Owner's Operator and Maintenance Manual
TDX
SP
™
Power Wheelchair Base
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com

Advertisement

Table of Contents
loading

Related Manuals for Invacare TDX SP

Summary of Contents for Invacare TDX SP

  • Page 1 Power Wheelchair Base DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...

  • Page 2: Reference Documents

    APPLICABLE) AND (3) THE SEATING SYSTEM’S MANUAL (IF APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE, INJURY OR DAMAGE MAY RESULT. REFERENCE DOCUMENTS Refer to the table below for part numbers of additional documents which are referenced ...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS REFERENCE DOCUMENTS ... 2 REGISTER YOUR PRODUCT... 6 SPECIAL NOTES ... 9 LABEL LOCATIONS ... 11 All Wheelchairs...11 Wheelchairs with TRRO ...13 Wheelchairs without TRRO ...13 TYPICAL PRODUCT PARAMETERS ... 14 SECTION 1—GENERAL GUIDELINES ... 15 Repair or Service Information ...15 Operation Information ...16 Wheelchairs with TRRO or TRBKTS Only...17 Tire Pressure ...17...
  • Page 4 TABLE OF CONTENTS SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING ... 28 Safety Inspection Checklists...28 Inspect/Adjust Initially ...28 Inspect/Adjust Weekly...29 Inspect/Adjust Monthly...29 Inspect/Adjust Periodically...30 Inspect/Adjust Every 18 Months...30 Inspect/Adjust Every 2 Years ...30 Troubleshooting - Mechanical ...30 Troubleshooting - Electrical...31 SPJ™+, SPJ+ w/PSS or SPJ+ w/ACC Joysticks ...31 MPJ™+, PSR+, PSF+ Joysticks or Displays...32 Checking Battery Charge Level...34 SECTION 5—WHEELCHAIR OPERATION ...
  • Page 5 TABLE OF CONTENTS SECTION 6—MOTOR LOCKS ... 48 Disengaging/Engaging Motor Lock Levers...48 SECTION 7—WHEEL LOCKS ... 49 Disengaging/Engaging the Wheel locks...49 Engaging ...49 Disengaging...49 SECTION 8—FOOTBOARD ASSEMBLY ... 50 Removing/Installing the Footboard...50 Removing ...50 Installing...50 Adjusting the Footboard Angle ...51 SECTION 9—FORKS ...

  • Page 6: Register Your Product

    3. Receive updates with product information, maintenance tips, and industry news. 4. Invacare can contact you or your provider, if servicing is needed on your product. 5. It will enable Invacare to improve product designs based on your input and needs.

  • Page 7: Product Registration Form

    11. User's Year of birth: ______________________________________________________ If at any time you wish not to receive future mailings from us, please contact us at Invacare Corporation, CRM Department, 39400 Taylor Parkway, Elyria, OH 44035, or fax to 877-619-7996 and we will remove you from our mailing list.
  • Page 8 Fold here Fold here TDX™ SP Invacare Product Registration Form Please Seal with Tape Before Mailing Part No 1143190...

  • Page 9: Special Notes

    CHANGE WITHOUT NOTICE. WHEELCHAIR USER As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.
  • Page 10 Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. The seat positioning strap is a positioning belt ONLY. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts.

  • Page 11: Label Locations

    LABEL LOCATIONS All Wheelchairs Serial Number Label is located on the right side rear swingarm. Wheelchairs with 22NF Batteries Use 22NF Batteries Only. See Owner's Manual. Part No 1143190 CAUTION DRIVE PUSH Ensure both clutches Located on each are fully engaged before driving chair 4-pole motor P/N 1118367...
  • Page 12 Wheelchairs with GP24 Batteries TDX™ SP WARNING GP24 batteries with terminal configuration (negative on the left and positive on the right) as shown MUST be used. GP24 batteries that have the reverse terminal configuration MUST not be used. Terminals MUST have a cross hole located as shown for proper battery connection.

  • Page 13: Wheelchairs With Trro

    Wheelchairs with TRRO NOTE: Also on opposite side. Wheelchairs without TRRO NOTE: Auto style seat  positioning strap shown. This  label is also on the airline style  seat positioning strap. Part No 1143190 TDX™ SP...

  • Page 14: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS BASE LENGTH: OVERALL WIDTH OF BASE: TDS SP WITH TWO 22NF BATTERIES: TDX SP WITH TWO GP24 BATTERIES OR WITH THREE 22NF BATTERIES: OVERALL HEIGHT WITH ASBA SEAT: WITH VAN SEAT: WITH FORMULA CG TILT ONLY: WITH ELEVATING ASBA SEAT:...

  • Page 15: Section 1-General Guidelines

    - otherwise, injury or damage may occur. Repair or Service Information Set‐up of the Electronics Control Unit is to be performed only by a qualified technician.  The final adjustments of the controller may affect other activities of the wheelchair.  Damage to the equipment could occur if improperly set‐up or adjusted.  Except for programming, DO NOT service or adjust the wheelchair while occupied,  unless otherwise noted. A pinch point exists between head tube cap and walking beam.  A pinch point exists between walking beam/head tube cap and telescoping tube when  TDX is at the lowest seat to floor height. Before adjusting, repairing or servicing the wheelchair, ALWAYS turn the wheelchair  power Off, otherwise, injury or damage may occur. Invacare products are specifically designed and manufactured for use in conjunction with  Invacare accessories. Accessories designed by other manufacturers have not been tested  by Invacare and are not recommended for use with Invacare products. Transport ready packages are not retrofittable to existing models and are not field  serviceable.  Battery retention brackets MUST be installed at all times. Otherwise, the wheelchair will  not be WC/19 compliant. Refer to Removing/Installing the Batteries From/Into the  Wheelchair on page 57. Wheelchairs should be examined during maintenance for signs of corrosion (water  exposure, incontinence, etc.). Electrical components damaged by corrosion should be  replaced IMMEDIATELY. Wheelchairs that are used by incontinent users and/or are frequently exposed to water  may require replacement of electrical components more frequently.

