Page 1: Assembly Instructions
CLUB SERIES LAT PULLDOWN ASSEMBLY INSTRUCTIONS Part # 6941801 Revision:08/02/00 Rev A. -
Page 2: Parts List
PART # DESCRIPTION 69046xx ASSY TOWER 6920001 CABLE 6714901 GUIDE ROD BUSHINGS 69032xx WLDMT, MAIN UPRIGHT 6692601 3 X 2 END CAP 6902201 SUPPORT HOOK CHROME 3222801 4.5" PULLEY 3102933 3/8-16 X 2 BOLT 3102903 3/8-16 X 2.5 BOLT 3102922 3/8-16 X 2.75 BOLT 6866701 3/8 RH WASHER... - Page 3 FIGURE 1 STEP 1: • LOOSELY assemble the TOWER (1) to the BENCH FRAME (3) using four RH CAPS (27), two 3/8 X 3-3/4” BOLTS (10), four 3/8” RH WASHERS (14) and two 3/8” LOW HEIGHT LOCK NUTS (11) as shown in FIGURE 1. 10 3/8 X 3-3/4”...
- Page 5 3/8 X 3-3/4” 10 FIGURE 2 STEP 2: • LOOSELY assemble the MAIN UPRIGHT (2) to the base of the BENCH FRAME (3) using four RH CAPS (27), two 3/8 X 3-3/ 4” BOLTS (10), four 3/8” RH WASHERS (14) and two 3/8” LOW HEIGHT LOCK NUTS (11) as shown in FIGURE 2. •...
- Page 6 FIGURE 3 STEP 3: • SECURELY assemble the KNEE SUPPORT (5) to the BENCH FRAME (3) using two BLACK RH CAPS (17), two RH CAPS (27), two 3/8 X 2-3/4” BOLTS (9), four 3/8” SAE WASHERS (13), four 3/8” RH WASHERS (14) and two 3/8” LOW HEIGHT LOCK NUTS (11) as shown in FIGURE 3.
- Page 7 3/8 X 2-3/4” 9 FIGURE 4 STEP 4 • SECURELY assemble the SEAT PAD (18) to the BENCH FRAME (3) using two RH CAPS (27), two 3/8 X 2-3/4” BOLTS (9) and two 3/8” RH WASHERS (14) as shown in FIGURE 4.
- Page 8 FIGURE 5 HEAVY WEIGHT OPTION STEP 5: • Insert the two GUIDE RODS (26) (found in the SHROUD KIT) into the base of the TOWER (1) as shown in FIGURE 5. Lubricate the GUIDE RODS (26) with a slicon or teflon spray that is available at most hardware stores. •...
- Page 9 FIGURE 6 TIGHTEN! STEP 6: • SECURELY assemble the GUIDE ROD SUPPORT (6) to the TOWER (1) and MAIN UPRIGHT (2) using four RH CAPS (27), two 3/8 X 2-3/4” BOLTS (9), four 3/8” RH WASHERS (14) and two 3/8” LOW HEIGHT LOCK NUTS (11) as shown in FIGURE 6. •...
- Page 10 TIGHTEN! FIGURE 7 S T ` ` ` ` ` • The WEIGHT STACK LABEL sheet (12) includes labels for both lbs. and kgs. for both the standard and optional weight stacks. • Peel the backing off the WEIGHT STACK LABELS (12), line up sheet to the right of the selector opening and apply labels to the WEIGHT PLATES (24), starting with the HEAD PLATE (8) as shown in FIGURE 7.
- Page 11 FIGURE 8 STEP 8: • Assemble the PLACARD LABEL (22) or the FOREIGN LANGUAGE PLACARD LABEL (23) to the FRONT SHROUD as shown in FIGURE 8. • Attach LAT BAR (4) and/or TRICEP ROPE (7) end of cable using on SNAP LINK (21) with the TRICEP ROPE (7) as shown in FIGURE 8.
- Page 12 FIGURE 8 STEP 8: (NOTE: If the PARTIAL SHROUD KIT is being used follow STEP 8. If the FULL SHROUD KIT is being used follow STEP 9.) • SECURELY assemble the FRONT PARTIAL SHROUD (29) and the REAR PARTIAL SHROUD (30) to the TOWER (1) using twelve 3/8 X 3-1/2”...
- Page 13 FIGURE 9 STEP 9: • SECURELY assemble the FRONT FULL SHROUD (31) and the REAR FULL SHROUD (32) to the TOWER (1) using ten 3/8 X 3-1/2” BUTTON HEAD BOLTS (28), ten STARLOCK WASHERS (27), and ten 3/8” ACORN NUTS (12) as shown in FIGURE 3/8 X 3-1/2”...
-
