Your LCD screen...

has a whole range of useful features and functions, e.g.:
TFT display (Thin Film Transistor; active matrix)
minimal space requirements thanks to slim casing
optimum ergonomic characteristics (totally distortion-free, excellent picture
definition and colour purity right into the corners)
high degree of brightness and good contrast
high resolution (1680 x 1050)
presentation of up to 16.7 million colours (in conjunction with an appropriate display adapter)
automatic scanning of horizontal frequencies from 30 to 82 kHz and refresh rates
(vertical frequencies) from 56 to 76 Hz (absolutely flicker-free)
digital screen controller with microprocessor for storing 28 different display modes
freely adjustable colour alignment for matching the screen colours to the
colours of various input and output devices
convenient operation via integrated OSD (On-Screen-display) menu
VESA-DDC compatibility
VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) –
Mounting device for swivel arm and wall bracket
Plug&Play capability
digital video inputs (DVI and HDMI) with HDCP
power management for reducing power consumption when the computer is not in use
Compliance with the recommendations according to TCO '03
the monitor fulfills all GS ("Geprüfte Sicherheit", Certified Security) requirements.
This operating manual contains important information you require to start up and run your LCD monitor.
When putting the monitor into operation for the first time, the screen display should be
optimally adapted to the display adapter used and adjusted in accordance with your
needs (see chapter

Target group

You don't need to be an "expert" to perform the operations described here. However, please observe
the safety information given in the operating instructions for the computer and in this manual.
In the event of any problems occurring, please contact your sales outlet or our Service Desk.

Further information

Details of how you set the resolution and refresh rate are provided in the documentation
for your display adapter and the associated driver software.
For ergonomic reasons, we recommend a screen resolution of 1680 x 1050 pixels.
Because of the technology used (active matrix) an LCD monitor provides a totally
flicker-free picture even with a refresh rate of 60 Hz.
A26361-K1253-Z220-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
"Changing the monitor settings", Page

Your LCD screen...

17.