  • Page 16: Operation Information

    SECTION 1—GENERAL GUIDELINES Operation Information Performance adjustments should only be made by professionals of the healthcare field or  persons fully conversant with this process and the driverʹs capabilities. Incorrect settings  could cause injury to the driver, bystanders, damage to the wheelchair and to  surrounding property. After the wheelchair has been set‐up/adjusted, check to make sure that the wheelchair  performs to the specifications entered during the set‐up procedure. If the wheelchair does  NOT perform to specifications, turn the wheelchair Off immediately and reenter set‐up  specifications. Repeat this procedure until the wheelchair performs to specifications. DO NOT leave the power button On when entering or exiting your wheelchair. DO NOT attempt to drive over curbs or obstacles greater than 3 inches. Doing so may  cause your wheelchair to turn over and cause bodily harm or damage to the wheelchair.  ALWAYS stop before climbing an obstacle. Approach slowly until casters contact the  obstacle. Apply power and the action of the SureStep feature will lift the casters over the  obstacle. Weight is transferred to the drive wheels providing traction and motor strength  to power the wheelchair over the obstacle. DO NOT operate on roads, streets or highways. DO NOT climb, go up or down ramps or traverse slopes greater than 9°. DO NOT attempt to move up or down an incline with water, ice or oil film. DO NOT stand on the frame of the wheelchair. DO determine and establish your particular safety limits by practicing bending, reaching  and transferring activities in the presence of a qualified healthcare professional before  attempting active use of the wheelchair. DO NOT attempt to reach objects if you have to move forward in your seat.  DO NOT attempt to reach objects if you have to pick them up from the floor by reaching  between your knees. DO NOT lean over the top of the back upholstery to reach objects behind you, as this may  cause the wheelchair to tip over. ALWAYS shift your weight in the direction you are turning. DO NOT shift your weight  in the opposite direction of the turn. Shifting your weight in the opposite direction of the  turn may cause the inside drive wheel to lose traction and the wheelchair to tip over. DO NOT shift your weight or sitting position toward the direction you are reaching as the  wheelchair and/or seating system (if any) may tip over. DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may  occur. DO NOT use the footplates as a platform. When getting in or out of the wheelchair, make  sure that the footplates are in the upward position or swing footrests towards the outside ...

  • Page 17: Wheelchairs With Trro Or Trbkts Only

    SECTION 1—GENERAL GUIDELINES DO NOT attempt to stop a moving wheelchair with the wheel locks. Wheel locks are not  brakes. DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by  means of any removable (detachable) parts of the wheelchair may result in injury to the  user or damage to the wheelchair. DO NOT overtighten hardware attaching to the frame. This could cause damage to the  frame tubing. ALWAYS keep hands and fingers clear of moving parts to avoid injury. ALWAYS wear your seat positioning strap. The seat positioning strap is a positioning belt  ONLY. It is not designed for use as a safety device withstanding high stress loads such as  auto or aircraft safety belts. If signs of wear appear, belt MUST be replaced immediately. ALWAYS turn the wheelchair power off and engage the motor locks/clutches to prevent  the wheels from moving before attempting to transfer in or out of the wheelchair. Also  make sure every precaution is taken to reduce the gap distance. Align both casters parallel  with the object you are transferring onto. DO NOT use with a broken or missing joystick knob. DO NOT use if joystick does not spring back to the neutral position or becomes sticky or  sluggish. DO NOT use if joystick boot is torn or damaged. ALWAYS check foam grips for looseness before using the wheelchair. If loose, contact a  qualified technician for instructions. ALWAYS engage both wheel locks and reduce the gap distance before transferring to and  from the wheelchair. Turn all casters parallel to the object you are transferring onto. Avoid storing or using the wheelchair near open flame or combustible products. Serious  injury or damage to property may result. DO NOT engage or disengage the motor locks until the power is in the off position. Wheelchairs with TRRO or TRBKTS Only Only use the transport brackets included with TRRO and TRBKTS for the purposes  described in this manual. Tire Pressure DO NOT use your wheelchair unless it has the proper tire pressure (P.S.I.). DO NOT  overinflate the tires. Failure to follow these recommendations may cause the tire to ...

  • Page 18: Electrical

    SECTION 1—GENERAL GUIDELINES Electrical Grounding Instructions DO NOT, under any circumstances, cut or remove the round grounding prong from any  plug used with or for Invacare products. Some devices are equipped with three‐prong  (grounding) plugs for protection against possible shock hazards. Where a two‐prong wall  receptacle is encountered, it is the personal responsibility and obligation of the customer  to contact a qualified electrician and have the two‐prong receptacle replaced with a  properly grounded three‐prong wall receptacle in accordance with the National Electrical  Code. If you must use an extension cord, use only a three‐wire extension cord having the  same or higher electrical rating as the device being connected. In addition, Invacare has  placed RED/ORANGE warning tags on some equipment. DO NOT remove these tags. Batteries The warranty and performance specifications contained in this manual are based on the  use of deep cycle gel cell batteries. Invacare strongly recommends their use as the power  source for this unit. Carefully read battery/battery charger information prior to installing, servicing or  operating your wheelchair. Charging Batteries DANGER When using an extension cord, use only a three wire extension cord having at least 16 AWG (American Wire Gauge) wire and the same or higher electrical rating as the device being connected.

