Summary of Contents for Avtech AVM332P
- Page 1 ADVANCED NETWORK SETUP For wired network camera Please read instructions thoroughly before operation and retain it for future reference. network_ipcam_V0.9...
- Page 2 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
- Page 3 MPEG4 Licensing THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. Check Your Network Environment ...................... 5 2 Wireless Router + Modem ........................6 2.1 Configure on Laptop / Computer ....................... 6 2.2 Configure with iOS devices (iPhone / iPad) ....................8 2.3 Configure with Android mobile devices ....................10 3 Router + Modem .......................... -
Page 5: Check Your Network Environment
1. Check Your Network Environment Please follow the instructions below to finish camera installation and network configurations. Check your network environment and see which category you have: If you’re using: Wireless router + modem, please refer to “2 Wireless Router + Modem”. ... -
Page 6: Wireless Router + Modem
2 Wireless Router + Modem You may use your laptop / computer, or your iOS (iPhone / iPad) and Android mobile device to complete the network configuration of the camera. Note: Network setup with your iOS (iPhone / iPad) and Android mobile device is available only for EaZy Networking, Push Video, and ETS camera series. - Page 7 Step4: Open Internet Explorer on your laptop / computer, and enter the IP address and port number you just found in the URL column to access this camera. The format is http://ipaddress:portnum, such as http://192.168.2.25:88 in our example. In the login page, enter the user name, password, and security code to access. Note: Please skip the wizard.
-
Page 8: Configure With Ios Devices (Iphone / Ipad)
2.2 Configure with iOS devices (iPhone / iPad) Before configuring this camera on iPhone / iPad, make sure: You’ve installed our mobile app, EagleEyes, in your iPhone / iPad. Note: If you haven’t installed EagleEyes, please go to “App Store” and search “eagleeyes”. The free version of EagleEyes is EagleEyes (Lite) for Android 1.6 (or later) or EagleEyes(Lite+) for Android 2.2 (or later). - Page 9 Step2: Open “EagleEyes” on your iPhone or iPad. In the address book, click “+” to add new device. Then, select “Local Network Search” to search your network camera. You’ll see an IP address assigned by your router. If you connect two or more cameras to the wireless router, you’ll see many cameras with different IP addresses after searching.
-
Page 10: Configure With Android Mobile Devices
Step5: In the new device page, give a meaningful name for this connection in “Title”, and click “Save”. Please continue with configuring port forwarding as instructed in “APPENDIX 3 CONFIGURE PORT FORWARDING” at page 23. Check your connection Step1: Switch the network mode to 3G mode on iPhone or iPad. Step2: Start EagleEyes, and select the connection you just added to see if you can access the camera successfully. - Page 11 Step3: Select the IP address you want to configure to show the IP address setting page. Then, click the drop-down list of “Network” to change the network type from “DHCP” to “Static”. The default port number is 88. You may change it to any value (such as 8080) if you know the port number of 88 is blocked.
- Page 12 Step5: In the new device page, give a meaningful name for this connection in “Title”, and click “Save”. Step6: Go to “Check your connection” below to examine your connection. Check your connection Step1: Switch the network mode to 3G mode on your android device. Step2: Start EagleEyes, and select the connection you just added to see if you can access the camera successfully.
-
Page 13: Router + Modem
3 Router + Modem You may use your laptop / PC to complete the network configuration of the camera. Before configuring this camera on your laptop / PC, make sure: Your Windows operating system is Windows 7, Vista or XP. ... - Page 14 If your router supports UPnP, please proceed Step7. If your router doesn’t support UPnP, click “Save”, and access your router for port forwarding as instructed in “APPENDIX 3 CONFIGURE PORT FORWARDING” at page 23. Step5: Go to “UPnP”, and enable the UPnP service. Then, enable “Port Mapping”, and click “Save”...
-
Page 15: Modem / Hub + Modem
4 Modem / Hub + Modem You may use your laptop / PC to complete the network configuration of the camera. Before configuring this camera on your laptop / PC, make sure: Your Windows operating system is Windows 7, Vista or XP. ... - Page 16 Item Description Account Change your default account password if needed. This change can also be made in “Config.” “General” “Account”. Date and Time Check and select the current date and time. Network Configure your network setting based on the network type you’re using. For details, please refer to Step4 &...
- Page 17 a) Enable DDNS. b) Select “default” in “System Name”. c) In “Hostname”, keep the default value, i.e. the MAC address of this camera. Then, note down the whole address of the camera, for example, MAC000e531d6ff1.ddns.eagleeyes.tw. d) (Optional) Enter your email address to receive messages from the DDNS server. Note: Please at least use the default address to access your network camera remotely once.
-
Page 18: Change Default Account
5 Change Default Account To ensure your account safety, please access the camera after network configuration to change the default user name and password with new one you prefer. 5.1 From Web Browser Log into the camera, and select “Config.” “General” “Account”. Select the default account “admin”, and click “Edit”... -
Page 19: Appendix 1 Change Ip Address Of Your Laptop / Pc
APPENDIX 1 CHANGE IP ADDRESS OF YOUR LAPTOP / PC For LAN connection with this network camera, you need to change the IP address of your laptop / PC to 192.168.1.xxx (1~255, except 10) first. Note: Before changing the IP address, make sure you note down the original IP address setting of your laptop / PC. - Page 20 For Windows Vista users: ” (start) “Control Panel” “Network and Internet” to enter the “Network and Sharing Center”. a) Select “ Then, click “Manage network connections” (If you’re in “Category View”). b) Right-click on “Local Area Connection”, and select “Properties”. Note: If your local area connection is not enabled, please also enable it.
- Page 21 b) Right-click on “Local Area Connection”, and select “Properties”. Note: If your local area connection is not enabled, please also enable it. c) In the “Networking” tab, select “Internet Protocol Version 4 (TCP/IPv4)”, and select “Properties”. d) In the “General” tab, select “Use the following IP address”, and set the IP address as described below. Note: It’s recommended to note down the current settings first and then change as instructed.
-
Page 22: Appendix 2 Mobile Surveillance Via Eagleeyes
APPENDIX 2 MOBILE SURVEILLANCE VIA EAGLEEYES EagleEyes is a mobile phone program used with our surveillance system for remote surveillance. It has several advantages: It’s free (Except EagleEyes Plus for iPhone, EagleEyesHD Plus for iPad, and EagleEyes(Plus+) for Android mobile devices). -
Page 23: Appendix 3 Configure Port Forwarding
APPENDIX 3 CONFIGURE PORT FORWARDING You need to additionally access your router for port forwarding when your router doesn’t support UPnP. Each router has different setting page. Here we’re taking D-Link wireless router as an example. Step1: Access your router for port forwarding. ...
