9.2.1.3
Setting the end stop of the footrest
Pre-requisites:
• 1x 6 mm Allen key
• 1x 10 mm open-ended spanner
The end position of the footrest is determined by means of a
rubber stop (1).
The rubber stop can be screwed in or out (A) or pushed up or
down (B).
