  • Page 1 U s e r ’ s M a n u a l SG300BT Wireless Handheld Linear Imager Bar code Scanner...

  • Page 2: Table Of Contents

    PRODUCT SAFETY ......2 Safety & Caution ......2 FCC Warning ......3 CHAPTER 2 GENERAL DESCRIPTION ......4 Use of the SG300BT ....... 4 CHAPTER 3 INSTALLATION OF THE SG300BT ....5 SG300BT Unpacking ......5 SG300BT Cradle Installation ....6 SG300BT Setup Bluetooth Communication ..
  • Page 3 4.3.1 Abort Configuration ...... 14 4.3.2 Recall ........14 4.3.3 Version Information ...... 14 Cradle Interface Selection ....14 4.4.1 Interface ........ 14 Bluetooth Scanner Setup ....15 4.5.1 Preface ........15 4.5.2 Scanner Mode ......15 4.5.3 *** Batch Mode (“***” means “Quick Setting Label”, The function can be executed directly by scanning barcode instead of doing the general process.) .........
  • Page 4 4.8.3 Parity ........21 4.8.4 Handshaking ....... 22 Keyboard Wedge Mode Parameters ..23 4.9.1 Terminal Type ......23 4.9.2 Country/Language ......24 4.9.3 Upper/Lower Case ......25 4.9.4 Capslock Detection ......25 4.9.5 Character by ALT Method ....26 4.9.6 Select Numerical Pad ......
  • Page 5 4.14.4 Setup Code Length ......38 4.15 Interleave 2 of 5 Parameters ..... 40 4.15.1 Check Digit Transmission ....40 4.15.2 Setup Number of Character ....40 4.15.3 Brazilian Banking Code ....40 4.15.4 Setup Code Length ......41 4.16 Industrial 2 of 5 Parameters ..... 42 4.16.1 Reading Type ......
  • Page 6 4.22.2 Check Digit Transmission ....55 4.22.3 Setup Code Length ......55 4.23 GS1 Databar Omnidirectional Parameters .. 57 4.23.1 Check Digit Transmission ....57 4.23.2 Application ID ......57 4.23.3 Symbology ID ......57 4.24 GS1 Databar Limited Parameters ..58 4.24.1 Check Digit Transmission ....
  • Page 7 APPENDIXES ..........72 Decimal Value Table ...... 72 ASCII Value Table ......73 ASCII Table ......74 Function Key Table ....... 80 Technical Specifications ....81 Scan Map ......... 83 LED Indicator Status ..... 84 Test Symbologies ......85 Quick Configuration ......87...

  • Page 8: Introduction

    SG300BT is a gun-type barcode scanner which is designed specifically for retail market. To the brand new series of SG300BT, we add on more user-friendly functions with detachable interface cable that makes it easier to be operated by the customers.

  • Page 9: Product Safety

    (d) The equipment can’t work well. (e) The equipment has any obvious damage, making the SG300BT working abnormally. 13. Don’t store the SG300BT at the temperature lower than -20°C (-4°F) or higher than +70°C (158°F) to avoid any damage.

  • Page 10: Table Of Contents

    1.2 FCC Warning This equipment complies with the requirements in Part 15 of FCC. Any operation must comply with the conditions below: (a) The equipment will not cause any severe interference. (b) The equipment can avoid any interference from environment. Statement: This product is classified as B class product.

  • Page 11: General Description

    LED indicator will light on after scan successfully. The programming of the SG300BT is very easy. You can setup the SG300BT by scan all necessary programming codes that meet applications. Thanks to the powerful decoding...

  • Page 12: Installation Of The Sg300Bt

    INSTALLATION OF THE SG300BT 3.1 SG300BT Unpacking Unpack the SG300BT as follows: 1. Take the SG300BT and its accessories out of the box. 2. Remove the packing material. 3. Check the packing list to make sure you have received all of the items ordered.

  • Page 13: Sg300Bt Cradle Installation

    3.2 SG300BT Cradle Installation To setup your SG300BT scanner with Bluetooth technology, please follow the steps. 1. Connect the supplied communication cable at the bottom side of the cradle. 2. Connect the other side of the communication cable to the right connector of your POS or HOST system.

