Summary of Contents for Liebert UPStation S VM12000
- Page 1 ® UPStation S Power Protection User Manual English...
- Page 2 UPS control circuit automatically tests them. The UPS displays an alarm message if there is a battery charger problem or if the battery fails a test. Call Liebert at 1-800- 222-5877 for battery maintenance or replacement. When replacing batteries, use the same number and type of batteries.
- Page 3 Porter toujours des vêtements protecteurs ainsi que des lunettes de protection pour les yeux. Si I’électrolyte entre en contact avec la peau, nettoyer immédiatement en rinçant avec de I’eau. Si I’électrolyte entre en contact avec les yeux, arroser immédiatement et généreusement avec de I’eau. Demander pour de I’aide médicale.
-
Page 4: Table Of Contents
Terminal/Modem Connection ... 28 RS-232 with User-Configurable Relays ... 29 Cables ... 29 External Battery Cabinets ... 30 ROUTINE MAINTENANCE ... 31 LIEBERT UPSTATION S™ SPECIFICATIONS... 31 APPENDIX ... 32 NEC Wire Gauge Chart ... 32 3.5 kVA Battery Run Times... 33 6 - 8 kVA Battery Run Times... - Page 5 Liebert UPStation S™ SITE PLANNING DATA...
-
Page 6: Introduction
INTRODUCTION The Liebert UPStation S™ Uninterruptible power supply (UPS) system protects valuable equipment, data, and processes from utility power disturbances. performance, on-line, microprocessor-controlled design ensures clean, regulated, sinewave power to loads regardless of utility power fluctuations. An internal battery provides power to loads during utility power outages. -
Page 7: Installation
AND EMI FILTER L1, L2 3.5 - 6 kVA Liebert UPStation S™ systems include the UPS and the AC unit. The unit provides connection to both utility power and UPS output power through the use of a simple Maintenance Bypass Switch. -
Page 8: 3.5-6 Kva Start-Up Checklist
Press Alarm Silence Button to silence the alarm. message appears, contact Liebert at 1-800-222-5877. 16. Turn ON Output Circuit Breaker on back of UPS by turning it OFF, then ON again to reset it. Press the front panel ON button. -
Page 9: 8-18 Kva Connections
8 –12 kVA Liebert UPStation S™ wiring, circuit AC Input Optional Dual AC Input AC Output Ground and GEC 15 - 18 kVA Liebert UPStation S™ AC Input Optional Dual AC Input AC Output Optional Ext. Battery Cabinet Ground and GEC... -
Page 10: 8 - 18 Kva Start-Up Checklist
After configuration, automatic self-tests begin. If self- tests are OK, a horn sounds and the ”Close Breaker then Press ON” message appears. message appears, contact Liebert at 1-800-222-5877. 10. Close (turn ON) Output circuit breaker on back of UPS and press the ON button. -
Page 11: Normal Operation
OPERATION Control / Display Panel The control panel includes tactile pads (dome buttons) and a menu-driven LCD (liquid crystal display). The display provides full metering, present status, and alarms, if any. See figure on right. Control Buttons ON Button - This button turns on the UPS inverter. It supplies power to the output if the Output Circuit Breaker is closed. -
Page 12: Table #2 Factory Default Settings
User Menus - The Main Menu allows these options: Configuration UPS Meters Event Log Test Options Power Management The Configuration option allows review or change of the following settings: Configuration Setting Input Voltage Input Frequency Output Voltage Output Frequency Low Battery Warning Time Auto Battery Test Total UPS Runtime Input Wiring... -
Page 13: Lcd Menu Tree
Configuration Change Review Settings UPS RATING INPUT VOLTAGE INPUT VOLTAGE 200/100 INPUT FREQUENCY 220/110 OUTPUT VOLTAGE 230/115 OUTPUT FREQUENCY 240/120 LOW BATTERY WARNING TIME 220/127 AUTO BATTERY TEST SETTINGS 208/120 TOTAL UPS RUNTIME INPUT FREQUENCY ADVANCE CONFIGURATION 50 Hz 60 HZ Input Wiring Output Wiring OUTPUT VOLTAGE... -
Page 14: System Start-Up
System Start-Up Manual Restart after Manual Off If Manual Restart has been selected (rather than Auto- Restart) and someone has turned the unit off, the Output Circuit Breaker will probably be closed. Just press the ON button to turn on the UPS inverter. Auto-Restart The factory enables this feature. -
Page 15: Maintenance Bypass Operation
See the alarm chart in the Appendix for alarm message meanings and corrective actions. Perform the corrective action described for a specific alarm. contact Liebert at 1-800-222-5877. UPS now supplies System Shutdown An optional switch with 50 feet of cable is... -
