TABLE OF CONTENTS

1

Before driving

2

When driving

Interior features

3

Maintenance and

4

care

When trouble

5

arises

Vehicle specifica-

6

tions

Index

CT200h_OM_OM76067E_(EE)

Information on the hybrid system and adjusting and op-

erating features such as door locks, mirrors, and steer-

ing column

Driving, stopping and safe-driving information

Air conditioning and audio systems, as well as other in-

terior features for a comfortable driving experience

Cleaning and protecting your vehicle, performing do-it-

yourself maintenance, and maintenance information

What to do if the vehicle needs to be towed, gets a flat

tire, or is involved in an accident

Detailed vehicle information

Alphabetical listing of information contained in this

manual

1

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the CT200h and is the answer not in the manual?

Questions and answers

Summary of Contents for Lexus CT200h

Page 1 TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column When driving Driving, stopping and safe-driving information Air conditioning and audio systems, as well as other in- Interior features terior features for a comfortable driving experience Maintenance and...
Page 2: Table Of Contents
• Air conditioning • Rear window and outside rear view mirror defoggers • Windshield wiper de-icer • Climate control • Lexus parking assist monitor 1-4. Adjustable components Before driving (seats, mirrors, steering wheel) Front seats ......98 1-1. Hybrid system Rear seats ......
Page 3 When driving Cruise control ..... 250 Dynamic radar cruise control ......255 2-1. Driving procedures Lexus parking assist-sensor 273 Driving the vehicle..... 186 Rear view monitor system.. 282 Power (ignition) switch..198 Driving assist systems ..291 EV drive mode ....204 Hill-start assist control ..
Page 4 TABLE OF CONTENTS Index ® 3-3. Using the Bluetooth audio Interior features system ® Bluetooth audio system ... 388 ® 3-1. Using the air conditioning sys- Using the Bluetooth audio system ......394 ® Operating a Bluetooth and defogger enabled portable player ..399 Automatic air conditioning ®...
Page 5 3-5. Using the interior lights Maintenance and care Interior lights list....445 • Personal/interior light main switch ...... 446 4-1. Maintenance and care • Front personal/interior Cleaning and protecting lights......... 446 the vehicle exterior... 476 • Rear interior light..... 447 Cleaning and protecting the vehicle interior ...
Page 6 TABLE OF CONTENTS Index When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 562 Maintenance data (fuel, oil level, etc.) ..650 If your vehicle needs to be towed ......563 Fuel information....665 If you think something is wrong......
Page 7 CT200h_OM_OM76067E_(EE)
Page 8 Pictorial index Exterior  Moon roof P. 127 Outside rear view Windshield wipers mirrors P. 118 P. 241 Hood P. 492  Headlight cleaner P. 249 Turn signal lights P. 216  Front fog lights Headlights P. 235 P. 239 Front position lights P.
Page 9 Rear window defogger P. 329 Turn signal lights P. 216 Rear window wip- Fuel filler door  P. 131 P. 247 Back door P. 93 Side doors P. 89 Rear fog light (right-hand drive vehicles) P. 239 License plate lights P.
Page 10 Interior Pictorial index (Left-hand drive vehicles) Seat belts SRS driver airbag P. 108 P. 151 Head restraints SRS knee airbags P. 105 P. 151 SRS front passen- P. 151 Rear seats Floor mat P. 100 P. 467 SRS side airbags Front seats P.
Page 11 Anti-glare inside rear view mirror P. 116 Sun visors P. 457  Moon roof switches P. 127  Intrusion sensor cancel switch P. 144 Interior light P. 446 SRS curtain shield airbags P. 151 Vanity mirrors P. 458 Interior lights P.
Page 12 Interior Pictorial index (Left-hand drive vehicles) Inside lock button P. 89  Driving position memory switches P. 102 Window lock switch P. 123 Door lock switch P. 89 Power window switches P. 123 Bottle holder P. 452 CT200h_OM_OM76067E_(EE)
Page 13 Without navigation system Auxiliary boxes P. 453 AUX port/USB port Power outlet P. 359, 370, 382 P. 460 With navigation system TILT switch Remote Touch OPEN CLOSE switch Auxiliary box P. 453 Power outlet AUX port/USB port P. 460  : If equipped : Refer to “Navigation System Owner’s CT200h_OM_OM76067E_(EE)