  • Page 14: Sg300Bt Setup Bluetooth Communication

    This address code is located on the bottom side of the cradle. The pairing of a SG300BT scanner to a cradle is one to one. Only one SG300BT scanner can be paired to a cradle at any point in time.
  • Page 15 SG300BT scanner can’t be paired with that cradle until the original connection is interrupted. If you pair a second SG300BT scanner to an in-use cradle, the cradle’s connection to the first SG300BT scanner will be interrupted and the connection will be re-established...

  • Page 16: Setup Spp Slave Mode Communication

    3.3.5 The SG300BT scanner enters sleep mode to save battery energy, when the SG300BT scanner is used for 1 minute or 10 minute time. During sleep mode all the functions and connection will be halted. After press the red trigger button the scanner will wake up and reconnect the communication with the cradle or Bluetooth device.

  • Page 17: Batch Mode

    This batch mode is enabled when you have scanned “Batch Mode on”. The scanned data is stored in the memory of the SG300BT scanner instead of being transmitted. You can delete the last scanned bar code data by scanning “Delete Last Data”...

  • Page 18: Configuring The Sg300Bt

    SG300BT scanner settings with programming labels. Changing Scanner Settings with 4.1.1 Programming Codes You can setup your SG300BT by scan all necessary programming codes that meet applications. In order to change the scanner settings please follow the sequence below: 1. Power up the scanner.

  • Page 19: Programming Flow Chart

    By scanning “Set All Default” label, the settings will go back to the factory default settings. Programming Flow Chart 4.1.2 Start Recall Set all Default Configuration Parameters Interface Selection Communication Parameters Bar codes Parameters Misc. Parameters etc. Abort Configuration Configuration Save Parameters...

  • Page 20: Set All Default Parameter

    4.2 Set All Default Parameter By scanning “Set All Default” label, the all parameters will go back to the factory default settings for scanner and cradle. After reading a valid programming code the scanner will give a three high beep and the Green LED indicator will light on.

  • Page 21: Abort Configuration

    Abort Configuration 4.3.1 Terminate current programming status. Recall 4.3.2 Replace the current parameters by the parameters saved last time Version Information 4.3.3 Display the Scanner version information and date code Display the Cradle version information and date code Display the Scanner Bluetooth MAC Address Display the Cradle Bluetooth MAC Address...

  • Page 22: Preface

    USB Virtual Comport Mode Bluetooth Scanner Setup Preface 4.5.1 How to configure the Bluetooth function: The barcode programming feature gives the possibility to change the SG300BT scanner settings with programming labels. Scanner Mode 4.5.2 BT Parameter set default SPP Master Mode...

  • Page 23: Batch Mode ("***" Means "Quick Setting Label", The Function Can Be Executed Directly By Scanning Barcode Instead Of Doing The General Process.)

    *** Batch Mode 4.5.3 (“***” means “Quick Setting Label”, The function can be executed directly by scanning barcode instead of doing the general process.) Batch Mode ON <Batch Mode OFF> ***Batch Data Output ***Batch Data Clear ***Delete Last Data Out of Range 4.5.4 <Out of Range Enable>...

  • Page 24: Reading Mode

    Sleep Mode On 10 minute <Sleep Mode OFF> 4.6 Scanner Operation Reading Mode 4.6.1 <Good Read OFF> Trigger ON/OFF Continuous/Trigger OFF Flash Auto Sence Beeper Option 4.6.2 <High> Medium...

  • Page 25: Reading Level

    Reading Level 4.6.3 Bar Equals High <Bar Equals Low> Accuracy Scan 4.6.4 < Require 1 good decoding for a good scan> Require 2 consecutive decoding of the same bar code data for a good scan Require 3 consecutive decoding of the same bar code data for a good scan Require 4 consecutive decoding of...
  • Page 26 <Fast> Slow Same Code Delay Reading Interval 4.6.6 Following code sequences represent the length of time before a barcode can be rescanned at continuous and flash reading mode. The value can be defined from 1-50 and they represent 100ms to 5 seconds in 100ms interval. Default value is 3(0.3 second).

  • Page 27: Reverse Output Characters

    Reverse Output Characters 4.6.7 Example: 012345 543210 Enable <Disable> 4.7 RS232 Mode Parameters Baud Rate 4.7.1 1200 2400 4800 <9600> 19200 38400 57600...

  • Page 28: Data/Stop Bits

    Data/Stop Bits 4.7.2 The number of data/stop bits transmitted for each character 7 Data Bits < 8 Data Bits > < 1 Stop Bits > 2 Stop Bits Parity 4.7.3 A Parity bit is an extra data bit used to check data transmission errors.

