IDV Series Direct Vent Gas Fireplace Insert
Installation and Operating Instructions
Models: 380IDVNVSB & 380IDVPVSB
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
•
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
•
WHAT TO DO IF YOU SMELL GAS
– Do not try to light any appliance.
– Do not touch any electrical switch; do
not use any phone in your building.
– Leave the building immediately.
– Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
– If you cannot reach your gas supplier,
call the fire department.
•
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult
a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an aftermarket,*
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is for use only with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer.
570215
380IDV cover
DANGER
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this
appliance and shall be installed.
INSTALLER: Leave this manual with the appliance.
DANGER
CONSUMER: Retain this manual for
future reference.
CERTIFIED
S
B
AFETY
ARRIER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
20306756 12/14 Rev. 1
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitré avant d'y toucher.
Advertisement
Table of Contents
Related Manuals for Vermont Castings 380IDVNVSB
Summary of Contents for Vermont Castings 380IDVNVSB
-
Page 1: Installation And Operating Instructions
IDV Series Direct Vent Gas Fireplace Insert Installation and Operating Instructions Models: 380IDVNVSB & 380IDVPVSB CERTIFIED AFETY ARRIER WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death or property damage. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 2: Table Of Contents
380IDV Fireplace Insert CONTENTS Thank you and congratulations on your purchase of a Vermont Castings Group Fireplace Insert. PLEASE READ THE INSTALLATION AND OPERATION INSTRUCTIONS BEFORE USING THE APPLIANCE! IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION 380IDV Fireplace Insert INSTALLER OWNER Please leave these instructions with the appliance. Please retain these instructions for future reference. WARNING • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. •... -
Page 4: Code Approval
380IDV Fireplace Insert IMPORTANT SAFETY INFORMATION 12. Do not use this insert to cook food or burn paper or IMPORTANT: other objects. PLEASE READ THE FOLLOWING CAREFULLY 13. Never place anything on top of insert. It is normal for fireplaces fabricated of steel to 14. -
Page 5: Pre-Installation Information
PRE-INSTALLATION INFORMATION 380IDV Fireplace Insert PRODUCT SPECIFICATIONS • This appliance has been certified for use with either natural or propane gas. Refer to the appropriate data plates. • This appliance is not for use with solid fuels. • The appliance is approved for bedroom or bedsit- ting room installations. -
Page 6: Insert Dimensions
380IDV Fireplace Insert PRE-INSTALLATION INFORMATION INSERT DIMENSIONS 27⁵⁄₈” (702 mm) 17⁷⁄₁₆” (443 mm) 4⁴⁄₂” 10³⁄₈” (114 mm) (264 mm) 15⁹⁄₁₆” (395 mm) 8²³⁄₃₂” (221 mm) 29¹⁄₂” (749 mm) 30³⁄₁₆” (767 mm) 22³⁄₄” 22³⁄₄” (578 mm) 22³⁄₄” 20³⁄₄” (578 mm) (578 mm) (527 mm) 21⁵⁄₈”... -
Page 7: Before You Start
PRE-INSTALLATION INFORMATION 380IDV Fireplace Insert BEFORE YOU START INSERT APPLICATIONS Before installing the gas fireplace insert, consider the Read this homeowner manual thoroughly and follow all functioning needs of the fireplace. Confirm the size of the instructions carefully. Inspect all contents for shipping fireplace cavity, the design of the chimney, and the avail- damage and immediately inform your dealer if any damage ability of the gas supply and electricity for the insert fan. -
Page 8: Clearances
380IDV Fireplace Insert PRE-INSTALLATION INFORMATION MINIMUM FIREPLACE SIZE/CLEARANCES TO COMBUSTIBLES The dimensions shown on Pages 8 and 9, Figures 4 and 5, are minimum clearances to maintain when installing this heater. Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. -
Page 9: Insert Placement
