Table Of Contents

Table of Contents

Quick Links

Download this manual

Reference Manual

Industrial Mainboard

GMB-AQ67010

CONTENTS

Introduction .................................................................. 4

Safety Precautions ...................................................... 9

Product Nomenclature and Function ............... 15

BIOS Setup .................................................................. 41

Appendix ...................................................................... 69

List of Optional Products ....................................... 78

Customer Support and Inquiry ............................ 80

Table of Contents

Need help?

Do you have a question about the GMB-AQ67010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Contec GMB-AQ67010

Page 1 Reference Manual Industrial Mainboard GMB-AQ67010 CONTENTS Introduction ..............4 Safety Precautions ............9 Product Nomenclature and Function ....15 BIOS Setup ..............41 Appendix ..............69 List of Optional Products ........78 Customer Support and Inquiry ......80...
Page 2: Table Of Contents
Table of Contents Introduction ..............4 1. Related Manuals ..............................5 2. About the Product ..............................6 3. Features ..................................7 4. Supported OS ................................8 Safety Precautions ............9 1. Safety Information ............................... 10 2. Handling Precautions ............................11 1. FCC PART 15 Class A Notice ........................13 3.
Page 3 Table of Contents 2.Using Setup ................................ 39 3.Getting Help ............................... 39 4.In Case of Problems ............................39 5.A Final Note About Setup ..........................39 2. Main Menu ................................40 1. Setup Items ..............................41 3.Main ..................................... 42 4.Advanced ................................... 43 1.
Page 4: Introduction
Table of Contents Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. - 4 -...
Page 5: Related Manuals
— — Safety Precautions GMB-AQ67010 Quick Guide 1. Related Manuals The manuals related to the product are listed below. Read them as necessary along with this document. ◆ Must Read the Following Manuals Name Purpose Contents How to get Read this when operating...
Page 6: About The Product
Intel® Core™ Processors that leverage advanced 7nm process technology with an energy-efficient architecture. The GMB-AQ67010 boasts four DDR5 U-DIMM sockets, accommodating an impressive 128GB of memory. Designed to meet the demands of factory automation applications, it comes in intel® NEXG SKU configurations.
Page 7: Features
— — Safety Precautions GMB-AQ67010 Quick Guide 3. Features ⚫ Intel® 12th / 13th/ 14th Gen. processor Alder Lake-S / Raptor Lake-S / Raptor Lake –S Refresh Platform ⚫ 4 x DDR5-4400 U-DIMM, up to 128GB (non-ECC support) ⚫ Multi display supported: Display port, HDMI and VGA ⚫...
Page 8: Supported Os
— — Safety Precautions GMB-AQ67010 Quick Guide 4. Supported OS Windows 11 IoT Enterprise 2024 LTSC (64-bit) - 8 -...
Page 9: Safety Precautions
— — Safety Precautions GMB-AQ67010 Quick Guide Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. - 9 -...
Page 10: Safety Information
— — Safety Precautions GMB-AQ67010 Quick Guide 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.
Page 11: Handling Precautions
— — Safety Precautions GMB-AQ67010 Quick Guide 2. Handling Precautions WARNING Always check that the power supply is turned off before connecting or disconnecting power ⚫ cables. Do not modify the product. ⚫ Always turn off the power before inserting or removing circuit boards or cables.
Page 12 To prevent corruption of files, always shutdown the OS before turning off this product. ⚫ CONTEC reserves the right to refuse to service a product modified by the user. ⚫ In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ⚫...
Page 13: Fcc Part 15 Class A Notice
— — Safety Precautions GMB-AQ67010 Quick Guide 1. FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 14: Security Warning
