LR-8500 & 9500
LIFE ROWER
Seat
OC68-00945-0001
Seat w/Roller Assembly
AK01-00007-0000
Seat Bracket
OC68-00164-00XF
Roller(6)
SC68-00041-0000
Extrusion
OC68-00995-0000
Pedestal
OC68-00932-00XF
Leveler(2)
0017-00102-0083
Glass
R901-30000-0072
Bezel Assembly
AK01-00048-0000
Yoke Assembly(LT)
AK01-00038-0002
Foot Padal(2)
OC68-00934-00XF
1 of 3
Switch Membrane Assembly
AK01-00041-0000
Rear Cover w/Decal
AK01-00052-0000
Flame Retardent Shroud
AK01-00052-FR
(Note: Decal is 9500 only)
Decal (9500 only)
OK01-01056-0000
Foot Pad(4)
OK01-01029-0000
Pivoting Strap
AK01-00036-0000
Pivoting Strap w/Plate
AK01-00037-0000
Yoke Assembly(RT)
AK01-00038-0001
Revision Date: 11/18/98
Advertisement
Related Manuals for Life Fitness LifeRower LR8500
Summary of Contents for Life Fitness LifeRower LR8500
- Page 1 LR-8500 & 9500 LIFE ROWER Seat Yoke Assembly(LT) OC68-00945-0001 AK01-00038-0002 Seat w/Roller Assembly AK01-00007-0000 Seat Bracket OC68-00164-00XF Roller(6) SC68-00041-0000 Extrusion OC68-00995-0000 Pedestal OC68-00932-00XF Leveler(2) 0017-00102-0083 Switch Membrane Assembly AK01-00041-0000 Glass R901-30000-0072 Bezel Assembly AK01-00048-0000 Foot Padal(2) OC68-00934-00XF Yoke Assembly(RT) AK01-00038-0001 1 of 3 Rear Cover w/Decal AK01-00052-0000...
- Page 2 LR-8500 & 9500 LIFE ROWER 2 of 3 Revision Date: 11/18/98...
- Page 3 LR-8500 & 9500 LIFE ROWER Key Pad Cable AK01-00022-0000 GK01-00003-0005(R) Flywheel OC68-00902-0000 Flywheel Pin 0017-00007-0192 Power Module Assembly 120v/60Hz AK01-00010-0000 110v/50Hz, 200v/50Hz, 220v/60Hz AK01-00010-0001 100v/50Hz, 220v/50Hz, 230v/50Hz, 240v AK01-00010-0002 Monitor & Fan Cable AK01-00057-0000 Convenience Outlet AK01-00030-0000 ON/OFF Switch 0017-00032-0181 3 of 3 Speaker 0017-00003-0659...