PRE-INSTALLATION INFORMATION 380IDV Fireplace Insert INSERT PLACEMENT • The insert must be placed within a code-conforming masonry fireplace or a tested and listed zero-clear- ance (UL-127, solid fuel) fireplace. Repair any fireplace damage prior to installation. • Because the insert uses a circulation blower, clean the fireplace, smoke shelf and chimney before installing. -
Page 10: Zero-Clearance Requirements
380IDV Fireplace Insert PRE-INSTALLATION INFORMATION ZERO-CLEARANCE (METAL) FIREPLACE REQUIREMENTS • The damper and grate must be removed. Insulation • The smoke shelf, internal baffles, screen, refractory and metal or glass doors may be removed (if applicable). • Do not remove or alter the insulation or any structured rigid frame members (metal sides, floor, door frames, Shelf face of the fireplace, etc.). -
Page 11: Venting Installation
Height • Unauthorized modification of the venting system. 10' (3 m) • Installation of any component part not manufactured or approved by Vermont Castings Group. • Installation other than permitted by these instruc- tions. Maximum 12" (305 mm) Offset at... -
Page 12: Altitude Considerations
380IDV Fireplace Insert VENTING INSTALLATION ALTITUDE CONSIDERATIONS Failure to adjust air shutter properly may This heater has been tested at altitudes ranging from sea level to 4,500 feet (1,370 m). In this testing, heater with lead to improper combustion which can standard orifice burns correctly with just an air shutter create a safety hazard. -
Page 13: Vent Configurations
VENTING INSTALLATION 380IDV Fireplace Insert VENT CONFIGURATIONS Termination Kits: HEDV32T812 Inlet Exhaust 3" (76 mm) or 4" (102 mm) Exhaust UL 1777 Gas Liner 3" (75 mm) Inlet Recommended block-off plate (noncombustible metal). Prevents odors from chimney entering room. UL 127 Solid Fuel Z.C Fire- FP2627 FP2627... -
Page 14: Manifold Removal And Installation
380IDV Fireplace Insert VENTING INSTALLATION MANIFOLD REMOVAL AND INSTALLATION The manifold is shipped attached to insert. It may be removed to allow tight installation. Manifold may be loos- Excess ened and rotated for desired Flex pipe location. Vent 1. Remove brick liner and baffle. -
Page 15: Insert Installation
INSERT INSTALLATION 380IDV Fireplace Insert CHECK GAS TYPE Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. 100 gal. (min. External See dealer where you purchased the fireplace for proper Propane/LP Regual- Supply Tank... - Page 16 380IDV Fireplace Insert INSERT INSTALLATION A manual shut-off valve is factory installed Only persons licensed to work with gas upstream of the appliance. Union tee and piping may make the necessary gas con- plugged 1/8" NPT pressure tapping point nections to this appliance. should be installed upstream of the appli- ance.
-
Page 17: Check Gas Pressure
INSERT INSTALLATION 380IDV Fireplace Insert CHECK GAS PRESSURE 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOP! Do not install the appliance. -
Page 18: Electrical Wiring
380IDV Fireplace Insert INSERT INSTALLATION ELECTRICAL WIRING Electrical connections should only be per- This insert will work without any electrical supply. Electricity formed by a qualified, licensed electrician. is only needed to operate blower. Main power must be off when connecting to REMOTE WALL MOUNTED SWITCH main electrical power supply or performing service. -
Page 19: Glass Frame Removal
INSERT INSTALLATION 380IDV Fireplace Insert GLASS FRAME REMOVAL DANGER NOTE: If the safety barrier is in place, you must first remove it before you remove the glass frame. To remove the barrier, simply lift up and pull out until the tabs are clear of their HOT GLASS WILL corresponding slots on the firebox. -
Page 20: Install Logs And Rock Wool
380IDV Fireplace Insert INSERT INSTALLATION INSTALL LOGS AND ROCK WOOL (EMBER The positioning of the logs is critical to MATERIAL) IN FIREBOX the safe and clean operation of this heater. Before you begin - This unit is supplied with seven (7) Sooting and other problems may result if the ceramic fiber logs. - Page 21 INSERT INSTALLATION 380IDV Fireplace Insert 6. Align holes in bottom of right base log #3 with two (2) 9. Place one end of right top log #6 on cutout of right base to the right of rear log. Figure 21 log.
