Operation

Setting functions

Input select
Language
DDC-CI
OSDH position
OSDV position
OSDTimeout
Factory recall

Displaying information

22
Downloaded from ManualMonitor.com Manuals
Call up the Setup settings window
Select the input signal
This function is used to select the input signal (VGA, DVI or HDMI).
This function is used to select the input signal (VGA, DVI, HDMI, CVBS,
S-Video or YPbPr).
This is on condition that the display adapter supports this function.
Set the language for the OSD menu
With this function you select the language for the OSD menu.
The default setting is English.
Activate/deactivate the DDC-CI
On = The DDC-CI function is activated (default setting)
Off = The DDC-CI function is deactivated
Set the horizontal position of the OSD menu
With this function you move the OSD menu to the left or to the right.
Set the vertical position of the OSD menu
With this function you move the OSD menu up or down.
Set the display duration of the OSD menu
With this function you select a value from 10 to 120 seconds.
If the set time expires without a setting being made, the OSD menu is
automatically faded out.
Activate the factory settings
With this function all settings are reset to the factory settings without
prompting for confirmation.
The function is executed with the
Processing message appears.
Call the Information setting window
With this function the model designation, serial number, resolution, H/V
frequency, input signal and polarity of the synchronisation signal are
displayed.
button. The Auto
SELECT / MENU
A26361-K1253-Z220-1-7619, edition 2
