ILDV Series Direct Vent Gas Fireplace Insert

Installation and Operating Instructions

Models: 30ILDVNV, 30ILDVPV
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
•
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
•
WHAT TO DO IF YOU SMELL GAS
– Do not try to light any appliance.
– Do not touch any electrical switch; do
not use any phone in your building.
– Leave the building immediately.
– Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
– If you cannot reach your gas supplier,
call the fire department.
•
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult
a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an aftermarket,*
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is for use only with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer.
0511
ILDV cover
DANGER
9/08
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this
appliance and shall be installed.
INSTALLER: Leave this manual with the appliance.
DANGER
CONSUMER: Retain this manual for
future reference.
CERTIFIED
S
B
AFETY
ARRIER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
20306755 11/14 Rev. 1
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitré avant d'y toucher.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30ILDVNV and is the answer not in the manual?

Questions and answers

Related Manuals for Vermont Castings 30ILDVNV

Summary of Contents for Vermont Castings 30ILDVNV

  • Page 1: Installation And Operating Instructions

    ILDV Series Direct Vent Gas Fireplace Insert Installation and Operating Instructions Models: 30ILDVNV, 30ILDVPV CERTIFIED WARNING: AFETY ARRIER FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death or property damage. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    30ILDV Series Gas Fireplace Insert CONTENTS Thank you and congratulations on your purchase of a Vermont Castings Group Gas Fireplace Insert PLEASE READ THE INSTALLATION AND OPERATION INSTRUCTIONS BEFORE USING THE APPLIANCE! IMPORTANT: Read all instructions and warnings carefully before starting installation.

  • Page 3: Important Safety Information

    30ILDV Series Gas Fireplace Insert IMPORTANT SAFETY INFORMATION INSTALLER OWNER Please leave these instructions with the appliance. Please retain these instructions for future reference. WARNING • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. •...

  • Page 4: Code Approval

    30ILDV Series Gas Fireplace Insert IMPORTANT SAFETY INFORMATION 14. Do not use any solid fuels (wood, coal, paper, card- IMPORTANT: board, etc.) in this fireplace. Use only the gas type PLEASE READ THE FOLLOWING indicated on rating plate. CAREFULLY 15. This appliance, when installed, must be electrically It is not unusual for gas fireplaces to give off some grounded in accordance with local codes or in the odor the first time it is burned.

  • Page 5: Product Features Product Specifications

    • This appliance is mobile home approved. Fuel BTU/h Model BTU/h size • The appliance must be properly connected to a venting 30ILDVNV Nat. 30,000 20,500 system. 30ILDVPV 30,000 23,000 • The appliance is not approved for closet or recessed installations.

  • Page 6: Insert Dimensions

    30ILDV Series Gas Fireplace Insert INSERT DIMENSIONS INSERT DIMENSIONS Figure 2 ILDV Fireplace Insert Dimensions 0511 REF. ILDV dims 30ILDV 9/08 ⁄ " (641 MM) ⁄ " (411 MM) ⁄ " (372 MM) ⁄ " (714 MM) ⁄ " (527 MM) ⁄...

  • Page 7: Installation Information

    30ILDV Series Gas Fireplace Insert GENERAL INSTALLATION INFORMATION BEFORE YOU START INSERT APPLICATIONS Read this homeowner manual thoroughly and follow all Before installing the gas fireplace insert, consider the instructions carefully. Inspect all contents for shipping functioning needs of the fireplace. Confirm the size of the damage and immediately inform your dealer if any damage fireplace cavity, the design of the chimney, and the avail- is found.

  • Page 8: Clearances

    30ILDV Series Gas Fireplace Insert CLEARANCES INSERT CLEARANCES WARNING No combustibles (ie: drapes, doors) may be within, or swing within 36" of the front of the insert. The dimensions shown on Pages 8 and 9, Figures 3 and 4, are minimum clearances to maintain when installing this heater.

  • Page 9: Insert Placement

    15¹⁄₈” 30ILDV Series Gas Fireplace Insert CLEARANCES (384 mm) INSERT PLACEMENT WARNING • The insert must be placed within a code-conforming 18” ILDV20 masonry fireplace or a tested and listed zero-clear- • Installer must attach red warning plate to the inside of the (457 mm) ance (UL-127, solid fuel) fireplace.

  • Page 10: Venting Installation

    Unauthorized modification of the venting system. Maximum Height 40' • Installation of any component part not manufactured (12.9 m) Minimum Height 10' or approved by Vermont Castings Group. (3 m) • Installation other than permitted by these instruc- tions. WARNING This insert must be vented to the outside.

  • Page 11: Altitude Considerations

    VENTING INSTALLATION 30ILDV Series Gas Fireplace Insert ALTITUDE CONSIDERATIONS This heater has been tested at altitudes ranging from sea level to 4,500 feet (1,370 m). In this testing, heater with standard orifice burns correctly with just an air shutter adjustment. If you need to resize orifice for use at high altitude, contact your dealer.

