Dimensions
Seat height with Lifter
Seat width (adjustable range of
the armrests in brackets)
Seat depth
Backrest height ****
Seat cushion thickness
Backrest angle
Armrest height (standard
armrest)
Armrest height (travelling
armrest)
Length of legrest
• Short (for a calf length of 32-
38 cm)
• Medium (for a calf length of
38-44 cm)
• Long (for a calf length of 44-
50 cm)
Seat angle, electric adjustment
(wheelchair without lifter)
Seat angle, manual adjustment
(wheelchair without lifter)
Standard Kontur
• 43 ... 73 cm • 43 ... 73 cm
• 50 ... 80 cm • 50 ... 80 cm
• 43 cm (44 - 48 • 48 cm (49 - 53
cm**)
• 43 cm (44 - 48
• 41 / 46 / 51cm • 41 / 46 / 51cm
• 48 / 54 cm • 64 cm
• 5 cm • 7 cm
• -10°, 0°, +7.5°, • -10° ... +45°
+15°, +22.5°,
+30°
• 25-35 cm • 25-35 cm
• 29-39 cm • 29-39 cm
• 29,5 - 35,5 cm • 29,5 - 35,5 cm
• 35,5 - 41,5 cm • 35,5 - 41,5 cm
• 41,5 - 47,5 cm • 41,5 - 47,5 cm
• 0° ... +15° • 0° ... +15°
• 0° ... +15° • 0° ... +15°
Flex
• 43 ... 73 cm
• 50 ... 80 cm
• 38 cm (39)
cm**) • 43 (44 - 48
cm**)
cm**) • 48 (49 - 53
cm**)
• 41 / 46 / 51cm
• 55 cm
• 7 cm
• -10°...+45°
(electric)
• 25-35 cm
• 29-39 cm
• 29,5 - 35,5 cm
• 35,5 - 41,5 cm
• 41,5 - 47,5 cm
• 0° ... +15°
• 0° ... +15°