  • Page 19: Rain Test

    SECTION 1—GENERAL GUIDELINES DO NOT under any circumstances cut or remove the round grounding plug from the  charger AC cable plug or the extension cord plug. Rain Test Invacare has tested its power wheelchairs in accordance with ISO 7176 “Rain Test”. This  provides the end user or his/her attendant sufficient time to remove his/her power  wheelchair from a rain storm and retain wheelchair operation. DO NOT leave power wheelchair in a rain storm of any kind. DO NOT use power wheelchair in a shower.  DO NOT leave power wheelchair in a damp area for any length of time. Direct exposure to rain or dampness will cause the wheelchair to malfunction electrically  and mechanically; may cause the wheelchair to prematurely rust or may damage the  upholstery. Check to ensure that the battery covers are secured in place, joystick boot is NOT torn or  cracked where water can enter and that all electrical connections are secure at all times. DO NOT use if the joystick boot is torn or cracked. If the joystick boot becomes torn or  cracked, replace IMMEDIATELY. Weight Training Invacare DOES NOT recommend the use of its wheelchairs as a weight training  apparatus. Invacare wheelchairs have NOT been designed or tested as a seat for any kind  of weight training. If occupant uses said wheelchair as a weight training apparatus,  INVACARE SHALL NOT BE LIABLE FOR BODILY INJURY AND THE WARRANTY IS  VOID. Weight Limitation Refer to Typical Product Parameters for Typical Product Parameters on page 14 to  determine the weight limit (total combined weight of user and any attachments) of your  wheelchair model. DO NOT exceed the limit ‐ otherwise, injury or damage may result. Part No 1143190 TDX™ SP...

  • Page 20: Section 2-Emi Information

    SECTION 2—EMI INFORMATION CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POSSIBLE EFFECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR. Electromagnetic Interference (EMI) From Radio Wave Sources Powered wheelchairs and motorized scooters (in this text, both will be referred to as powered wheelchairs) may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two way radios, and...
  • Page 21 2) This device has been tested to a radiated immunity level of 20 volts per meter. 3) The immunity level of the product is unknown. Modification of any kind to the electronics of this wheelchair as manufactured by Invacare may adversely affect the EMI immunity levels. Part No 1143190 WARNING...

  • Page 22: Section 3-Safety/Handling Of Wheelchairs

    DO NOT climb, go UP or DOWN ramps or traverse slopes greater than 9°. Invacare strongly recommends proceeding down ramps or slopes slowly to avoid hard braking or sudden stops. DO NOT leave elevating legrests in the fully extended position when proceeding down ramps or slopes.

  • Page 23: Coping With Everyday Obstacles

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS WARNING DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. Many activities require the wheelchair user to reach, bend and transfer in and out of the wheelchair.

  • Page 24: A Note To Wheelchair Assistants

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS A Note to Wheelchair Assistants When assistance to the wheelchair user is required, remember to use good body  mechanics. Keep your back straight and bend your knees whenever tilting wheelchair or  traversing curbs or other impediments. Also, be aware of detachable parts such as arms or legrests. These must NEVER be used  to move the wheelchair or as lifting supports, as they may be inadvertently released,  resulting in possible injury to the user and/or assistant(s). When learning a new assistance technique, have an experienced assistant help you before  attempting it alone. Reaching, Leaning and Bending - Forward   WARNING DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees.

  • Page 25: Reaching, Bending - Backward

    A pinch point exists between head tube cap and walking beam (Detail “A”). A pinch point exists between walking beam/head tube cap and telescoping tube when TDX SP is at the lowest seat to floor height (Detail “B”). Pinch point may occur when rotating the footboard assembly (Detail “C”).

  • Page 26: Stairways

    MUST be removed and transported independently of the power wheelchair. Extreme caution is advised when it is necessary to move an unoccupied power wheelchair up or down the stairs. Invacare recommends using two assistants and making thorough preparations. Make sure to use ONLY secure, non-detachable parts for hand-hold supports.

  • Page 27: Transferring To And From Other Seats

    Transferring To and From Other Seats ALWAYS turn the wheelchair power OFF and engage the motor locks/clutches to prevent the wheels from moving before attempting to transfer in or out of the wheelchair. Also make sure every precaution is taken to reduce the gap distance. Align both casters parallel with the object you are transferring onto.

  • Page 28: Section 4-Safety Inspection/Troubleshooting

    SECTION 4—SAFETY INSPECTION/ TROUBLESHOOTING NOTE: Every six months take your wheelchair to a qualified technician for a thorough inspection  and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation  of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any  other vehicle. Routine maintenance will extend the life and efficiency of your wheelchair. Initial adjustments should be made to suit your personal body structure needs and  preference. Thereafter follow these maintenance procedures: Safety Inspection Checklists Inspect/Adjust Initially As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced. ❑ Ensure wheelchair rolls straight (no excessive drag or pull to one side). ❑ Inspect all fasteners. ❑ Inspect TRRO/TRBKTS fasteners and hardware. ❑...

  • Page 29: Inspect/Adjust Weekly

    ❑ Check pneumatic tires for proper inflation. ❑ Check center mount front riggings for worn/frayed belts and/or loose fasteners. If  found, replace these items. ❑ Check that all labels are present and legible. Replace if necessary. ❑ Inspect locking gas cylinders. ❑ Check that cables are routed and secured properly to ensure that cables DO NOT  become entangled and damaged during normal operation of seating system. Inspect/Adjust Weekly As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced. ❑ Wheels/casters have proper tension when wheels/casters are spun (when free‐ wheeling). Wheels/casters should come to a gradual stop. ❑ Ensure that casters are free of debris. ❑ Ensure all caster/wheel/fork/headtube fasteners are secure and not damaged/missing. ❑...

