- Page 1 Ness 101-082B Metal Waterproof Access Control Keypad (non-addressable) 101-082B User Manual...
- Page 2 1. Introduction Single door stand alone multi function access controller Keypad and Card Reader with Wiegand output. Non- addressable 2. Technical Specifications 101-082B Description Features Appearance Metal case, anti-explosion and anti-tamper Waterproof IP 65 Input voltage DC: 12-24V AC: 12-18V Capacity(max) 2500 users Anti-demolition alarm...
- Page 3 3.3 Connection Diagram 3.3.1 Common power supply Negative Output Pink Power Green Wiegand Output/Input AC&DC Alarm Power Supply White Wiegand Output/Input 1 2 V /3A Positive Grey Connect Alarm Negative ALARM- Exit Button Yellow OPEN Alarm Door Contact Button Brown D_IN AC&DC Black...
- Page 6 Ness 101-082B Access Control Keypad Programming and User Manual Document Part No: N/A Aug 2020 www.nesscorporation.com National Customer Service Centre For the product: 101-082B Keypad Ph: 1300 551 991 customerservice@ness.com.au...
