Snap Server 700i Series
To remove a failed fan module, unplug the cable and lift the module out of the
2
unit.
Needlenose pliers may be required to remove the cable on Fan 1.
Note
Fan 1
Set the module aside.
3
Field Service Documentation
Copyright © 2007, Adaptec, Inc. All rights reserved. Information in this document is subject to change without notice and does not represent
a commitment on the part of Adaptec or any of its subsidiaries.
Fan 5
Fan 3
Fan 2
Replacing a Fan Module
Cable
3