  • Page 30: Inspect/Adjust Periodically

    Inspect/Adjust Periodically ❑ Ensure wheelchair rolls straight (no excessive drag or pull to one side). ❑ Inspect all fasteners. ❑ Inspect TRRO/TRBKTS fasteners and hardware. ❑ Ensure clothing guards are secure. ❑ Arms are secure but easy to release and adjustment levers engage properly. ❑ Adjustable height arms operate and lock securely. ❑ Upholstery has no rips. ❑ Armrest pad sits flush against arm tube. ❑ Axle nut and wheel mounting nuts are secure on drive wheels. ❑ Wheels/casters have proper tension when wheels/casters are spun (when free‐ wheeling). Wheels/casters should come to a gradual stop. ❑ Ensure that casters are free of debris. ❑ Inspect foam handgrips for damage. If damaged, have them replaced by a qualified  technician. ❑ Inspect motor brushes and gearbox coupling (4 pole). ❑ Check center mount front riggings for worn/frayed belts and/or loose fasteners. If  found, replace these items. ❑ Check that all labels are present and legible. Replace if necessary. ❑ Inspect electrical components for signs of corrosion. Replace if corroded or damaged. Inspect/Adjust Every 18 Months ❑...

  • Page 31: Troubleshooting - Electrical

    Troubleshooting - Electrical NOTE: For additional troubleshooting information and explanation of error codes, refer to the  individual Electronics Manual supplied with each wheelchair. SPJ™+, SPJ+ w/PSS or SPJ+ w/ACC Joysticks The joystick information gauge and the service indicator give indications of the type of  fault or error detected by the control module. When a fault is detected, the wheelchair  may stop and not drive. The LEDs on the information gauge may flash in a particular  pattern or the service indicator light will flash. The number or type of flashes indicates the  nature of the error. If multiple errors are found, only the first error encountered by the  control module will be displayed. Information Gauge Display Diagnostics DISPLAY DESCRIPTION Information Gauge Display All LEDs are off. All LEDs are on. Left RED LED is flashing. Left to Right “chase”...

  • Page 32: Service Indicator Light Diagnostics

    Check to make sure joystick is connected properly. Contact Invacare/Dealer for service. Contact Invacare/Dealer for service. Contact Invacare/Dealer for service. Contact Invacare/Dealer for service. Wrong type of remote connected. Contact Invacare/Dealer for service. PROBABLE CAUSE Motor lock levers disengaged Engage motor lock levers. Refer to (Error code E9 or E10).
  • Page 33 (Error code W05). Battery failure. Have batteries checked for shorted cell. Replace if necessary. Electrical malfunction. Contact Dealer/Invacare for service. Battery failure. Check batteries for shorted cell. Replace if necessary. Malfunctioning battery charger. Contact Dealer/Invacare for Service.

  • Page 34: Checking Battery Charge Level

    Checking Battery Charge Level The following “Do’s” and “Don’ts” are provided for your convenience and safety. DON’T Don’t perform any installation or maintenance without first reading this manual. Don’t perform installation or maintenance of batteries in an area that could be damaged by battery spills. Don’t make it a habit to discharge batteries to the lowest level.

  • Page 35: Section 5-Wheelchair Operation

    SECTION 5—WHEELCHAIR OPERATION After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Set-up of the Electronic Control Unit is to be performed only by a qualified techni- cian.
  • Page 36 The joystick has proportional drive control, meaning that the further it is pushed from the  upright (neutral) position, the faster the wheelchair moves. The maximum speed,  however, is limited by the setting of the speed‐control knob. To slow the wheelchair to a stop, simply release the joystick. The wheelchair has  automatic speed and direction compensation to minimize corrections. When first learning to drive, select a slow speed and try to drive the wheelchair as slowly  as possible by pushing the joystick slightly forward. This exercise will help you learn to  utilize the full potential of the proportional control and allow you to start and stop  smoothly. To drive the wheelchair, perform the following: 1. Adjust speed control knob to the appropriate setting. 2. Turn the power On. Refer to Turning the Power On/Off on page 35. 3. Maneuver the joystick in the following manner: MOVEMENT ACTION FORWARD Push joystick forward, towards the front of the wheelchair. REVERSE Pull joystick back, towards the rear of the wheelchair. Turn RIGHT Move joystick toward the right side of the wheelchair.

  • Page 37: Spj+, Mk6I™ Spj+ W/Pss And Mk6I Spj+ W/Acc Joystick Switches And Indicators

    SPJ+, MK6i™ SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators NOTE: For the following information, refer to FIGURE 5.3. On/Off Button Decrease Speed Button (Tortoise) GREEN *NOTE: The mode button is only  present on SPJ+ w/ACC joystick. FIGURE 5.3 SPJ+, MK6i™ SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators On/Off Button This button is located at the front of the joystick housing. It is used to turn the wheelchair  On and Off, to remove the joystick from sleep mode (if programmed) and to lock or ...

  • Page 38: Speed Control Buttons

    Speed Control Buttons The speed control buttons (tortoise button ( adjust the maximum speed. 1. To adjust the speed, perform one of the following: • Adjust Speed in 20% Increments (5 Speed Mode) ‐ Press the tortoise button ( or hare button ( ) to decrease/increase the speed in 20% increments. The larger  bars in the speedometer will light. • Adjust Speed in Smaller Increments (VSP Mode) ‐ Perform the following steps: i. Press and hold both the tortoise button ( joystick beeps. ii. Perform one of the following: • Press the tortoise button ( speed in 20% increments. The larger bars in the speedometer will light. • Press and hold the tortoise button ( increase the speed in smaller increments. The smaller bars in the  speedometer will light. Joystick The joystick has proportional drive control, meaning that the further the joystick is  pushed from the upright (neutral) position, the faster the wheelchair or seat moves. Your  top speed, however, is limited by the programmed settings. To slow the wheelchair to a stop, simply release the joystick. The wheelchair has  automatic speed and direction compensation to minimize corrections. Charger/Programming Input The charger/programming input is located at the front of the joystick housing. This  provides easy access for charging the wheelchair batteries. This port also serves as the  Remote Programmer Communication connection. Driving is prevented while the system  is charging. Service Indicator The AMBER service indicator will light when an error or fault occurs. Refer to Service ...