Page 14 Instrument panel Pictorial index (Left-hand drive vehicles) Gauges and meters Windshield wipers and washer switch P. 219 P. 241  Multi-information display Rear window wiper and washer switch P. 247 P. 229 Clock P. 459 Headlight switch P. 235 Turn signal lever Glove box P.
Page 15  Talk switch P. 418 “DISP” switch P. 231 Audio remote Telephone switch- control switches  P. 384 P. 418 Vehicle-to-vehicle  distance button Horn P. 218 P. 255  Cruise control switch P. 250  Dynamic radar cruise control switch P.
Page 16 (Left-hand drive vehicles)  Manual headlight leveling dial P. 236 P. 249  Windshield wiper de-icer switch P. 330  Lexus parking assist-sensor switch P. 273  Heated steering wheel switch P. 463 Fuel filler door opener P. 131 CT200h_OM_OM76067E_(EE)
Page 17 Without navigation system   Auxiliary box Power outlet P. 453 P. 460 Power (ignition) switch Emergency flasher switch P. 562 P. 198  : If equipped : For vehicles with a navigation system, refer to “Navigation System Owner’s CT200h_OM_OM76067E_(EE)
Page 18 Instrument panel Pictorial index (Left-hand drive vehicles) With navigation system Navigation system Power (ignition) switch Emergency flasher switch P. 562 P. 198 CT200h_OM_OM76067E_(EE)
Page 19 Audio system P. 331 Shift lever Security indicator P. 207 P. 135, 142 P position  switch Seat heater switches P. 465 P. 210 Driving mode select switch P. 209 EV drive mode switch P. 204  : If equipped : Refer to “Navigation System Owner’s Manual”.
Page 20 Interior Pictorial index (Right-hand drive vehicles) SRS driver airbag Seat belts P. 108 P. 151 SRS knee airbags Head restraints P. 151 P. 105 SRS front passen- P. 151 Floor mat Rear seats P. 100 P. 467 Front seats SRS side airbags P.
Page 21 Anti-glare inside rear view mirror P. 116 Sun visors P. 457  Moon roof switches P. 127  Intrusion sensor cancel switch P. 144 Interior light P. 446 SRS curtain shield airbags P. 151 Vanity mirrors P. 458 Interior lights P.
Page 22 Interior Pictorial index (Right-hand drive vehicles) Inside lock button P. 89 Driving position memory  switches P. 102 Window lock switch P. 123 Door lock switch P. 89 Power window switches P. 123 Bottle holder P. 452 CT200h_OM_OM76067E_(EE)
Page 23 Without navigation system Auxiliary boxes P. 453 Power outlet AUX port/USB port P. 460 P. 359, 370, 382 With navigation system Remote Touch TILT switch OPEN CLOSE switch Auxiliary box P. 453 Power outlet AUX port/USB port P. 460  : If equipped : Refer to “Navigation System Owner’s CT200h_OM_OM76067E_(EE)
Page 24 Instrument panel Pictorial index (Right-hand drive vehicles) Headlight switch Gauges and meters P. 235 P. 219 Multi-information display Turn signal lever P. 216 P. 229 Fog light switch P. 239 Windshield wipers and washer switch P. 241 Clock P. 459 Rear window wiper and ...
Page 25  Talk switch P. 418 “DISP” switch P. 231 Audio remote Telephone switch- control switches  P. 384 P. 418 Vehicle-to-vehicle  distance button Horn P. 218 P. 255  Cruise control switch P. 250  Dynamic radar cruise control switch P.
Page 26 (Right-hand drive vehicles)  Manual headlight leveling dial P. 236 P. 249  Windshield wiper de-icer switch P. 330  Lexus parking assist-sensor switch P. 273  Heated steering wheel switch P. 463 Fuel filler door opener P. 131 CT200h_OM_OM76067E_(EE)
Page 27 Without navigation system   Auxiliary box Power outlet P. 453 P. 460 Power (ignition) switch P. 198 Emergency flasher switch P. 562  : If equipped : For vehicles with a navigation system, refer to “Navigation System Owner’s CT200h_OM_OM76067E_(EE)
Page 28 Instrument panel Pictorial index (Right-hand drive vehicles) With navigation system Navigation system Power (ignition) switch P. 198 Emergency flasher switch P. 562 CT200h_OM_OM76067E_(EE)
Page 29 Shift lever P. 207 Audio system P. 331  Seat heater switches P. 465 P position switch P. 210 Security indicator P. 135, 142 EV drive mode switch Driving mode select switch P. 204 P. 209  : If equipped : Refer to “Navigation System Owner’s Manual”.
Page 30: For Your Information
