- Page 1 377Z USER MANUAL High Resolution Dome Camera Please read the instructions thoroughly before using the product. 484a_V1.0 377Z USER MANUAL High Resolution Dome Camera Please read the instructions thoroughly before using the product. 484a_V1.0...
-
Page 2: Risk Of Electric Shock
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages. -
Page 3: Package Content
FEATURES 1. 1/3" color CCD sensor with SONY Effio DSP 2. High resolution 3. F1.4 Large aperture 4. f3.8 ~ f9.5mm vari-focal lens 5. Supports 0.05 Lux at F1.4 6. Vandal-proof housing design (IPxx7) PACKAGE CONTENT Please make sure you have the following items in your sales package: Vari-Focal Dome Camera with Power and Video Cable * 1 User Manual * 1... -
Page 4: Specifications
SPECIFICATIONS* Pick up Element 1/3" Color CCD image sensor with SONY Effio DSP Number of Pixel 768(H)x494(V) <NTSC> / 752(H)x582(V) <PAL> Resolution Super High Resolution Min. Illumination 0.05 Lux / F1.4 S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/60 (1/50) to 1/100,000 sec f3.8mm ~ f9.5mm Vari-focal Lens... -
Page 5: Lens Angle Adjustment
LENS ANGLE ADJUSTMENT The lens can be panned left or right for angle adjustment, maximum 60° respectively from the default position . CONNECTION 1. DC12V Terminal Connect the power connector of the camera to a DC 12V regulated power supply. NOTE: Please use a regulated DC12V power adaptor to operate this unit. -
Page 6: Installation
INSTALLATION Step1 Remove the Dome Cover Step2 Remove the Black Shield Case Remove the Dome Cover by turning it First, unscrew the Black Shield Case. Then remove counterclockwise to the end and then take it off. it by pressing the two sides and then pulling it outward. - Page 7 Step3 Align the screw holes Step4 Attach the camera to the ceiling Attach the camera to the ceiling with three screws. Rotate the lens plate to the front side of the Then, connect the power and video cable to the camera, and align the gaps on the plate with the power supply and the input of the DVR for later three screw holes respectively as indicated...
- Page 8 Step5 Adjust the angle of the camera To adjust the angle of the camera, swivel the black rotatable plate from the center to the left or to the right, maximum 60° (Pan). Adjust the tilt angle by moving the lens, maximum 90° (Tilt). Use a flat-headed screwdriver to loosen the pivots on the lens.
- Page 9 Step6 Replace the Black Shield Case Step7 Replace the Dome Cover Replace the Black Shield Case to the camera Replace the dome cover to the camera base and base. Ensure that the Black Shield Case does not turn it clockwise to the end to secure it. cover the lens.