  • Page 39: Information Gauge Display

    Information Gauge Display The information gauge display is located on the front of the joystick housing and provides  the following information to the user on the status of the wheelchair: 1. Power is On. 2. True state‐of‐battery‐charge, including notification of when the battery requires  charging: A. GREEN LEDs are lit, indicating well charged batteries. B. AMBER LEDs are lit, indicating batteries are moderately charged. Recharge  batteries before taking a long trip. C. RED LEDs are lit, indicating batteries are running out of charge. Recharge batteries  as soon as possible.  The Information Gauge display also serves as a system diagnostic device when a fault is  detected by the control module. A specific number of flashes of the LEDs indicate the type  of fault detected. Refer to Service Indicator Light Diagnostics on page 30 for the  diagnostic indications of the wheelchair status. MPJ+ Joystick Switches and Indicators NOTE: For this procedure, refer to FIGURE 5.4 on page 40. Drive Select Toggle Switch The drive select toggle switch is located on the left side, below the LCD. The drive select  position is momentary, meaning that it will return to the neutral position after a selection  is made. This switch allows the operator to select the type of operation or performance which best  suits a particular control need or situation. The DRIVE 1 program uses performance  values which are independent of those used for the DRIVE 2 or 3 or 4 program. As an ...

  • Page 40: Speed Control

    Charger/Programming Input (Front of Joystick) Drive Select Toggle Switch Programmable Joystick Mono Port 1/2 or External Mode Switch FIGURE 5.4 MPJ+ Joystick Switches and Indicators Speed Control The speed control knob is located on the side of the joystick housing.  1. Rotate the knob clockwise (forward) to increase the speed of the wheelchair to the  programmed max speed. 2. Rotate the knob counterclockwise (backward) to decrease the speed of the wheelchair  to the programmed max speed. Joystick The joystick has proportional drive control, meaning that the further the joystick is  pushed from the upright (neutral) position, the faster the wheelchair or seat moves. Your  top speed, however, is limited by the programmed settings. To slow the wheelchair to a stop, simply release the joystick. The wheelchair has  automatic speed and direction compensation to minimize corrections. Charger/Programming Input The charger/programming input is located at the front of the joystick housing. This ...
  • Page 41 Splash Screen NOTE: For this procedure, refer to   FIGURE 5.5. This screen is displayed at startup of the  joystick for about 2 seconds. This screen  displays the software version and date  information. After this screen, the joystick displays the  Main Screen. Main Screen NOTE: For this information, refer to FIGURE 5.6 on page 42. During normal operation, the active drive is displayed in the upper half of the LCD  display. Battery charge level is shown in the Battery Gauge Display (BGD) located on the  right side of the LCD display. At full charge, solid blocks fill in all ten segments between  E (Empty) and F (Full). As the battery becomes discharged, the top most segments will  progressively disappear until no segments appear between E and F. At this level, the user  should charge the batteries as soon as possible. The lower half of the LCD display is the Information Center. The Information Center  displays current data on the wheelchair. Refer to LCD Display table on page 41 for descriptions of information shown. ITEM DRIVE NAME This field shows the currently selected Drive’s Name. Available choices are as follows: *NOTE: Drive names can be customized.
  • Page 42 ITEM STATUS INDICATOR The status indicator will show a “Warning” (exclamation point inside a triangle) indicator when the chair has a condition that requires attention. The status indicator will show a “STOP” sign when a serious condition exists. The chair will not be allowed to operate. The status indicator shows an Attendant Icon if the attendant’s override switch is active.

  • Page 43: Programmable Mono Port 1/2 Or External Mode Switch

    Connected Devices Screen NOTE: For this procedure, refer to FIGURE 5.8. This screen is displayed if the Mode Select switch is held active for about 10 seconds. This  screen shows an icon that represents any additional devices that are connected to the  chair. FIGURE 5.8 LCD Display Screens - Connected Devices Screen Programmable Mono Port 1/2 or External Mode Switch The programmable mono port or external mode switch input is located at the rear of the  joystick on the left side. The programmable mono port input offers the choice of three  options: • Remote drive select • Remote stop/mode (reset) input • Single actuator input The single switch functions operate through mono port 1. An optional y‐cable allows a  second programmable function through mono port 2. Remote Stop Switch The remote stop switch is used to stop the wheelchair. Remote Mode (Reset) Switch The remote mode reset switch functions the same way as the mode switch. Refer to Mode ...

  • Page 44: Remote On/Off Switch

    SECTION 5—WHEELCHAIR OPERATION Remote On/Off Switch The remote On/Off switch input is located at the rear of the joystick on the right side and  allows the power switch to be operated by an ability switch (normally open momentary  switch with mono plug). To use the remote On/Off feature, the Drive Select/On/Off switch  must be in the On position. Each activation of the ability switch will alternately turn the  joystick On or Off. Mode Switch NOTE: For this procedure, refer to FIGURE 5.4 on page 40. The mode switch is used to select the operating mode for the wheelchair. The mode  switch is located on the joystick. A mode switch is needed whenever any of the following  operating modes are programmed: • Environmental Controls (ECU 1, ECU 2, ECU 3, ECU 4)* • 3 Speed Mode in Digital 3 Speed (Slow, Medium, Full) • Latched Modes • Sleep Mode • RIM Mode* • Remote Drive Selection Mode* • Tilt/Recline Mode* • Information Center Display Selection (does not require Reset activation at power up) If any of the above modes are selected, the control will require activation of the switch  immediately after the power switch is turned On in order to enter the drive mode. The  second line of the LCD will display ‐ PRESS RESET. *NOTE: In these modes, Standby Select allows the reset switch to be bypassed for users unable to  activate the switch. Memory Card Slot The memory card slot is used with the basic or professional memory card for saving or ...

