- Page 1 SM-821DT User’s Manual Indoor Pan/Tilt/Zoom Add-on Wireless Camera For DIGILCDNDVR Series...
- Page 2 SecurityMan. The content of this manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by SecurityMan.
- Page 3 The liability of SecurityMan Inc, arising from this warranty and sale shall be limited to a refund of the purchase price. In no event shall SecurityMan be liable for costs of procurement of substitute products or services, or for any lost profits, or for any consequential, incidental, direct or indirect damages, however caused and on any theory of liability, arising from this warranty and sale.
-
Page 4: Table Of Contents
Table of Contents Features Important Restrictions Contents Product Basics Front Back Operations Adding our camera to the SM-871DR receiver Specifications... -
Page 5: Important
Important This guide provides important information on the use and operation of your SM-821DT. Please read all the information carefully prior to using the product for the best performance and to prevent any damage/injuries or misuse of the device(s). Customers are entitled to have read through this complete user’s manual before using the SM-821DT. - Page 6 • DO NOT use this product to carry out any illegal activities such as sneak preview, and etc. SecurityMan shall not be responsible for any consequences of illegal conducts made by users. • DO NOT put the plastic package bags in reach of children or babies. Young children can choke on these items if they put them into their mouths.
- Page 7 adapter near heaters, or put it on the floor which is equipped with a heater. The above mentioned operation might cause fire or incidents. • DO NOT use it aboard; please abide by the airway’s provision. It might influence communication aboard and the flying apparatus if departing from the airway’s regulation.
- Page 8 Please turn off the power when not in use. • Do not disassemble the product. • Do not shake or strike the product. • Please obey the local government’s environment protection policy. Contents 1 x SM-821DT 1 x Mounting 1 x AC Adapter Mounting User’s...
-
Page 9: Product Basics
Product Basics Front Light Sensor Camera Lens Air Ventilation IR LED’s Microphone Back Antenna Pair Power Socket Power LED Pair Button... -
Page 10: Adding Our Camera To The Sm-871Dr Receiver
The SM-871DR is a 4 channel receive and can support up to 4 cameras (SM-816DTX or SM-821DT). To add a camera, make sure that the camera is powered on and is no more than 2 feet away from the receiver and follow the steps below. - Page 11 3. Now select Camera Pairing from the available options and “keep pressing” (press/release/press/release) the Pairing Button located on the back of your camera until you see a green “Check Mark” on the screen. NOTE: Please repeat the process if a red “X” is displayed at any time during the pairing process.
-
Page 12: Specifications
Specifications ***Required and compatible with SM-871DR monitor/receiver. Operating frequency 2.4GHz Imaging sensor type CMOS Color Resolution 640 x 480 pixels (NTSC/PAL selectable) Minimum illumination 2 Lux (IR off); 0 Lux (IR on) LED night vision range Up to 30ft (B/W) Viewing angle Horizontal:210°...