  • Page 29: Handshaking

    Handshaking 4.7.4 RTS/CTS ON – Output a Request to Send (RTS) signal and wait for a Clear to Send (CTS) signal before transmitting data <RTS/CTS OFF> ACK/NAK ON – After transmitting data, wait for host to send an ACK or a NAK response. If ACK is received, then complete the data transmission.

  • Page 30: Keyboard Wedge Mode Parameters

    4.8 Keyboard Wedge Mode Parameters Terminal Type 4.8.1 <IBM PC/AT,PS/2> - Includes IBM PS/2 and compatible models 50, 55, 60, 80 IBM PC/XT IBM PS/2 25, 30 IBM 5550 IBM 102 Key IBM 122 Key (1) IBM 122 Key (2) NEC 9800 Apple Desktop Bus(ADB)

  • Page 31: Country/Language

    Country/Language 4.8.2 <US English> UK English Italian Spanish French German Swedish Switzerland Hungarian Japanese Belgium...

  • Page 32: Upper/Lower Case

    Portuguese Denmark Netherlands Turkey Upper/Lower Case 4.8.3 <No Change> Enable Lower Case – Transmit all data as lower case Enable Upper Case – Transmit all data as upper case Capslock Detection 4.8.4 Enable <Disable>...

  • Page 33: Character By Alt Method

    Character by ALT Method 4.8.5 ALT Method Enable Send <ALT Method Disable> Select Numerical Pad 4.8.6 Numerical Pad ON <Numerical Pad OFF> Interscan Code Delay 4.8.7 <No Delay> 5 ms 10 ms 25 ms 50 ms...

  • Page 34: Output Characters

    100 ms 200 ms 300 ms 4.9 Output Characters Select Terminator 4.9.1 <CR+LF>– The scanner transmits a carriage return and a line feed after each scan CR Suffix – The scanner transmits a carriage return after each scan LF Suffix – The scanner transmits a line feed after each scan Space STX-ETX –...

  • Page 35: Code Type

    4.10 Code Type Barcode Selection 4.10.1 If “All Bar Code ON” is selected, the scanner could read all types of bar code. If “Disable” is selected for a certain bar code type, the scanner could not read the particular bar code. The symbol of “<>” means default setting.
  • Page 36 <CODE 39 ON> CODE 39 OFF Code32 / Italian Pharmacy ON <Code32 / Italian Pharmacy OFF> <Code 128 ON> Code 128 OFF <Interleave 2 of 5 ON> Interleave 2 of 5 OFF <Codabar/NW7 ON> Codabar/NW7 OFF Industrial 2 of 5 ON <Industrial 2 of 5 OFF>...
  • Page 37 Matrix 2 of 5 ON <Matrix 2 of 5 OFF> CODE 93 ON <CODE 93 OFF> CODE 11 ON <CODE 11 OFF> MSI/PLESSEY ON <MSI/PLESSEY OFF> Telepen ON <Telepen OFF> China Postage ON <China Postage OFF>...

  • Page 38: Upc/Ean/Jan Parameters

    GS1 DataBar Omnidirectional ON <GS1 DataBar Omnidirectional OFF> GS1 DataBar Expanded ON <GS1 DataBar Expanded OFF> GS1 DataBar Limited ON <GS1 DataBar Limited OFF> 4.11 UPC/EAN/JAN Parameters Reading Type 4.11.1 UPC-A=EAN-13 ON Add 0 before UPC-A to make it 13 digits.
  • Page 39 ISSN Enable <ISSN Disable> Decode with Supplement <Auto Discriminate Supplement> Expand UPC-E Enable <Expand UPC-E Disable> EAN8=EAN13 Enable <EAN8=EAN13 Disable> GTIN Format Enable <GTIN Format Disable>...

  • Page 40: Supplemental Setup

    Supplemental Setup 4.11.2 <Not Transmit> 2 Digit Supplemental 5 Digit Supplemental 2 & 5 Digit Supplemental Check Digit Transmission 4.11.3 <UPC-A Check Digit Transmission ON> UPC-A Check Digit Transmission OFF <UPC-E Check Digit Transmission ON> UPC-E Check Digit Transmission OFF <EAN-8 Check Digit Transmission ON>...