  • Page 45: Repositioning Joystick

    Repositioning Joystick Van Seats NOTE: For this procedure, refer to FIGURE 5.9. NOTE: Take note of position and orientation of mounting hardware for reinstalling the joystick  assembly. 1. Turn the adjustment lock lever to release the joystick mounting tube from the  mounting bracket. 2. Remove the joystick mounting tube from the wheelchair. 3. Remove the three hex mounting screws, bushings and locknuts that secure the  mounting bracket to the three mounting holes on the armrest plate. NOTE: The mounting bracket is mounted to the inside of the armrest plate. 4. Reposition the mounting bracket on the opposite armrest plate. 5. Using the three hex mounting screws, bushings and locknuts secure the mounting  bracket to the three mounting holes of the armrest plate. 6. If necessary, perform the following to reposition the adjustment lock: A. Slide the adjustment lock from the mounting bracket.  B. Rotate adjustment lock 180° and slide adjustment lock over the opposite end of the  mounting bracket. 7. Slide joystick mounting tube through the mounting bracket to the desired position  and secure adjustment lock to tube by turning lever on adjustment lock. Mounting Bracket Armrest Plate Bushings Locknuts FIGURE 5.9 Repositioning Joystick - Van Seats Part No 1143190 Hex Mounting Screws Adjustment Lock Lever...

  • Page 46: Adjustable Asba Seats

    Adjustable ASBA Seats NOTE: For this procedure, refer to  FIGURE 5.10. 1. Turn the adjustment lock lever to  release the joystick mounting tube from  the mounting bracket. 2. Remove the joystick from the wheelchair. 3. Remove the three hex screws that  secure both halves of the mounting  bracket to the arm tube. 4. Reposition mounting bracket on  opposite arm tube ensuring the  threaded plate of the mounting bracket  is on the inside of the arm tube as  shown in FIGURE 5.10. 5. Using the three hex mounting screws and washers, secure both halves of the mounting  bracket to the arm tube. 6. Slide the joystick mounting tube through the mounting bracket to the desired position. 7. Turn the adjustment lock lever to secure the joystick mounting tube into the mounting  bracket. Disconnecting/Connecting the Joysticks NOTE: For this procedure, refer to FIGURE 5.11 on page 47. NOTE: The joystick connector is located at the rear of the seat frame. SPJ+ Joysticks Disconnecting 1.

  • Page 47: Mpj+ Joysticks

    WARNING The excess joystick cable must be coiled, and tie-wrapped to the rear of the seat frame to ensure that cable does NOT become entangled or damaged during normal operation of seating sys- tem - otherwise injury or damage may result.

  • Page 48: Section 6-Motor Locks

    SECTION 6—MOTOR LOCKS After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced.

  • Page 49: Section 7-Wheel Locks

    SECTION 7—WHEEL LOCKS SECTION 7—WHEEL LOCKS WARNING After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. CAUTION DO NOT use the wheel locks when the wheelchair power is on and the clutches are engaged - otherwise damage to the wheelchair may result.

  • Page 50: Section 8-Footboard Assembly

    SECTION 8—FOOTBOARD ASSEMBLY After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service, verify that ON/OFF switch on the joystick is in the OFF position. DO NOT stand on the flip-up footboard.

  • Page 51: Adjusting The Footboard Angle

    Washer Spacer FIGURE 8.1 Removing/Installing the Footboard Adjusting the Footboard Angle NOTE: For this procedure, refer to FIGURE 8.2. 1. Loosen the jam nut and set screw  located underneath on the rear of the  footplate. 2. Adjust the mounting screw in or out to  obtain the desired footboard angle. 3. Thread the jam nut inward until it is  flush with the footboard bracket. 4. Securely tighten the jam nut and washer  to secure the mounting screw in place. Part No 1143190 Footboard Support Washers Socket Head Screw Locknut Jam Nut Footboard FIGURE 8.2 Adjusting the Footboard Angle Footboard Assembly Set Screw...

  • Page 52: Section 9-Forks

    SECTION 9—FORKS After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced.

  • Page 53: Section 10-Batteries

    WARNING The use of rubber gloves is recommended when working with batteries. Invacare strongly recommends that battery installation and battery replacement always be done by a qualified technician. After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result.

  • Page 54: Using The Proper Batteries

    Using the Proper Batteries 1. Position battery on ground/flat surface as shown below. 2. Visually inspect the battery to ensure proper polarity: FOR TDX SP WHEELCHAIRS USING 22NF BATTERIES Batteries with terminal configuration (POSITIVE on the left and NEGATIVE on the right) as shown below MUST be used. Batteries that have the reverse terminal configuration MUST not be used - otherwise injury and damage may occur.

  • Page 55: Replacing Batteries

    Replacing Batteries NOTE:  For this procedure, refer to FIGURE 10.1 on page 56. NOTE: The following tools are required to perform this procedure: • Wire Cutter 1. Remove the batteries from the wheelchair. Refer to Removing/Installing the Batteries  From/Into the Wheelchair on page 57. 2. Cut the tie‐wraps that secure the battery terminal covers to the battery terminals. 3. Slide the RED battery terminal cover back on the RED battery cable to expose the  POSITIVE battery terminal. 4. Slide the BLACK battery terminal cover back on the BLACK battery cable to expose  NEGATIVE battery terminal. NEVER allow any of your tools and/or battery cable(s) to contact BOTH battery post(s) at the same time. An electrical short may occur and serious personal injury or damage may occur.
  • Page 56 22NF Batteries BATTERY COVER AND TIE-WRAP DETAIL RED Battery Terminal Cover Cover BLACK Cover Tie-Wrap Battery Wiring Harness Bracket of POSITIVE Battery Cable FOR FRONT BATTERY FOR REAR BATTERY Bracket of POSITIVE Battery Cable POSITIVE (+) Battery Terminal /Post 22NF Battery FIGURE 10.1 Replacing Batteries TDX™...