Lexus cannot accept any liability or guarantee spare parts and accessories which are not genuine Lexus products, nor for replacement or installation involving such parts. In addition, damage or performance problems resulting from the use of nongenuine Lexus spare parts or accessories may not be cov- ered under warranty. CT200h_OM_OM76067E_(EE)
Page 31  SRS airbag system  Seat belt pretensioner system Be sure to check with any authorized Lexus dealer or repairer, or another duly qualified and equipped professional for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system.
Page 32 Scrapping of your Lexus The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be...
Page 33 Never resell, hand over or modify the hybrid battery. To prevent accidents, hybrid batteries that have been removed from a disposed vehicle are col- lected through any authorized Lexus dealer or repairer, or another duly qual- ified and equipped professional. Do not dispose of the battery yourself.
Page 34 In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by any authorized Lexus dealer or repairer, or another duly qualified and equipped profes- sional. If the hybrid battery is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 35 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Lexus and its equipment.
Page 36 CT200h_OM_OM76067E_(EE)
Page 37: Before Driving
Before driving 1-1. Hybrid system 1-5. Opening and closing the windows and moon roof Hybrid system features ..38 Power windows....123 Hybrid system precautions....... 43 Moon roof ......127 Energy monitor/consumption screen ....... 49 1-6. Refueling Hybrid vehicle driving tips 54 Opening the fuel tank cap 131 1-2.
Page 38: Hybrid System Hybrid System Features
1-1. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an elec- tric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 39 1-1. Hybrid system  When stopped/during start off The gasoline engine stops* when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped* and the electric motor (traction motor) is used.
Page 40 1-1. Hybrid system  Regenerative braking In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery).  The accelerator pedal is released while driving with the shift position in D or B.
Page 41 30 minutes or 16 km (10 miles). If the hybrid bat- tery becomes fully discharged and you are unable to jump-start the vehi- cle with the 12-volt battery, contact any authorized Lexus dealer or repairer, or another duly qualified and equipped professional.
Page 42 Cooling fan sounds may be heard from the air intake vent on the side of rear right seatback.  Maintenance, repair, recycling, and disposal Contact any authorized Lexus dealer or repairer, or another duly qualified and equipped professional regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. ...
Page 43: Hybrid System Precautions
1-1. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it contains a high volt- age system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle.
Page 44 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact any autho- rized Lexus dealer or repairer, or another duly qualified and equipped professional. CT200h_OM_OM76067E_(EE)
Page 45 The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact any authorized Lexus dealer or repairer, or another duly qualified and equipped professional.
Page 46 1-1. Hybrid system  Electromagnetic waves  High voltage parts and cables on the hybrid vehicles incorporate electro- magnetic shielding, and therefore emit approximately the same amount of electromagnetic waves as conventional gasoline powered vehicles or home electronic appliances.  Your vehicle may cause sound interference in some third party-produced radio parts.
Page 47 1-1. Hybrid system CAUTION  Road accident cautions If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury:  Stop the vehicle in a safe place to prevent subsequent accidents. While depressing the brake pedal, apply the parking brake and shift the shift position to P to stop the hybrid system.
Page 48 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the bat- tery may be damaged. Have the vehicle inspected by any authorized Lexus dealer or repairer, or another duly qualified and equipped profes- sional. CT200h_OM_OM76067E_(EE)
