ELECTRICAL CONNECTION

Power Supply Cord
Electrical Connection Options
1.
Choose electrical connection type
Power supply cord 4-wire receptacle
(NEMA Type 14-30R):
Go to "Power Supply Cord Connection."
Power supply cord 3-wire receptacle
(NEMA Type 10-30R):
Go to "Power Supply Cord Connection."
4-wire direct connection:
Go to "Direct Wire Connection."
3-wire direct connection:
Go to "Direct Wire Connection."
NOTE:
If local codes do not permit connection of a cabinet-
ground conductor to neutral wire, go to "Optional 3-wire
connection." This connection may be used with either a power
supply cord or a direct wire connection.
7