  • Page 41: Code 39 Parameters

    <EAN-13 Check Digit Transmission ON> EAN-13 Check Digit Transmission OFF <ISSN Check Digit Transmission ON> ISSN Check Digit Transmission OFF 4.12 Code 39 Parameters Type of Code 4.12.1 <Standard Code 39> Full ASCII Code 39 <Italian Pharmacy/Code 32 Off> Italian Pharmacy/Code 32 ON Check Digit Transmission 4.12.2 <Do Not Calculate Check Digit>...

  • Page 42: Output Start/Stop Character

    Calculate Check Digit and Transmit Calculate Check Digit and Not Transmit Output Start/Stop Character 4.12.3 Enable <Disable> Decode Asterisk 4.12.4 Enable <Disable> Setup Code Length 4.12.5 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired set.
  • Page 43 <Variable> Fixed Length 1 Set Begin Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin...

  • Page 44: Code 128 Parameters

    Decimal Value See Appendix A Minimum Length Complete 4.13 Code 128 Parameters Reading Type 4.13.1 UCC/EAN-128 Enable <UCC/EAN-128 Disable> <Enable ‘]C1’ Code Format> Disable ‘]C1’ Code Format <Enable Code128 Group Separators (GS)> Disable Code128 Group Separators (GS)

  • Page 45: Check Digit Transmission

    Check Digit Transmission 4.13.2 Do Not Calculate Check Digit Calculate Check Digit and Transmit <Calculate Check Digit and Not Transmit> Append FNC2 4.13.3 <OFF> Setup Code Length 4.13.4 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired 2.
  • Page 46 Fixed Length 1 Set Begin Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete...

  • Page 47: Interleave 2 Of 5 Parameters

    4.14 Interleave 2 of 5 Parameters Check Digit Transmission 4.14.1 <Do Not Calculate Check Digit> Calculate Check Digit and Transmit Calculate Check Digit and Not Transmit Setup Number of Character 4.14.2 <Even> Brazilian Banking Code 4.14.3 Enable <Disable>...

  • Page 48: Setup Code Length

    Setup Code Length 4.14.4 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired 2. Go to the Decimal Value Table in Appendix A. Scan programming codes that represent the length to be read.

  • Page 49: Industrial 2 Of 5 Parameters

    Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete 4.15 Industrial 2 of 5 Parameters Reading Type 4.15.1 IATA25 Enable <IATA25 Disable> Check Digit Transmission 4.15.2 <Do Not Calculate Check Digit> Calculate Check Digit and Transmit...

  • Page 50: Setup Code Length

    Calculate Check Digit and Not Transmit Setup Code Length 4.15.3 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired 2. Go to the Decimal Value Table in Appendix A. Scan programming codes that represent the length to be read.

  • Page 51: Matrix 2 Of 5 Parameters

    Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete 4.16 Matrix 2 of 5 Parameters Check Digit Transmission 4.16.1 <Do Not Calculate Check Digit> Calculate Check Digit and Transmit Calculate Check Digit and Not Transmit...

  • Page 52: Setup Code Length

    Setup Code Length 4.16.2 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired 2. Go to the Decimal Value Table in Appendix A. Scan programming codes that represent the length to be read.

  • Page 53: Codabar/Nw7 Parameters

    Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete 4.17 CODABAR/NW7 Parameters Setup Start/Stop Characters upon 4.17.1 Transmission <OFF> Transmission Type of Start/Stop 4.17.2 A/B/C/D <Start> A/B/C/D <Stop>...

  • Page 54: Setup Code Length

    A Start A Stop B Start B Stop C Start C Stop D Start D Stop Setup Code Length 4.17.3 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired 2. Go to the Decimal Value Table in Appendix A. Scan programming codes that represent the length to be read.
  • Page 55 <Variable> Fixed Length 1 Set Begin Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin...

  • Page 56: Code 93 Parameters

    Decimal Value See Appendix A Minimum Length Complete 4.18 Code 93 Parameters Check Digit Transmission 4.18.1 Do Not Calculate Check Digit <Calculate Check 2 Digit and Not Transmit> Setup Code Length 4.18.2 To set the fixed length: (2 sets available) 1.
  • Page 57 Set Begin Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete...

  • Page 58: Code 11 Parameters

    4.19 Code 11 Parameters Check Digit Transmission 4.19.1 <Do Not Calculate Check Digit> Calculate Check 1 Digit and Transmit Calculate Check 1 Digit and Not Transmit Calculate Check 2 Digit and Transmit Calculate Check 2 Digit and Not Transmit Setup Code Length 4.19.2 To set the fixed length: (2 sets available) 1.
  • Page 59 Fixed Length 1 Set Begin Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete...