  • Page 12: Venting Configurations

    30ILDV Series Gas Fireplace Insert VENTING INSTALLATION VENTING CONFIGURATIONS Termination Kits (Refer to Page 12) Exhaust Inlet 3" (75 mm) Exhaust UL 1777 Gas Liner 3" (75 mm) Inlet Recommended block-off plate (noncombustible metal). Prevents odors from chimney entering room. UL 127 Solid Fuel Z.C Fire- FP1924...

  • Page 13: Manifold Removal And Installation

    VENTING INSTALLATION 30ILDV Series Gas Fireplace Insert INTAKE MANIFOLD VENT INSTALLATION 4. Feed exhaust flex through hole on top of insert and attach to manifold with hose clamp (not provided) or other approved Before insert is placed back into fireplace opening, attach intake methods (check local codes).

  • Page 14: Insert Installation

    30ILDV Series Gas Fireplace Insert INSERT INSTALLATION CHECK GAS TYPE Use proper gas type for the insert you are installing. If you have conflicting gas type, do not install insert. See dealer 100 gal. (min. External where you purchased the insert for proper insert according Propane/LP Regual- to your gas type.
  • Page 15 30ILDV Series Gas Fireplace Insert INSERT INSTALLATION A manual shut-off valve is factory installed upstream WARNING of the appliance. Union tee and plugged 1/8" NPT pressure tapping point should be installed upstream Only persons licensed to work with gas piping may make of the appliance.

  • Page 16: Check Gas Pressure

    30ILDV Series Gas Fireplace Insert INSERT INSTALLATION CHECKING GAS PRESSURE ELECTRICAL WIRING 1. Check gas type. The gas supply must be the same as This insert will work without any electrical supply. Elec- stated on the appliance’s rating decal. If the gas supply tricity is only needed to operate blower.

  • Page 17: Remote Wall Mounted Switch

    INSERT INSTALLATION 30ILDV Series Gas Fireplace Insert REMOTE WALL MOUNTED SWITCH A remote wall switch and up to fifteen (15) feet of 18 Ga. wire may be used with this appliance. Attach the wall switch in a junction box at the desired location on the wall. Figure 14.

  • Page 18: Glass Frame Removal

    30ILDV Series Gas Fireplace Insert INSERT INSTALLATION GLASS FRAME REMOVAL DANGER NOTE: If the safety barrier is in place, you must first remove it before you remove the glass frame. To remove the barrier, simply lift up and pull out until the tabs are clear HOT GLASS WILL of their corresponding slots on the firebox.

  • Page 19: Log Placement

    INSERT INSTALLATION 30ILDV Series Gas Fireplace Insert LOG PLACEMENT WARNING Before you begin - This unit is supplied with six (6) ceramic fiber logs. Do not handle these logs with your bare hands. The positioning of the logs is critical to the safe and Always wear gloves to prevent skin irritation from ceramic clean operation of this heater.
  • Page 20 30ILDV Series Gas Fireplace Insert INSERT INSTALLATION 3. Align the two pin holes on Log #6 onto the burner. Figure 6. Position log #3 so that the bottom right end is resting on the pad on log #2 and the left end is resting on the flat spot on log #1.
  • Page 21 INSERT INSTALLATION 30ILDV Series Gas Fireplace Insert INSTALL SURROUND 1. Remove glass door assembly. Page 18, Figure 16 2. Align cast or beveled surround holes with insert and attach with screws provided. 3. Re-attach glass door assembly. 4. Attach filigree to face by gently pushing into place. Insert Facing Figure 24 -...

  • Page 22: Operating Instructions

    30ILDV Series Gas Fireplace Insert OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly.
  • Page 23 OPERATING INSTRUCTIONS 30ILDV Series Gas Fireplace Insert LIGHTING PILOT FOR THE FIRST TIME APPROVED LEAK TESTING METHOD WARNING You may check for gas leaks with the following methods only: If using a soap and water solution to test for leaks, DO NOT spray solution onto control body.

  • Page 24: Lighting Burner

    30ILDV Series Gas Fireplace Insert OPERATING INSTRUCTIONS LIGHTING BURNER MAIN BURNER SWITCH The “ON/OFF” switch for the main burner can be found on the right side of insert surround. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”...

  • Page 25: Adjusting Blower Speed

    OPERATING INSTRUCTIONS 30ILDV Series Gas Fireplace Insert ADJUSTING BLOWER SPEED ADJUST THE AIR SHUTTER The internal blower helps transfer heat from heater into room. The venturi of the burner is equipped with an air shutter. It will not turn on until heater is up to temperature (approxi- The opening of the venturi has been set at 1/4"...

  • Page 26: Final Installation

    30ILDV Series Gas Fireplace Insert FINAL INSTALLATION SAFETY BARRIER INSTALLATION DANGER CERTIFIED AFETY ARRIER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS NOTE: A barrier designed to reduce the risk of burns from UNTIL COOLED. the hot viewing glass is provided with this appliance and shall be installed for the protection of children and other NEVER ALLOW CHILDREN at risk individuals.

