• Lift leg over the heel strap and place on the ground.
9.2.2.8
Adjusting the angle adjustable foot plate
Pre-requisites:
• 1x 5 mm Allen key
• Use the Allen key to loosen both set screws on the foot
plate.
• Adjust to the desired angle.
• Re-tighten the screws.
