4. Click the "Set" button. This will reboot the phone. After the phone has finished 4. Click the "Set" button. This will reboot the phone. After the phone has finished 4. Click the "Set" button. This will reboot the phone. After the phone has finished
rebooting, it will be automatically configured with the selected User Extension. rebooting, it will be automatically configured with the selected User Extension. rebooting, it will be automatically configured with the selected User Extension.
5. Configure the other IP (SIP) Phone with the correct parameters. 5. Configure the other IP (SIP) Phone with the correct parameters. 5. Configure the other IP (SIP) Phone with the correct parameters.
6. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and 6. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and 6. To test the Atcom AT530P, pick up the previously configured IP (SIP) Phone and
call the AT530P's extension number (301 in this example). When the call is call the AT530P's extension number (301 in this example). When the call is call the AT530P's extension number (301 in this example). When the call is
established, speak into the phone and verify that the other IP (SIP) Phone can hear established, speak into the phone and verify that the other IP (SIP) Phone can hear established, speak into the phone and verify that the other IP (SIP) Phone can hear
your voice. Check this by calling from both ends. your voice. Check this by calling from both ends. your voice. Check this by calling from both ends.
Figure 4.12 Endpoint Configurator Figure 4.12 Endpoint Configurator Figure 4.12 Endpoint Configurator
