- Page 1 ® Vidifox Document Camera GV 400 USER GUIDE Please read this manual carefully before operating the camera and keep it for your reference.
- Page 2 PLEASE READ CAREFULLY BEFORE USE n Please be aware of the required power supply environment is 100-240V, 50/60Hz, 2A Max. n Do not place the equipment under sunlight, near heaters, near water, or on any unstable surface. n Keep the equipment away from acid or alkali gas. n...
-
Page 3: Table Of Contents
CONTENTS 1. PARTS A ND F UNCTION ................. 1 2.INPUTS A ND O UTPUTS ................ 2 3. C ontrol P anel .................. 3 ... -
Page 4: Parts A Nd F Unction
1. PARTS AND FUNCTIONS 1. Camera 2. LED light box 3. Goose neck 4. Remote control IR receiver 5. Side panel 6. Control panel... -
Page 5: Inputs And Outputs
2.INPUTS AND OUTPUTS 1.VGA IN: VGA(RGB) signal input(15 pin D-SUB). 2.VGA OUT: VGA(RGB) signal output(15 pin D-SUB). 3.HDMI:HDMI signal output 4.LAN: Network connection 5.USB-B: USB slave, used to connect with PC 6.USB1/USB2: USB host, used to connect with USB mouse or USB memory stick. 7.SD CARD: SD card slot. -
Page 6: Control Panel
3.Control Panel 1.PC/CAM: Switch between the camera signal and PC signal. 2.AUTO: Adjust white balance and focus automatically. 3.FOCUS+/-: Adjust focus manually, focus far and focus near. 4.BRIGHT+/-: Image brightness control. 5.ZOOM+/-: Image zoom in and zoom out. : Power on/off. When turn off the power, the PC signal can pass through the visualizer via VGA in and VGA out. -
Page 7: Remote Control
SD card, or built-in memory. GV 400 can detect when there is an external storage media and automatically switch to the last detected storage. If there is no external storage connected, all video slip will be saved in the built-in memory. - Page 8 6.Mir: Flip the camera image. 7.Save: Capture and save the image to Memory stick, SD card, or built-in memory. GV 400 can detect when there is an external storage media and automatically switch to the last detected storage. If there is no external storage connected, all captured image will be saved in the built-in memory.
-
Page 9: Annotation
5.ANNOTATION The annotation function will be activated by connecting a USB mouse to the document camera. We will see the following icons by clicking the left button on a mouse: ：Clicking this icon, the whiteboard function is activated. The image captured is now subjected to annotation. - Page 10 ：Output the mirror image ：Switch the image mode between positive and negative. ：Image freeze ：Image split. ：Title freeze. In Title freeze mode, there are 4 buttons used to adjust the title function: : Enlarge the frozen title area : Reduce the frozen title area : Adjust the frozen title position.
-
Page 11: Multimedia System
6.MULTIMEDIA SYSTEM Under the main system interface user can find tips column and function column. 1. Tips column indicates no USB flash drive plugs in indicates USB flash drive plugs in indicates no SD card plugs in indicates SD card plugs in indicates document camera’s wireless function has been disabled indicates document camera’s wireless function has been enabled 2. - Page 12 ：Open the files saved in SD card or memory stick that connected to the document camera(see the screen shot below) ：Browse the webpage ：System settings...
- Page 13 Settings 1. Device Name :Define the SSID of the document camera. Factory Mode: Enter to adjust the parameters of document camera. Please contact the dealer for professional assistance. 2. Resolution Select the suitable output resolution of the document camera. Note: Document camera will be restarted after switches resolution.
- Page 14 Frame rate switching: Video mode: Frame rate: 30fps Stand mode: Frame rate: 22fps Visualizer mode: Frame rate: 12fps 3. Network Network: Wired network: Select to connect to a router with cable via LAN. Wireless network: Select to connect to an external Wi-Fi network. Device hotspot: Select to connect to the embedded Wi-Fi network.
- Page 15 IP: Select to configure the IP address automatically or manually. 4. Language Switch the system language between simplified Chinese and English. 5. System...
- Page 16 Please try restarting the device or restoring factory settings if there is a problem with the system. Click “firmware upgrade” to start upgrading system firmware. Note: There is risk involved in upgrading the firmware ,please upgrade under the guidance of professionals.
-
Page 17: Software
7.SOFTWARE Software I nstallation There are 3 types of software in CD for different operation systems, here we take the software of Windows system for example. Double click in CD to install the software to your PC, there will be a generated icon on the desktop Connection ... - Page 18 Wired network Wireless network Software S tart Note: Please go back to Visualizer mode before start the software. Double click the icon on the desktop. Left click on the left tool bar , or choose the “select” of “visualizer” in the menu bar.
- Page 19 There will be a window lists all connected devices. Double click the DocCamera icon to activate it, then the image from this camera will be displayed.
- Page 20 We also can choose to connect a device manually. 1) Tick the 2) Input the IP address of the device need to be selected 3) Click to activate. Please refer to the help for detailed information.
-
Page 21: Specifications
8.SPECIFICATIONS Model GV 400 Sensor 1/3" CMOS Zoom 9x optical, 20x digital Frame rate Shooting area Max:14.7"x11.7", Min: 0.1"x0.1" Focus Auto/manual Native output signal SXGA(1280x1024@60Hz) Converted output signal XGA,720P, 1080P Resolution (Horizontal) ≥ 750 TV lines White balance Auto/manual Brightness adjustment... - Page 22 Power supply 12V DC power adapter Weight(net) 5.5lbs/2.5kg...
-
Page 23: Trouble-Shooting
9.TROUBLE-SHOOTING Symptoms Possible causes/counter-measures No image 1. Power cord is not properly connected. 2. Cables are not properly connected. 3. Power switch is not turned on. 4. The built-in fuse is broken: Change fuse. 5. Change the output resolution. Image bending Camera not in right position, adjust the camera. -
Page 24: Packing List And Accessories
10.PACKING LIST AND ACCESSORIES Items Quantity Power cord & adaptor VGA Cable HDMI Cable USB Cable Remote control CD(Software and user manual)