— — Safety Precautions GMB-AQ67010 Quick Guide 3. Security Warning When connecting to the network, be aware of security-related problems. See the examples of Security measures below and set up the product properly along with the network devices. 1. Information security risks Unauthorized access from the outside through a network could cause the system halt, data ⚫...
Page 15: Product Nomenclature And Function
Table of Contents Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. - 15 -...
Page 16: Product Overview
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 1. Product Overview connectors of the product are shown in the picture below. - 16 -...
Page 17: Top View
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide ◆ Top View - 17 -...
Page 18 — — Product Nomenclature and Function GMB-AQ67010 Quick Guide Ref. Connector Function AUDIO1 Mic-in, Line-Out 3.5Ømm Audio Jack LAN USB3 2.5GbE RJ-45 Connector + Dual USB3.2 Gen2 Type A LAN USB2 2.5GbE RJ-45 Connector + Dual USB3.2 Gen3 Type A LAN USB1 GbE RJ-45 Connector + Dual USB3.2 Gen4 Type A...
Page 19 — — Product Nomenclature and Function GMB-AQ67010 Quick Guide PCI2 5V 32-bit PCI slot (Idsel=AD29) PCIE4 PCIe 5.0 x8 slot PCI1 5V 32-bit PCI slot (Idsel=AD28) PCIE3 PCIe 4.0 x4 slot PCIE2 PCIe 4.0 x4 slot PCIE1 PCIe 5.0 x16 or PCIe 5.0 x8 (Signal share with PCIE4) slot M2_1 M.2 Slot (M Key, PCIe 4.0 x4 signal, 2280)
Page 20: Jumper List
GMB-AQ67010 Quick Guide 2. Jumper List For users to customize GMB-AQ67010 features. In the following sections, short means covering a jumper cap over jumper pins; Open or N/C (not connected) means removing a jumper cap from jumper pins. Users can refer to below Top view picture and tables for jumper positions, functions, and signal description.
Page 21: Connector List
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 3. Connector List 1. ATXCONN2: 8-Pin ATX 12V Power Connector PIN No. Signal Description PIN No. Signal Description +12V +12V +12V +12V 2. JPWR1: 24-Pin ATX Power Connector PIN No. Signal Description PIN No.
Page 22: Cpufan1, Sysfan1: Cpu/ System Fan Connectors
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 5V_SB 3. CPUFAN1, SYSFAN1: CPU/ System Fan Connectors PIN No. Signal Description +12V Sense Control 4. F_JAUD1: Front Audio Connector - 22 -...
Page 23: Jusb1: Usb 3.2 Gen 1 Connector
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide PIN No. Signal Description PIN No. Signal Description MIC_L MIC_R LINE_OUT_R MIC_JD No pin LINE_OUT_L LINE_OUT_JD 5. JUSB1: USB 3.2 Gen 1 Connector PIN No. Signal Description PIN No. Signal Description USB_D+ USB 3.2 RX-...
Page 24: Usb2_1/2/3: Usb 2.0 Connector
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 6. USB2_1/2/3: USB 2.0 Connector USB2_1 USB2_2 USB2_3 PIN No. Signal Description PIN No. Signal Description GND- USB1_D+ USB2_D+ USB2_D- USB2_D- 5V_USB 5V_USB 7. F_PANEL1: Front Panel Connector PIN No. Signal Description PIN No.
Page 25: Gpio1: Gpi Connector
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 8. GPIO1: GPI Connector PIN No. Signal Description PIN No. Signal Description GPI01 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 GPIO8 5V_DUAL *More detail please Reference GPIO sample code chapter 9.JAT1: I2C Connector This connector is provided for users to connect I²C (Inter-Integrated Circuit) interface...
Page 26: Com2~6: Serial Port Connectors
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 10.COM2~6: Serial Port Connectors PIN No. Signal Description PIN No. Signal Description DCD# DSR# RTS# SOUT CTS# No Pin 11.SATA1~3 : SATA Connector Stack PIN No. Signal Description SATA_TXP SATA_TXN SATA_RXN...
Page 27: M2_1: M.2 Slot (M Key, Pcie 4.0 X4, 2280)
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 12.M2_1: M.2 Slot (M Key, PCIe 4.0 x4, 2280) 13.SPI1: SPI Connector PIN No. Signal Description PIN No. Signal Description 3V3_SPI SPIROM_CS# SPIROM_SCK SPIROM_SO SPIROM_SI No Pin (Key) - 27 -...
Page 28: 14: Bat1: Rtc Battery Holder
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 14: BAT1: RTC Battery Holder Note: Replace the CMOS battery with a lithium CMOS ⚫ battery of the same type (CR2032) is must. After you replace the CMOS battery, you must ⚫...
Page 29: Cn1: Ext. Battery Connector
