Summary of Contents for Ness W1-B
-
Page 1: User Manual
1~4 Waterproof Keypad/Reader/Controller ansmitted ternal Wiegand erminals on the 13.56MHZ) can external reader, added at either Supply • • •• • •• • W1-B User manual... - Page 2 improvement.
-
Page 3: Packing List
W1/W3-B. 2. Description (W1-B&W3-B are in the same function, only different in shape . ) W1/W3-B is single door multifunction access controller or a Wiegand output keypad or card reader. It is suitable for mounting either indoor or outdoor in harsh environments. It is housed in a strong, sturdy and vandal proof Zinc Alloy electroplated case. -
Page 4: Installation
12VDC Environment Conforms to IP68 User Capacity 2500 Adjustable Door Relay time 0~99 seconds 12 keys, 2 x 6 digits(W1-B) Keypad Adjustable Alarm Time 0~3 minutes 12 keys, 3 x 4 digits(W3-B) Wiegand Interface Card Type EM 125 KHZ card/Tag Wiegand 26 input &... -
Page 5: Connection Diagram
6. Wiring Colour Function Description Green Wiegand Output D0 White Wiegand Output D1 Grey Alarm - Alarm Negative Yellow OPEN Request to Exit Button Brown D-IN Door Contact +12V DC Power Input Black -12V DC Power Input Blue Relay NO Purple Relay COM Relay NC... -
Page 6: To Reset To Factory Default
Power • • • • • Pink • • • • • • • • • • • • • • • • • • • • • Green • • • • • • • •• • • • White •... -
Page 7: Sound And Light Indication
9. Sound and Light indication Operation Status Red Light Green Light Blue Light Buzzer Power on Bright Short Ring Stand by Bright Press keypad Short Ring Operation successful Bright Short Ring Operation failed 3 Short Ring Bright Enter into programming mode Short Ring In the programming mode Bright... - Page 8 1 User ID number # PIN # To add a PIN users The ID number is any number between 1 ~ 2500. The PIN is any four digits between 0000 ~ 9999 with the exception of 1234 which is reserved. Users can be added continuously without exiting from programming mode as follows: 1 User ID No 1 # PIN # User ID No 2 # PIN #...
- Page 9 To add and delete users in card and PIN mode ( 3 1 # ) Add the card as for a card user To Add a card and Pin user Press * to exit from the programming mode (The PIN is any four digits between Then allocate the card a PIN as follows: 0000 ~ 9999 with the exception of 1234 which is reserved.)
-
Page 10: Door Open Detection
To unlock the door For a PIN user Enter the PIN then press # For a card user Read card For a card and PIN user Read card then enter PIN # 10.2 Door Relay, Door Open Detection, Alarm, Facility code Settings Door relay time setting 4 0~99 # Door relay time setting... -
Page 11: Interconnecting Two Devices
7 1 # Keypad Lockout 7 2 # Alarm Output To remove the alarm To reset the Door Forced Open warning Read valid card or Master Code # To reset the Door Open Too Long warning Close the door or Read valid card or Master Code # To set the facility code To set the facility code of W1/W3- 8 Facility code # Repeat Facility code #... - Page 12 Transmission Format: 1: Keypad Transmission The Reader will transmit the PIN data when it receives the last key (#) press after PIN code. Format: Facility Code + PIN Code (Facility code is any digits between 0~255, factory default is 0; Pin code is any 1~4 digits between 0~9999) Example: Facility code: 1 de #...
- Page 13 W1/W3-B Quick Reference Programming Guide Master code To enter the programming mode 888888 is the default factory master code To exit from the programming mode Note that to undertake the following programming the master user must be logged in To change the master code The master code is any 6 digits User ID number The ID number is any number between 1 ~ 2500.
