3.6 SUPPLEMENTAL FLIGHT DATA

OUTSIDE AIR TEMPERATURE BOX

The outside air temperature (OAT) is displayed in °C.
On the AUX System Setup Page of the MFD OAT can be
configured to display °F instead of °C (refer to the Multi
Function Display Pilot' s Guide).
Figure 3.6.1 Outside Air Temperature Box

SYSTEM TIME BOX

The System Time Box displays the local time. Time and
date is obtained from the satellites and cannot be changed.
The pilot may select the desired time format and offset.
There are 3 time formats available: Local 12 hr, Local 24 hr
and Coordinated Universal Time (UTC). The Time Offset
(Time Zone) represents the number of hours plus or minus
UTC (refer to the Multi Function Display Pilot' s Guide).
Figure 3.6.2 System Time Box
190-00387-02 Rev. A

TRAFFIC ANNUNCIATION

(TIS) or Traffic Advisory System (TAS) traffic on the Inset
Map (PFD) and the Navigation Map Page (MFD). When
a traffic advisory is detected, the following automatically
occurs:
Garmin G1000 PFD Pilot's Guide for Cessna Nav III
SUPPLEMENTAL FLIGHT DATA
The G1000 system displays Traffic Information Service
• The Inset Map is enabled and displays the traffic.
• A single "TRAFFIC" voice message is heard.
• A flashing "TRAFFIC" annunciation appears to the
top left of the Attitude indicator. This alert flashes
(black text on yellow background) for 5 seconds
and remains displayed until no TAs are detected
in the area.
NOTE: If a second TA appears or if the TAs
displayed decrease and then increase, a new
audio alert is heard and a new visual alert is
displayed.
NOTE: Refer to theAppendix for detailed informa-
tion on the Traffic Information Service (TIS).
NOTE: Refer to the Multi Function Display
Optional Interface Addendum for detailed infor-
mation on the Traffic Advisory System (TAS).
Figure 3.6.3 Traffic Annunciation
3-27
