Page 1: User Manual
393Z USER MANUAL High Resolution Dome Camera Please read the instructions thoroughly before using the product. 489a_V1.0 393Z USER MANUAL High Resolution Dome Camera Please read the instructions thoroughly before using the product. 489a_V1.0... - Page 3 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
- Page 4 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device mat not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
-
Page 5: Table Of Contents
TABLE OF CONTENT FEATURES ......................1 PACKAGE CONTENT .................... 1 SPECIFICATIONS*....................2 LENS ANGLE ADJUSTMENT................. 3 CONNECTION......................3 INSTALLATION ....................... 4 CAMERA CONFIGURATION.................. 8 TABLE OF CONTENT FEATURES ......................1 PACKAGE CONTENT .................... 1 SPECIFICATIONS*....................2 LENS ANGLE ADJUSTMENT................. 3 CONNECTION...................... -
Page 7: Features
FEATURES 1. 1/3" color CCD sensor with SONY Effio DSP 2. High resolution 3. F1.4 Large aperture 4. f3.8 ~ f9.5mm vari-focal lens 5. Min. illumination of 0.05 Lux at F1.4 6. External alarm device connection 7. Customized OSD for camera configuration 8. -
Page 8: Specifications
SPECIFICATIONS* Pick up Element 1/3" Color CCD image sensor with SONY Effio DSP Number of Pixel 768(H)x494(V) <NTSC> / 752(H)x582(V) <PAL> Resolution Super High Resolution Min. Illumination 0.05 Lux / F1.4 S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/60 (1/50) to 1/100,000 sec Vari-focal Lens f3.8mm ~ f9.5mm... -
Page 9: Lens Angle Adjustment
LENS ANGLE ADJUSTMENT The lens can be panned left or right for angle adjustment, maximum 60° respectively from the default position . CONNECTION 1. Connect the power connector of the camera to a DC 12V regulated power supply. NOTE: Please use a regulated DC12V power adaptor to operate this unit. The power tolerance of this unit is DC12V ±... -
Page 10: Installation
INSTALLATION Step1 Remove the Dome Cover Step2 Remove the Black Shield Case Remove the Dome Cover by turning it counterclockwise to the end and then First, unscrew the Black Shield Case. take it off. Then remove it by pressing the two sides and then pulling it outward. - Page 11 Step3 Align the screw holes Rotate the lens plate to the front side of the camera, and align the gaps on the plate with the three screw holes respectively as indicated below. Then, aim the lens to the place you want to watch.
- Page 12 Step5 Adjust the angle of the camera To adjust the angle of the camera, swivel the black rotatable plate from the center to the left or to the right, maximum 60° (Pan). Adjust the tilt angle by moving the lens, maximum 90°...
- Page 13 Step6 Replace the Black Shield Step7 Replace the Dome Cover Case Replace the dome cover to the camera Replace the Black Shield Case to the base and turn it clockwise to the end to camera base. Ensure that the Black secure it.
-
Page 14: Camera Configuration
CAMERA CONFIGURATION This camera has its own menu for parameter settings. To enter the menu, please connect this camera with a DCCS-enabled DVR, or used with our control box, AVK-T1, when it’s connected to a non-DCCS DVR. Enter camera menu Connect the supplied power adapter to the camera’s power jack on the rear panel and the power outlet. - Page 15 From DCCS menu Right-click to display the DVR main menu, and select “ADVANCED CONFIG“ “DCCS“. ADVANCED CONFIG CANERA C H 1 C H 2 C H 3 C H 4 DETECTION DIAGNOSTIC START ALERT MENU SETUP NETWORK DISPLAY RECORD DEVICES DCCS DEVICE OSD CAM...
-
Page 16: Camera Menu
Camera menu SUB-MENU DESCRIPTION SHUTTER / AGC 1. Select “AUTO” to allow the camera to act automatically when the light condition of the environment changes. 2. Select “MANUAL” to fix the shutter and AGC modes of the camera no matter how the light condition of the environment changes. - Page 17 Camera menu tree SUB-MENU OPTIONS SHUTTER / AGC AUTO HIGH MODE AUTO IRIS / LUNINANCE SHUT+AUTO IRIS BRIGHTNESS 0 ~ 255 MODE AGC / OFF LUMINANCE BRIGHTNESS x0.25 / x0.50 / x0.75 / x1.00 MANUAL MODE SHUT + AGC SHUTTER 1/50;...
- Page 18 SUB-MENU OPTIONS WHITE BAL PUSH USER1 B – GAIN / 0 ~ 255 USER2 R – GAIN BACKLIGHT OFF / BLC / HLC PICT ADJUST MIRROR OFF / ON BRIGHTNESS / 0 ~ 255 CONTRAST / SHARPNESS / HUE / GAIN LUMINANCE LOW / MID / HIGH CONTRAST...
- Page 19 SUB-MENU OPTIONS DAY/NIGHT COLOR BURST ON / OFF AUTO BURST ON / OFF DELAY CNT 0 ~ 255 DAY-> NIGHT 0 ~ 255 NIGHT-> DAY 0 ~ 255 NR MODE Y/C; Y; C; OFF Y LEVEL C LEVEL CAMERA ID OFF / ON LANGUAGE ENGLISH / 日本語...
