If the direction is displayed several sec-
onds after adjustment, the calibration is
finished.
CAUTION
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
WWW.MANUALS.WS
13C011
CALIBRATING THE COMPASS (circling
calibration)
"C" appears on the display in case the
circling calibration is required due to the
drastic change of the magnetic field. To
rectify this, follow the calibration proce-
dure.
'01 L/C U (L/O 0008)
13C012
Drive the vehicle slowly (at 8km/h (5mph)
or lower) in a circle until the direction is
displayed. If there is not enough space to
drive in a circle, drive around the block
until the direction is displayed.
After driving in 1 to 3 circles in the above
method, calibration is complete with the
direction shown on the display.
If calibration cannot be performed because
of the magnetized vehicle, etc., take your
vehicle to Toyota dealer.
91