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 15.CN1: Ext. Battery Connector PIN No. Signal Description PIN No. Signal Description GND(-) 3Vdc(+) 16.EXT_1: Debug Port PIN No. Signal Description 3V3_DUAL ESPI_RESET ESPI_CS0# ESPI_IO0 ESPI_IO1 ESPI_IO2 ESPI_IO3 ESPI_CLK - 29 -...
Page 30: Rear I/O Panel
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 17.Rear I/O Panel DP1: DisplayPort DisplayPort is a digital display interface standard. This connector is used to connect a monitor with DisplayPort inputs. Signal Description PIN No. Signal Description DP_TXP0（+） DP_TXN0（-）...
Page 31 — — Product Nomenclature and Function GMB-AQ67010 Quick Guide HDMI1: HDMI Connector The High-Definition Multimedia Interface (HDMI™) is an all-digital audio/ video interface capable of transmitting uncompressed streams. Signal Description PIN No. Signal Description HDMI1 DATA2(+) HDMI1 DATA2(-) HDMI1 DATA1(+)
Page 32 — — Product Nomenclature and Function GMB-AQ67010 Quick Guide The VGA port supports monitors and other VGA interface devices. PIN No. Signal Description PIN No. Signal Description PIN No. Signal Description VGA_RED VGA_GREEN DDC_DAT VGA_BLUE VGA_HSYNC +5V_VGA VGA_VSYNC DDC_CLK LANUSB1: GbE RJ-45 LAN Jacks The standard single RJ45 LAN jack is provided for connection to the Local Area Network (LAN).
Page 33 — — Product Nomenclature and Function GMB-AQ67010 Quick Guide LANUSB1~3: USB 3.2 Gen 2 Ports : USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, delivers high-speed data transfer for various devices, such as storage devices, hard drives, video cameras, etc.
Page 34: Installation
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 4 .Installation 1. CPU Installation 1. Make sure PC and all other peripheral devices are shut down. 2. Disconnect all power cords and cables. 3. Open the load plate then remove the plastic cap as below picture 1 and 2 showed.
Page 35 — — Product Nomenclature and Function GMB-AQ67010 Quick Guide 4. Be careful to put CPU straight down into the socket. (Make sure socket keys and CPU pin1 are put at right location marked in below picture 3.) Press down on the socket cover and pull the lever down to secure the socket cover as picture 4 and picture 5 (Make sure CPU is inserted into socket properly before close socket cover.)
Page 36: Motherboard Installation
— — Product Nomenclature and Function GMB-AQ67010 Quick Guide 2. Motherboard Installation Some components are very close to the mounting holes. Please take precautionary measure to avoid damaging these components when installing the motherboard. 3. Memory Installation 1. The DDR5 U-DIMM memory sockets are divided into A and B two channels, each has two sockets showed as below.
Page 37: Bios Setup
Table of Contents BIOS Setup This section describes AMI’s Setup program built into the FLASH ROM BIOS. - 37 -...
Page 38: Introduction
— — BIOS Setup GMB-AQ67010 Quick Guide 1. Introduction The BIOS setup program allows users to modify the basic system configuration. In this following chapter will describe how to access the BIOS setup program and the configuration options that may be changed.
Page 39: Using Setup
— — BIOS Setup GMB-AQ67010 Quick Guide 2.Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard.
Page 40: Main Menu
— — BIOS Setup GMB-AQ67010 Quick Guide 2. Main Menu Once you enter the Aptio Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and exit choices. Use the arrow keys to select among the items and press <Enter>...
Page 41: Setup Items
— — BIOS Setup GMB-AQ67010 Quick Guide 1. Setup Items The selectable tabs are as follows. Main Record some basic hardware configurations in your computer and set the system clock. Advanced configure your CPU and other system devices for basic operation through the following sub-menus.
Page 42: Main
— — BIOS Setup GMB-AQ67010 Quick Guide 3.Main View the basic system structure. The following items are displayed. Indication item of the main menu Item Indication Example Explanation Project Version AQ67C 1.01 x64 Displays the BIOS version. Build Data and Time 09/04/2024 Displays the BIOS version.
Page 43: Advanced
— — BIOS Setup GMB-AQ67010 Quick Guide 4.Advanced This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. - 43 -...