-
Page 22: Surround Installation
380IDV Fireplace Insert INSERT INSTALLATION SURROUND INSTALLATION 3. Install lower door by aligning notches in door with shoul- der bolts installed on bottom of surround. Figure 28 1. Attach the eyebrow canopy to the surround using three (3) screws provided. Figure 26 2. -
Page 23: Install On/Off Switch
INSERT INSTALLATION 380IDV Fireplace Insert INSTALL ON/OFF SWITCH 1. After installing surround, disconnect the on/off switch from wires leading from heater. 2. Insert switch into hole in upper right side of the trim. Figure 30 3. Reattach wires. Figure 30 On/Off Switch - Tape wires to back of surround... -
Page 24: Safety Barrier Installation
380IDV Fireplace Insert INSERT INSTALLATION SAFETY BARRIER INSTALLATION DANGER INSTRUCTIONS CERTIFIED HOT GLASS WILL CAUSE BURNS. AFETY ARRIER DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN NOTE: A barrier designed to reduce the risk of burns TO TOUCH GLASS. from the hot viewing glass is provided with this A barrier designed to reduce the risk of burns from appliance and shall be installed for the protection of... -
Page 25: Operating Instructions
OPERATING INSTRUCTIONS 380IDV Fireplace Insert FOR YOUR SAFETY READ BEFORE LIGHTING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. -
Page 26: Lighting Pilot
380IDV Fireplace Insert OPERATING INSTRUCTIONS LIGHTING PILOT FOR THE FIRST TIME APPROVED LEAK TESTING METHOD You may check for gas leaks with the following If using a soap and water solution to test for leaks, methods only: DO NOT spray solution onto •... -
Page 27: Lighting Burner
OPERATING INSTRUCTIONS 380IDV Fireplace Insert LIGHTING BURNER MAIN BURNER SWITCH The “ON/OFF” switch for the main burner can be found on the right side of insert surround. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”... -
Page 28: Air Shutter Adjustment - Natural Gas Only
380IDV Fireplace Insert OPERATING INSTRUCTIONS ADJUST THE AIR SHUTTER (Natural Gas Only) The venturi of the burner is equipped with an air shutter. The opening of the venturi has been set at 1/4" for Natural Gas and fully open for Propane installation at sea level. The burner on Natural Gas models may be adjusted for high altitude as follows: •... -
Page 29: Cleaning And Maintenance
CLEANING and MAINTENANCE 380IDV Fireplace Insert PILOT AND BURNER FLAMES Make sure the gas valve knob is in the “OFF” position. Wait at least five (5) minutes before start ing maintenance. Visually check pilot and burner flames periodically. Refer VENTING SYSTEM to Figure 34 for typical burner flame. -
Page 30: Firebox Cleaning
380IDV Fireplace Insert CLEANING AND MAINTENANCE FIREBOX CLEANING 1. Carefully remove log set, and embers from combustion chamber. 2. Vacuum burner compartment thoroughly. 3. Vacuum any dust off logs. 4. Remove any lint from main burner and pilot. 5. Carefully replace log set, and embers in their correct positions. -
Page 31: Yearly Service Procedure
380IDV Fireplace Insert CLEANING AND MAINTENANCE YEARLY SERVICE PROCEDURE Failure to inspect and maintain heater may lead to improper combustion and a potentially dangerous situation. A quali- Thermopile fied technician should do the following once a year. 1. Check pilot flame. Flame should touch approximately Thermocouple 3/8"... -
Page 32: Troubleshooting
380IDV Fireplace Insert TROUBLESHOOTING Turn appliance OFF and allow to cool before servicing. Only a qualified service person should service and repair the heater. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Piezo ignitor will not light the 1. -
Page 33: Replacement Parts
REPLACEMENT PARTS 380IDV Fireplace Insert BLOWER PARTS LIST Description Qty. Part No. Blower 20302445 Parts not shown Thermostat Bracket 26D3320 Thermostat 49D0130 Speed Control 26D0746 Wire Harness 41D0203 Label all wires prior to disconnection when FP1945 servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 34: Firebox Components & Accessories
380IDV Fireplace Insert REPLACEMENT PARTS FIREBOX COMPONENTS 570016 IDV parts 20306756... - Page 35 REPLACEMENT PARTS 380IDV Fireplace Insert FIREBOX COMPONENTS 380IDVNV 380IDVPV Item Description Qty. Natural Propane Burner Assembly 57D0022 57D0022 Left Log Support Bracket 57D0076 57D0076 Right Log Support Bracket 57D0078 57D0078 SIT820 Nova Valve 37D0117 37D0118 Injector 57D0209 57D0210 Tube from Valve 57D0111 57D0111 Tube from Venturi...
-
Page 36: For Massachusetts Residents Only
MASSACHUSETTS RESIDENTS ONLY 380IDV Fireplace Insert Please read and follow these special requirements NOTE REGARDING VENTED PRODUCTS 2. Approved Carbon Monoxide Detectors. Each carbon This product must be installed by a licensed plumber or gas fitter monoxide detector as required in accordance with the above when installed within the Commonwealth of Massachusetts. -
Page 37: Warranty
Ceramic Fiber Logs. BASIC WARRANTY Vermont Castings Group warrants the components and materials in your gas appliance to be free from manu- facturing and material defects for a period of two years from date of installation. After installation, if any of the... - Page 38 380IDV Fireplace Insert This page intentionally left blank. 20306756...
