CORDLESS
CHAINSAW
36V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
36V
Battery:
3.0Ah Li-ion
Charge Time:
3 Hours
Motor:
Brushless Motor
Bar Type:
Oregon 305mm (12")
Chain Pitch:
9.53mm (3/8")
No Load Speed:
8,000/min
Chain Speed:
9m/s
Chain Oil Tank Capacity: 180ml
Chain Oil:
Chain Bar Oil
Weight with battery:
6.5kg
ozito.com.au
WHAT'S IN THE BOX
Chainsaw
Guide Bar
Chain
Guide Bar Cover
Battery Pack
Battery Charger
CSL-036
Advertisement
Table of Contents
Related Manuals for Ozito CSL-036
Summary of Contents for Ozito CSL-036
- Page 1 Brushless Motor Bar Type: Oregon 305mm (12”) Guide Bar Cover Chain Pitch: 9.53mm (3/8”) No Load Speed: 8,000/min Chain Speed: 9m/s Chain Oil Tank Capacity: 180ml Chain Oil: Chain Bar Oil Weight with battery: 6.5kg ozito.com.au Battery Pack Battery Charger CSL-036...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS CHAINSAW 1. ASSEMBLY 1 Rear Handle 8 Guide Bar 2 Trigger Switch 9 Chain Fitting a chain and bar 3 Battery 10 Bucking Spikes 11 Oil Level Window 4 Chain Tensioning CAUTION!: ALWAYS BE SURE THAT THE TOOL IS Adjustment Knob SWITCHED OFF AND THE BATTERY PACK IS REMOVED 12 Chain Oil Tank Cap... - Page 3 2. OIL 5. Fit the side cover back onto the IMPORTANT: ONLY USE OIL THAT IS EXPRESSLY chainsaw. Screw on the guide bar LABELLED “CHAIN BAR OIL”. locking knob but do not fully tighten at this stage. 2. Fill the tank with chain bar oil. 1.
- Page 4 3. BATTERY & CHARGING Battery Charge Indicator Charging your lithium ion battery The chainsaw battery is equipped with The chainsaw’s battery has been shipped in a low charge condition, a battery charge indicator to show the and requires charging prior to use. Allow several cycles of charging and state of the battery charge.
-
Page 5: Operation
OPERATION 4. SWITCHING ON/OFF 5. CUTTING Switching on CAUTION: FIRST TIME USERS SHOULD, AS A MINIMUM 1. Pull the hand guard/chain PRACTISE, CUT LOGS ON A SAW-HORSE OR CRADLE brake towards you. The brake may be stiff and may require to be moved with 1. -
Page 6: General Maintenance
APPLICATIONS MAINTENANCE 6. GENERAL MAINTENANCE Felling a tree WARNING!: BEFORE CLEANING YOUR CHAINSAW OR CARRYING OUT ANY MAINTENANCE WARNING!: FELLING A TREE SHOULD ONLY BE PROCEDURE, MAKE SURE THAT THE MOTOR IS OFF AND DONE BY TRAINED OPERATORS. THE BATTERY REMOVED TO PREVENT ACCIDENTAL STARTING. -
Page 7: Hints And Tips
Chain Replacement: Blade continues to rotate after the machine is switched off. Wait until all The chain can be purchased through Ozito spare parts or from your machine components have completely stopped before touching them. local Bunnings Warehouse. The correct chain can be purchased by matching the pitch, gauge and number of links as shown below: Do not saw in the rain or leave the chainsaw outdoors while raining. - Page 8 Model No. CSL-036 Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Battery Pack ACCLB-136 Charger...
-
Page 9: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 10: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0514...