Page 44: Power & Performance
— — BIOS Setup GMB-AQ67010 Quick Guide 1. Power & Performance CPU- Power Management Control Max Battery Select the performance state Max Non-Turbo performance Boot performance mode that the BIOS will set staring Turbo performance from reset vector. Allows more then two frequency...
Page 45: Pch-Fw Configuration
— — BIOS Setup GMB-AQ67010 Quick Guide 2. PCH-FW Configuration PCH-FW Configuration Item Options Description When Disabled Me will be put into ME Temporarily Enabled ME State Disabled Disabled Mode. Item Options Description Enable /Disable Intel® manageability features. Note: This option disables/enables manageability features...
Page 46 — — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description As defined in FIT Allow switching AMT support from Integrated LAN to Dynamic Lan Switch Integrated LAN Discrete LAN Discrete LAN Local platform Erase Configuration Perform Platform Erase Disable / (The item fixed in disable)
Page 47: Trusted Computing
— — BIOS Setup GMB-AQ67010 Quick Guide 3. Trusted Computing Trusted Computing Item Options Description Enables or Disables BIOS support for security device. Enable Security Device Support O.S. will not show Security Device. TCG EFI protocol Disable and INT1A interface will not be available.
Page 48 — — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description 1_ 2 Select to tell O.S to support PPI Spec version 1.2 or 1.3 Physical Presence Spec Version 1 .3 . Note: some HCK tests might not support 1.3. TPM 2.0 Interface Type TPM 1.2 will restrict support to TPM 1.2 devices,...
Page 49: Acpi Settings
— — BIOS Setup GMB-AQ67010 Quick Guide 4. ACPI Settings ACPI Settings Item Options Description Enabled Enable ACPI Auto Configuration Do not change this setting. Disabled Enables or Disables System ability to Hibernate Enabled Enable Hibernation (OS/S4 Sleep State). This option may not be Disabled effective with some operating systems.
Page 50: Nct6126D Super Io Configuration
— — BIOS Setup GMB-AQ67010 Quick Guide 5. NCT6126D Super IO Configuration Super IO Configuration Item Options Description Serial Port 1 Configuration IO=3F8h; IRQ=4 Refer to Serial Port 1 IO=2F8h; IRQ=3 Serial Port 2 Configuration Refer to Serial Port 2 IO=3E8h;...
Page 51 — — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description Enabled Enable or Disable Terminator of the RS422/485 Terminator Disabled RS422/485 Mode selects 485 Enabled RS485 Auto Flow Control Enable or Disable RS485 auto flow control Disabled High RS485 RTS inverse High or Low when RS485 receives data.
Page 52 — — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description Enabled Serial Port Enable or Disable Serial Port (COM). Disabled Auto IO=228h; IRQ=7; Select an optimal setting for Super IO IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Change Setting device IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=220h; IRQ=3,4,5,6,7,9,10,11,12; IO=228h; IRQ=3,4,5,6,7,9,10,11,12;...
Page 53: Hardware Monitor
— — BIOS Setup GMB-AQ67010 Quick Guide 6. Hardware Monitor View hardware monitor information such as the CPU temperature. Smart Fan Function Fan1 Setting (SYS_FAN) & Fan2 Setting (CPU_FAN) ⚫ Item Options Description Manual mode Fan1 Mode Thermal Cruise Mode...
Page 54 — — BIOS Setup GMB-AQ67010 Quick Guide Speed Cruise ⚫ SMART FAN IV ⚫ - 54 -...
Page 55: Usb Configuration
— — BIOS Setup GMB-AQ67010 Quick Guide 7. USB Configuration USB Configuration Item Options Description Enables Legacy USB Support. AUTO option: Disables legacy support if no USB device Enabled Legacy USB Support Are connected. Disabled Disable option: will keep USB devices available Auto only for EFI applications.
Page 56: Network Stack Configuration
— — BIOS Setup GMB-AQ67010 Quick Guide 8. Network stack Configuration Network Stack: Default Disabled When Network Stack Setting [Enable] the configuration item as below » IPV4 PXE Support Enables or disables IPv4 PXE boot support. » IPV6 PXE Support Enables or disables Ipv6 PXE Support.
Page 57: Chipset