  • Page 27: Blower Replacement

    30ILDV Series Gas Fireplace Insert FINAL INSTALLATION BLOWER REPLACEMENT Turn off the unit and allow to cool completely. Turn off gas at shut-off and disconnect all electricity to unit. 1. Remove the decorative filigree by gently pulling it out. 2. Rotate the cam on the glass toward the center. 3.

  • Page 28: Blower Parts

    30ILDV Series Gas Fireplace Insert FINAL INSTALLATION BLOWER PARTS LIST: Description Qty. 20ILDV 30ILDV 40ILDV Blower 53D2196 56D2196 56D2196 Parts not shown Disc Bracket 39D0098 39D0098 39D0098 Blower Snap Disc 26D2870 26D2870 26D2870 Speed Control 26D0746 26D0746 26D0746 Wire Assembly 34" 83D0521 83D0521 83D0521...

  • Page 29: Cleaning And Maintenance

    30ILDV Series Gas Fireplace Insert CLEANING and MAINTENANCE You should clean the glass after the first two weeks of use. CLEANING AND MAINTENANCE After that, you should clean the glass no more than two or Make sure the gas valve knob is in the “OFF” position. three times a season.

  • Page 30: Firebox Cleaning

    30ILDV Series Gas Fireplace Insert CLEANING and MAINTENANCE FIREBOX CLEANING WARNING • Allow logs to cool completely before cleaning. Logs reach high temperatures. • Make sure clearances to combustibles leave enough room for maintenance and service. • Carefully reassemble and reseal insert properly after any cleaning or servicing.

  • Page 31: Yearly Service Procedure

    30ILDV Series Gas Fireplace Insert CLEANING AND MAINTENANCE YEARLY SERVICE PROCEDURE 4. Clean burner and burner ports. Figure 35 5. Replace log set and rock wool per instructions on Pages Failure to inspect and maintain heater may lead to im- 19-21.

  • Page 32: Troubleshooting

    30ILDV Series Gas Fireplace Insert TROUBLESHOOTING OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Piezo ignitor will not light 1. Defective ignitor 1. Check connections to ignitor. Replace ignitor if ignitor the pilot after repeated connections are good, but there is no spark. pressing of piezo ignitor.

  • Page 33: Replacement Parts

    30ILDV Series Gas Fireplace Insert REPLACEMENT PARTS 12/13 0511 ILDV parts 9/08 20306755...
  • Page 34 30ILDV Series Gas Fireplace Insert REPLACEMENT PARTS REF. DESCRIPTION QTY. 30ILDVNV 30ILDVPV LOG #1 83D1047 83D1047 LOG #2 83D1049 83D1049 LOG #3 83D1045 83D1045 LOG #4 83D1048 83D1048 LOG #5 83D1050 83D1050 LOG #6 83D1046 83D1046 BURNER ASSEMBLY 83D1267K 83D1267K...

  • Page 35: Optional Accessories

    30ILDV Series Gas Fireplace Insert REPLACEMENT PARTS OPTIONAL ACCESSORIES REF. DESCRIPTION 30ILDV Hood Top - Black Texture CF30BT Hood Top - Iron Age CF30IA Assembly Louver - Black Texture LF30BT Assembly Louver - Iron Age LF30IA Floral Filigree - Black Texture FF30BT Floral Filigree - Iron Age FF30IA...
  • Page 36 30ILDV Series Gas Fireplace Insert This page intentionally left blank. 20306755...
  • Page 37 30ILDV Series Gas Fireplace Insert This page intentionally left blank. 20306755...

  • Page 38: For Massachusetts Residents Only

    MASSACHUSETTS RESIDENTS ONLY Please read and follow these special requirements NOTE REGARDING VENTED PRODUCTS monoxide detector as required in accordance with the above This product must be installed by a licensed plumber or gas fitter provisions shall comply with NFPA 720 and be ANSI/UL 2034 when installed within the Commonwealth of Massachusetts.

  • Page 39: Warranty

    Ceramic Fiber Logs. BASIC WARRANTY Vermont Castings Group warrants the components and materials in your gas appliance to be free from manu- facturing and material defects for a period of two years from date of installation. After installation, if any of the...

  • Page 40: Efficiencies

    Based on CSA P.4.1-09 EFFICIENCY RATINGS ENERGUIDE RATINGS D.O.E. FIREPLACE EFFICIENCY Steady State (%) (AFUE MODEL PERCENTAGE Fan-OFF Fan-ON PERCENTAGE) 30ILDVNV 71.9 76.5 77.5 65.9 30ILDVPV 83.7 88.6 89.6 68.5 Recherchez dans la brochure les caractéristique de rendement énergétique de foyer au gaz Énerguide...

This manual is also suitable for:

30ildvpv