  • Page 57: Cleaning Battery Terminals

    Cleaning Battery Terminals Most batteries are not sold with instructions. However, warnings are frequently noted on the cell caps. Read them carefully. DO NOT allow the liquid in the battery to come in contact with skin, clothes or other possessions. It is a form of acid and harmful or damaging burns may result. Should the liquid touch your skin, wash the area IMMEDIATELY and thoroughly with cool water.
  • Page 58 7. Disconnect the controller from the batteries at the rear of the wheelchair. 8. Remove the batteries. Removing the Batteries from Wheelchair on page 59. Mounting Rear Shroud Screws Controller Mounting Screw and Washer (Wheelchairs with Footboard Only) FIGURE 10.2 Removing the Front Shroud/Battery Retention Bracket and Rear Shroud - Installing the Front Shroud/Battery Retention Bracket and Rear Shroud TDX™ SP DETAIL “A”...

  • Page 59: Removing The Batteries From Wheelchair

    Removing the Batteries from Wheelchair NOTE: For this procedure, refer to FIGURE 10.3 on page 59. 1. Slide battery tray with batteries out. 2. Disconnect the battery straps. 3. Unplug front battery from rear battery. 4. Remove the front battery. 5. Slide the rear battery forward and remove it from the tray. NOTE: Battery tray  shown removed for  clarity. FIGURE 10.3 Removing the Batteries from Wheelchair Installing Batteries into Wheelchair NOTE: For this procedure, refer to FIGURE 10.3 and FIGURE 10.4 on page 60. NOTE: Positioning of the batteries into the battery tray is completed with battery tray positioned  in wheelchair and partially pulled out. Refer to FIGURE 10.3 for full view of wheelchair base.  Illustrations in FIGURE 10.4 on page 60 are shown without the wheelchair for clarification  purposes only. ...

  • Page 60: Installing The Front Shroud/Battery Retention Bracket And Rear Shroud

    5. Slide the battery tray into the wheelchair (FIGURE 10.3). 6. Install the battery door and rear shroud. Refer to Installing the Front Shroud/Battery  Retention Bracket and Rear Shroud on page 60. Battery with Battery Connector Bracket NOTE: 22NF Batteries  shown. Rear of the Battery Tray Rear Battery FIGURE 10.4 Installing Batteries into Wheelchair Installing the Front Shroud/Battery Retention Bracket and Rear Shroud Wheelchairs with TRRO or TRBKTS Only - Battery retention brackets MUST be installed at all times.

  • Page 61: When To Charge Batteries

    5. Reinstall the rear shroud and secure in place with three mounting screws. NOTE: New Batteries MUST be fully charged before using, otherwise the life of the battery(ies)  will be reduced. 6. If necessary, charge the batteries. Refer to Charging Batteries on page 62. When to Charge Batteries SPJ+, SPJ+ w/PSS and SPJ+ w/ACC Joysticks NOTE: For this procedure, refer to FIGURE 10.5. The Information Gauge Display located on the front of the joystick housing, it provides  the state‐of‐battery charge, including notification of when the battery requires charging.  It also provides the following information to the user on the status of the wheelchair: A. GREEN LEDs are lit, indicating well  charged batteries. B. AMBER LEDs are lit, indicating  batteries are moderately charged.  Recharge batteries before taking a  long trip. C. RED LEDs are lit, indicating  batteries are running out of charge.  Recharge batteries as soon as  possible.  MPJ+ Joystick NOTE: For this procedure, refer to FIGURE 10.6 on page 61. The far right side of the display screen is the Battery Gauge Display (BGD). It provides ...

  • Page 62: Charging Batteries

    The amount of electrical current drawn within a given time to charge a battery is called  the “charge rate”. If, due to usage, the charge stored in the battery is low, the charge rate  is high, as indicated by the GREEN light on the charger. Initially, the GREEN light will  stay illuminated for a short period of time followed by a longer period of off time. As a  charge builds up, the charge rate is reduced, and the GREEN light will stay illuminated  for a longer period of time followed by a shorter off time.  NEVER leave the charger unattended when the breaker has tripped. A fault condi- tion exists. Unplug and discontinue using immediately. Contact an Invacare dealer. NOTE: If performing the charging procedures independently, READ and CAREFULLY follow the  individual instructions for each charger (supplied or purchased). TDX™ SP WARNING CAUTION WARNING Part No 1143190...
  • Page 63 TOOL Battery Charger Extension Cord 1. Attach the battery charger connector to the charger port on the joystick. 2. Plug the charger’s AC power cord, or extension, into the grounded 120 VAC wall  outlet. 3. Wait until charging is complete. NOTE: Allow eight hours for normal charging. Larger batteries (greater than 55 ampere‐hours) or  severely discharged batteries may require up to sixteen hours to be properly charged and equalized. NOTE: It is advantageous to recharge frequently rather than only when necessary. In fact, a  battery’s life is extended if the charge level is maintained well above a low condition. NOTE: If the batteries need to be charged more often or take longer to charge than normal, they  may need to be replaced. Contact an Invacare dealer for service. SPJ+, SPJ+ w/PSS and SPJ+ w/ACC Joysticks Part No 1143190 QUANTITY Charger/ Programming Port FIGURE 10.7 Charging Batteries COMMENTS Supplied Not Supplied...