— — BIOS Setup GMB-AQ67010 Quick Guide 5. Chipset 1. System Agent (SA) Configuration System Agent (SA) Configuration Graphic Configuration Item Options Description Auto IGFX Select which of IGFX/PEG/PCI graphics device Primary Display should be primary display or select SG for...
Page 58 — — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description 32M/F7 128M Select DVMT 5.0 total Graphics memory size the DVMT Total Gfx Mem 256M internal used By the internal Graphics Device Enabled PAVP Enable Enable / Disable RAVP Disabled VMD setup menu ∙...
Page 59: Pch-Io Configuration
— — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description Enable/Disable to VDM controller Disabled Enable VDM controller. Enabled 2. PCH-IO Configuration SATA Configuration Item Options Description Enabled SATA Configuration(S) Enable/Disable SATA Device. Disabled SATA Mode Selection Determines how SATA controller(s) operate.
Page 60 — — BIOS Setup GMB-AQ67010 Quick Guide Item Options Description Control Detection of the HD-Audio device. Enabled HD Audio Disabled = HDA will be unconditionally disabled Disabled Enabled = HAD will be unconditionally enabled. HD Audio BUS Controller 72708086 Select HD Audio BUS Controller Subsystem Id Subsystem Id 300010EC ..
Page 61: Security
— — BIOS Setup GMB-AQ67010 Quick Guide 6. Security Secure Boot Secure Boot ⚫ Item Options Description Secure Boot feature is Active if Secure Boot is Enabled, Enabled Secure Boot Platform Key(PK) is enrolled, and the System is in Disabled User mode.
Page 62: Boot
— — BIOS Setup GMB-AQ67010 Quick Guide 7. Boot The system setting default as figure list ⚫ Boot Item Options Description Number of seconds to wait for setup activation key. Setup Prompt Timeout 65535(0xFFFF) means indefinite waiting. Bootup NumLock State...
Page 63: Save And Exit
— — BIOS Setup GMB-AQ67010 Quick Guide 8. Save and Exit Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes.
Page 64: Firmware Update
— — BIOS Setup GMB-AQ67010 Quick Guide 9. Firmware Update Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. - 64 -...
Page 65: Mebx
— — BIOS Setup GMB-AQ67010 Quick Guide 8.MEBx Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. - 65 -...
Page 66: Appendix
Table of Contents Appendix This section lists the specifications and components suggestion, block diagram, driver installation, and mechanical drawing. - 66 -...
Page 67: System Reference
— — Appendix GMB-AQ67010 Quick Guide 1. System Reference 1. Specifications Model Name GMB-AQ67010 Intel ® / 13 / 14 Gen Core™ Processors CPU in LGA1700 socket up to 125W TDP ( CPU cooler backplane size: 78x78/75x75mm) Chipset Intel® Q670E...
Page 68 — — Appendix GMB-AQ67010 Quick Guide 0~60℃ Recommended options: RGD3328EAAD-002 5000RPM ( Part No.43951940) 0~50℃ Recommended options: FAN JYCML118ATC-0 4500RPM (Part No.43951890) CPU Selection Guide NEX-Intel Core processors(14th Gen) / Raptor lake -S Refresh CPU Part No. Cores(P+E) Threads Processor Base Power * (L3)cache Intel®...
Page 69 — — Appendix GMB-AQ67010 Quick Guide NEX-Intel Core processors(12th Gen) / Alder lake -S CPU Part No. Cores(P+E) Threads Processor Base Power * (L3)cache Intel® Core i9-12900E* 16 (8+16) 30 MB Intel® Core i9-12900TE 16 (8+16) 30 MB Intel® Core i7-12700E...
Page 70: List Of Optional Products
Table of Contents List of Optional Products This section lists optional items that can be used along with the product. - 70 -...
Page 71: Optional Product
List of Optional Products GMB-AQ67010 Quick Guide 1. Optional Product Optional product items are as follows, please acquire them as required. Accessory Parts Name Product Code Description Visit the CONTEC website for the latest optional products. https://www.contec.com/ Download - 71 -...
Page 72: Customer Support And Inquiry
Table of Contents Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. - 72 -...
Page 73: Services
— — Customer Support and Inquiry GMB-AQ67010 Quick Guide 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services.
Page 74: Revision History
No part of this document may be copied or reproduced in any form by any means without ⚫ prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained ⚫ in this document.
Page 75 CONTEC CO., LTD. 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. GMB-AQ67010 Quick Guide NA10400 (LXEA081) [10052024]...