  • Page 60: Msi/Plessey Code Parameters

    4.20 MSI/Plessey Code Parameters Check Digit Transmission 4.20.1 <Do Not Calculate Check Digit> Calculate Check Digit and Transmit Calculate Check Digit and Not Transmit Setup Code Length 4.20.2 To set the fixed length: (2 sets available) 1. Scan the “Begin” programming code of the desired 2.
  • Page 61 Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete...

  • Page 62: Telepen Parameters

    4.21 Telepen Parameters Type of Code 4.21.1 <Telepen ASCII ON> Telepen Numeric Check Digit Transmission 4.21.2 Do Not Calculate Check Digit Calculate Check Digit and Transmit <Calculate Check Digit and Not Transmit> Setup Code Length 4.21.3 To set the fixed length: (2 sets available) 1.
  • Page 63 <Variable> Fixed Length 1 Set Begin Decimal Value See Appendix A Set Complete Fixed Length 2 Set Begin Decimal Value See Appendix A Set Complete Minimum Length Minimum Length Begin Decimal Value See Appendix A Minimum Length Complete...

  • Page 64: Gs1 Databar Omnidirectional Parameters

    4.22 GS1 Databar Omnidirectional Parameters Check Digit Transmission 4.22.1 <Calculate Check Digit and Transmit> Calculate Check Digit and Not Transmit Application ID 4.22.2 <Transmit Application ID> Add 01 before GS1 Databar Omnidirectional Do Not Transmit Application ID Symbology ID 4.22.3 Transmit Symbology ID Add ]e0 before GS1 Databar Omnidirectional.

  • Page 65: Gs1 Databar Limited Parameters

    4.23 GS1 Databar Limited Parameters Check Digit Transmission 4.23.1 <Calculate Check Digit and Transmit> Calculate Check Digit and Not Transmit Application ID 4.23.2 <Transmit Application ID> Add 01 before GS1 Databar Limited. Don’t Transmit Application ID Symbology ID 4.23.3 Transmit Symbology ID Add ]e0 before GS1 Databar Limited.

  • Page 66: Gs1 Databar Expanded Parameters

    4.24 GS1 Databar Expanded Parameters Symbology ID 4.24.1 Transmit Symbology ID Add ]e0 before GS1 Databar Expanded. <Don’t Transmit Symbology ID>...

  • Page 67: Miscellaneous Parameters

    CHAPTER 5 MISCELLANEOUS PARAMETERS 5.1 Bar Code ID Default Barcode ID 5.1.1 With this function on, a leading character will be added to the output string while scanning code. User may refer to the following table to know what kind of barcode has being scanned.

  • Page 68: User Define Code Id

    Bar Code ID ON <Bar Code ID OFF> Default – Return from User Define to Default User Define Code ID 5.1.2 To set the code ID 1. Scan the symbologies programming code. 2. Go to the ASCII Table in Appendix B. Scan programming codes that represent the desired ID.
  • Page 69 CODE 128 Codabar/NW7 Interleave 2 of 5 Industrial 2 of 5 Matrix 2 of 5 CODE 93 CODE 11 China Postage MSI/PLESSEY Telepen GS1 DataBar Omnidirectional...

  • Page 70: Preamble And Postamble Insertion

    GS1 DataBar Expanded GS1 DataBar Limited 5.2 Preamble and Postamble Insertion Setup Insertion 5.2.1 To set the insertion of the output characters: 1. Scan the programming code of the desired set. 2. Scan the programming code of the desired symbology 3.

  • Page 71: Insertion Set Number

    Code UPC-A 1st Digit Complete Complete End Configuration Save Parameters Insertion Set Number 5.2.2...

  • Page 72: Code Type For Insertion

    Code Type for Insertion 5.2.3 UPC-A UPC-E EAN-13/JAN-13 EAN-8/JAN-8 CODE 39 CODE 128 Codabar/NW7 Interleave 2 of 5...
  • Page 73 Industrial 2 of 5 Matrix 2 of 5 CODE 93 CODE 11 China Postage MSI/PLESSEY Telepen GS1 DataBar Omnidirectional GS1 DataBar Expanded GS1 DataBar Limited All Codes...