  • Page 64: Section 11-Transport Ready Package (Trro)

    NOTE: The information in this section is for wheelchairs ordered with the transport ready package  ONLY. WARNING Contact Invacare Corporation (800-333-6900) with any questions about using this wheelchair for seating in a motor vehicle. When feasible, wheelchair occupants should transfer into the vehicle seat and use the OEM (Original Equipment Manufacturer) vehicle-installed restraint system.

  • Page 65: About Transport Ready Packages

    WC/19 compliant. Refer to Removing/Installing the Batteries From/Into the Wheelchair on page 57. About Transport Ready Packages TRRO includes four factory‐installed transport brackets and a wheelchair anchored  pelvic belt. TRRO has been crash‐tested in accordance with ANSI/RESNA WC Vol 1  Section 19 Frontal Impact Test requirements for wheelchairs with a 168 lb crash dummy,  which corresponds to a person with a weight of 114 to 209 lbs. TRBKTS includes four factory‐installed wheelchair transport brackets. TRBKTS has not  been crash‐tested in accordance with WC 19. Use these transport brackets only to secure  an unoccupied wheelchair during transport. As of this date, the Department of Transportation has not approved any tie‐down systems  for transportation of a user while in a wheelchair, in a moving vehicle of any type. It is  Invacare’s position that users of wheelchairs should be transferred into appropriate  seating in vehicles for transportation and use be made of the restraints made available by  the auto industry. Invacare cannot and does not recommend any wheelchair  transportation systems. Compliance Information This wheelchair conforms with the requirements of the ANSI/RESNA WC/Vol. 1 ‐ Section  NOTE: ANSI = American National Standards Institute, RESNA= Rehabilitation Engineering  and Assistive Technology Society of North America. This wheelchair has been dynamically tested in a forward‐facing mode with the specified  crash test dummy, which corresponds to a person with a weight of 114‐209 pounds,  restrained by BOTH pelvic and upper‐torso belts in accordance with ANSI/RESNA WC  Vol 1 Section 19. BOTH pelvic and upper‐torso belts should be used to reduce the ...

  • Page 66: Specifications

    Specifications MODEL TDX SP HD TDX SP Securing the Wheelchair to the Vehicle Positioning the Wheelchair in the Vehicle This wheelchair must be in a forward facing position during travel in a motor vehicle. The recommended clear zones for wheelchair seated occupants restrained by BOTH pelvic and upper-torso belt(s) and ONLY by a pelvic belt are shown in the diagrams and described below.

  • Page 67: Securement Points

    SECTION 11—TRANSPORT READY PACKAGE (TRRO) Securement Points Tie-Down Tie-Down Brackets Bracket Tie-Down Bracket FIGURE 11.1 Securement Points Securing the Wheelchair This wheelchair is to be used only with Wheelchair Tie‐down and Occupant Restraint  Systems (WTORS) that have been installed in accordance with the manufacturerʹs  instructions and SAE J2249. NOTE: A copy of SAE J2249 Wheelchair Tie‐down and Occupant Restraint Systems (WTORS)  for use in Motor Vehicles can be obtained from: SAE International, 400 Commonwealth Drive,  Warrendale, PA 15096‐0001, (877) 606‐7232 or (724) 776‐4970. Attach WTORS to the tie‐down brackets in accordance with the manufacturerʹs  instructions and SAE J2249. Part No 1143190 TDX™ SP...

  • Page 68: Securing The Occupant

    Securing the Occupant Wheelchair-Anchored Belts The pelvic belt that is provided by Invacare has been tested for use in a motor vehi- cle on this wheelchair ONLY. DO NOT replace the pelvic belt with a different style pelvic belt. NOTE: For this procedure, refer to FIGURE 11.2 on page 69.
  • Page 69 SECTION 11—TRANSPORT READY PACKAGE (TRRO) DETAIL “A” Pelvic Belt (Used to secure the vehicle anchored upper-torso belt) Male End DETAIL “B” - ADULT SEATS DETAIL “C” - JUNIOR SEATS Back Angle Bracket Large End of Slot Belt Mounting Bracket Belt Mounting Bracket Large End of Slot...

  • Page 70: Vehicle-Anchored Belts

    Vehicle-Anchored Belts NOTE: For this procedure, refer to FIGURE 11.3. With regard to accommodating the use and fit of vehicle‐anchored belts, this wheelchair  has an overall rating of: • TDX SP Adult ‐ A • TDX SP Junior ‐ B This rating is scored as follows: RATING Excellent Good Fair Poor The test for Lateral Stability Displacement for Point (P) is shown in FIGURE 11.3. The  average test result for point (P) is: • TDX SP with Two 22NF Batteries ‐ • TDX SP Adult ‐ 0.53‐inches (13.4 mm) • TDX SP Junior ‐ 0.57 inches (14.4 mm) • TDX SP with Two GP24 Batteries ‐ • TDX SP Adult ‐ 0.54‐inches (13.7 mm) • TDX SP Junior ‐ 0.51 inches (12.95 mm) Point (P) Test Platform FIGURE 11.3 Vehicle-Anchored Belts Seating System This wheelchair has been tested for seating in a motor vehicle with the factory installed seating system ONLY.

  • Page 71: Positioning Belts

    Positioning Belts The angle of the pelvic belt should be within the preferred zone of 45 to 75 degrees to the horizontal OR within the optional zone of 30 to 45 degrees to the horizontal. Steeper side-view pelvic belt angles are especially important if the pelvic belt is intended to be used for postural support in addition to occupant restraint in a...

  • Page 72: Limited Warranty

    Invacare warrants all batteries for a period of six (6) months from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.
