SRa5P and SRa Dual Receivers
Jointed Whip Antennas
The AMJ antenna is a general purpose design for any
Lectrosonics receiver or transmitter with a standard
SMA connector. The hinged joint pivots in both direc-
tions for positioning the whip at any desired angle.
Lay uncut antenna on this template and cut to length for the desired frequency block
Trim the end of the color cap and slide the remaining sleeve over the whip - OR - Glue color cap onto the end
BLOCK FREQUENCY
RANGE
470 470.100 - 495.600
486.400 - 511.900
19
20 512.000 - 537.500
537.600 - 563.100
21
563.200 - 588.700
22
588.800 - 614.300
23
614.400 - 639.900
24
640.000 - 665.500
25
665.600 - 691.100
26
14
AMJ KIT CUTTING TEMPLATE
Whip Length
*Cut end of cap off
and slide over whip
Note: Check the scale of your printout. This line should be 6.00 inches long (152.4 mm).
CAP/SLEEVE
COLOR
Black w/ Label
Black w/ Label
Black w/ Label
Brown w/ Label
Red w/ Label
Orange w/ Label
Yellow w/ Label
Green w/ Label
Blue w/ Label
Frequency Blocks
ANTENNA
WHIP LENGTH
5.56" 141.2 mm
5.27" 133.9 mm
4.93" 125.2 mm
4.71" 119.6 mm
4.48" 113.8 mm
108.5 mm
4.27"
4.07" 103.4 mm
3.87" 98.3 mm
3.68" 93.5 mm
*Color cap
The hinged joint pivots in both