Page 49: Energy Monitor/Consumption Screen
1-1. Hybrid system Energy monitor/consumption screen You can view the status of your hybrid system on the multi-informa- tion display and the navigation system screen. Navigation system screen (if equipped) Multi-information display Remote Touch* “MENU” button Remote Touch knob “ENTER” button : For use of the Remote Touch, refer to “Naviga- tion System Owner’s Man-...
Page 50 1-1. Hybrid system STEP Select “Car” on the “Menu” screen. If the “Energy monitor” screen displayed, select “Energy”. Multi-information display Press the “DISP” switch on the steering wheel several times to select the energy monitor dis- play. CT200h_OM_OM76067E_(EE)
Page 51 1-1. Hybrid system Multi-information Navigation system screen display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine When the vehicle is charging the...
Page 52 1-1. Hybrid system Multi-information Navigation system screen display Full Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual condi- tions. Consumption (vehicles with a navigation system) Press the “MENU” button on the Remote Touch and select “Car” on the “Menu”...
Page 53 1-1. Hybrid system Past record (vehicles with a navigation system) Press the “MENU” button on the Remote Touch and select “Car” on the “Menu” screen. If the “Past record” screen does not appear, select “Fuel consumption” on the “Energy monitor” screen or “Past record” on the “Consump- tion”...
Page 54: Hybrid Vehicle Driving Tips
1-1. Hybrid system Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points:  Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 55 1-1. Hybrid system  Air conditioning Use the air conditioning only when necessary. Doing so can help control excessive gasoline consumption. In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well.
Page 56: 1-2. Key Information
1-2. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system equipped) (P. 62) • Operating the push-button start system (if equipped) (P. 79) • Operating wireless remote control function (P.
Page 57 1-2. Key information Using the mechanical key To take out the mechanical key: Electronic keys: Slide release lever and take the key out. Card key: Press the lock release button and take the key out. The mechanical key can only be inserted in one direction, as the key only has grooves on one side.
Page 58 If the battery cover is not installed and the battery falls out or if the bat- tery was removed because the key got wet, reinstall the battery with the positive terminal facing the Lexus emblem.  The card key is not waterproof. CT200h_OM_OM76067E_(EE)
Page 59 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at any authorized Lexus dealer or repairer, or another duly qualified and equipped profes- sional using the key number plate. (P. 629) ...
Page 60 In case of a smart entry & start system malfunction or other key-related problems Take your vehicle with all the electronic keys provided with your vehicle, including the card key, to any authorized Lexus dealer or repairer, or another duly qualified and equipped professional. ...
Page 61 (To remove the battery cover, lightly grasp and pull it.) If the bat- tery is corroded, have any authorized Lexus dealer or repairer, or another duly qualified and equipped professional replace the battery.
Page 62: Opening, Closing And Locking The Doors Smart Entry & Start System
1-3. Opening, closing and locking the doors  Smart entry & start system The following operations can be performed simply by carrying the electronic key (including the card key) on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (P.
Page 63 1-3. Opening, closing and locking the doors Unlocking and locking the doors Front door handles Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
Page 64 1-3. Opening, closing and locking the doors Back door Press the back door opener switch to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors.
Page 65 1-3. Opening, closing and locking the doors Antenna location and effective range  Antenna location Antennas outside the cabin Antennas inside the cabin Antenna inside the luggage compartment Antenna outside the luggage compartment CT200h_OM_OM76067E_(EE)