  • Page 74: Position To Be Inserted

    None Position to Be Inserted 5.2.4 Decimal Value See Appendix A Complete Characters to Be Inserted 5.2.5 ASCII Table See Appendix B and C Complete 5.3 Character Deletion To setup the deletion of output characters: 1. Scan the programming code of the desired set. 2.
  • Page 75 Repeat the steps 1 – 6 to set additional deletion. Example: Delete first 3 digits Code EAN-13. Start Configuration Code EAN-13 1st Digit – Delete from the 1 digit Complete – Delete 3 digits Complete End Configuration Save Parameters...

  • Page 76: Deletion Set Number

    Deletion Set Number 5.3.1 Code Type for Deletion 5.3.2 UPC-A UPC-E EAN-13/JAN-13 EAN-8/JAN-8...
  • Page 77 CODE 39 CODE 128 Codabar/NW7 Interleave 2 of 5 Industrial 2 of 5 Matrix 2 of 5 CODE 93 CODE 11 China Postage MSI/PLESSEY Telepen...

  • Page 78: Position To Be Deleted

    GS1 DataBar Omnidirectional GS1 DataBar Expanded GS1 DataBar Limited All Codes None Position to Be Deleted 5.3.3 Decimal Value See Appendix A Complete Number of Characters to Be Deleted 5.3.4 Decimal Value See Appendix A Complete...

  • Page 79: Appendixes

    APPENDIXES Decimal Value Table...

  • Page 80: Ascii Value Table

    ASCII Value Table Enter...

  • Page 81: Ascii Table

    ASCII Table NULL...
  • Page 82 SPACE ″ &...
  • Page 83 Comma Minus Period Number Number One Zero < Less Than > Greater Than...
  • Page 84 Letter I Letter O...
  • Page 85 Underscore...
  • Page 86 Vertical Slash...

  • Page 87: Function Key Table

    Function Key Table Insert Delete Home Page Up Page Down Left Right...

  • Page 88: Technical Specifications

    Down Technical Specifications Physical Characteristics: Scanner Scanner Weight Approx. 215g (include batteries) Charger Weight Approx. 135g (include adaptor) Material ABS Plastic Dimension 82.9 mm(L) x 75.0 mm(W) x 171.3 mm(H) Physical Characteristics: Bluetooth Cradle Weight Approx 150 g Material ABS Plastic Connector RJ 45C 10Pins Dimension...
  • Page 89 Electrical Characteristics Scanner: Voltage Battery Li-Ion 3.7V/2600 mAh Charge Time 5.5 hours Reads per Charge 20,000 Times Scanner LED Indicator Good read Green Error / Alarm Bluetooth Communication Blue Power Consumption Power On 400mA Stand by 270mA Operation 290mA Sleep 36mA Cradle: Voltage...

  • Page 90: Scan Map

    Environmental Operating Temp. 0°C to 50°C (32°F to 122°F) Storage Temp. -20°C to 70°C (-4°F to 158°F) Relative Humidity 20 to 95% non-condensing Ambient Light 10,000 LUX max @ Direct sun Light Immunity Ingress Protection Sealed with IP42 rating protection Scanner Drop Functions normally after repeated Specification...

  • Page 91: Led Indicator Status

    G. LED Indicator Status Scanner Indicators Status Buzzer Green Light and Power On Buzzer Be-Be-Be* 2 loops Simultaneously Battery No Power Red Blink 3 times Bi-Bi-Bi Battery Low Power Red Blink 1 time Be per 20 seconds Alarm Battery Very Low Bi-Bi-Bi-Bi per 10 Red Blink 4 times Power Alarm...

  • Page 92: Test Symbologies

    Cradle Indicators Status Buzzer Power On Red Light Continue Transmitted Green Blink 1 Time Succeed Blue Blink BT Connected Continue Blue Blink 2 Times BT Disconnect per Second H. Test Symbologies Scan one or more of these bar codes to test symbologies you enabled.
  • Page 93 EAN 13 Interleave 2 of 5 234567 890128 ISBN ISSN GS1 DataBar Omnidirectional GS1 DataBar Expanded GS1 Databar Limited MSI / Plessey Matrix 2 of 5 Industrial 2 of 5 UPC A UPC E 12345 67890 123456 Telepen China Postage...

  • Page 94: Quick Configuration

    QUICK CONFIGURATION Start Configuration (Select your Settings) End Configuration Save Parameters Set All Defaults Recall Stored Parameters Abort Configuration Version Information...