Page 16: Options
Contact your Liebert UPS distributor for option availability and ordering information. Distribution Configurable Distribution (CD) An optional enclosure hardwires to 3.5 - 12 kVA units and accommodates up to eight Standard or Power Management Load Modules. It may be wall or floor-mounted and includes a 70 Amp circuit breaker. Refer to drawings below. -
Page 17: Load Modules
Load Modules Load Modules for 3.5 to 12 kVA units offer a variety of power receptacles when used in conjunction with the Configurable Distribution. Each Load Module includes: Circuit Breaker Green output receptacle(s) power indicator 1 or 2 Output Receptacles. Hard Wire (terminal block) Load Modules provide a knockout to attach flexible conduit (see drawings to the right). - Page 18 On-Line When the rotary switch is placed in the On-Line position, contacts A and C are closed with contact B open. The standard Liebert UPStation S™ is powering the critical load as illustrated below. Standard Features A locking handle prevents unauthorized access.
- Page 19 Test When the rotary switch is placed in the Test position, contacts A and B are closed and C is open. The power for the load is now coming from the maintenance bypass source, as illustrated in below. The connection from the output of the UPS is open. Input power to the UPS is still available for testing and troubleshooting purposes.
- Page 20 Insure that the system ordered is what was received prior to mounting. Mounting The Liebert UPStation S™ Maintenance Bypass Cabinet is designed for wall mount only. Prior to installation, verify that the wall can support the weight of the bypass cabinet.
- Page 21 5. The UPStation S must have an internal bypass for system to operate according to specifications. The 8-18 kVA Liebert UPStation S™ allows the customer to connect a three-phase input if desired. The only benefit to connecting a third phase is to balance a three-phase feed transformer.
- Page 22 Input and output terminal blocks are provided on the back of the 8-12 kVA Liebert UPStation S™ as illustrated below. Conduit can be landed on the rear or bottom of the UPS. Note that side, rear, front and top access is required for service on all Liebert UPStation S™...
- Page 23 TB1 L2 to TB3 L2 Rotate the bypass switch to the On-Line position. Transfer the Liebert UPStation S™ to the UPS mode by placing the bypass/UPS switch on the back of the unit in the UPS position and pressing the ON button on the front of the unit.
- Page 24 Troubleshooting Troubleshooting should only be performed by a trained engineer authorized by. If you cannot resolve a problem, consult Liebert immediately at 1-800-222-5877. Do not Close the input continue to use the maintenance bypass cabinet if it is not performing according to specifications.
-
Page 25: Power Management
Use Power Management to program power to individual loads to turn OFF or ON at specific times or as a result of specific events. Only Load Modules with Power Management circuitry respond to Power Management programming. Power Management enables you to selectively turn programmable Load Modules (receptacles) off and on to conserve energy, extend battery time, or control network devices based on:... -
Page 26: Power Management Programming Elements
Selected program steps become active as soon as they are entered Maintain a chart of selections. Change the chart when you change the program. For assistance call Liebert at 1-800-222-5877. Sample Programs Refer to Sample Programs #1 and #2 on the following pages. -
Page 27: Power Management Sample #1
POWER MANAGEMENT SAMPLE #1 Objective: Save energy by turning OFF computers after hours. Specifically, turn ON all loads except load 03 at 7:00 a.m. and then turn them OFF at 6:00 p.m. every workday (M-F). Remain off during the weekend. Define Parameters Start Closure... -
Page 28: Remote Emergency Power Off (Repo) Cable
SiteNet 2 Power Surveillance This option includes software to enable UPS monitoring and control from a remote computer or workstation. Contact a Liebert UPS supplier for more details including availability for your computer or workstation SiteNet SNMP (Simple Network Management Protocol) The SiteNet SNMP internal agent allows for direct network UPS management in an Ethernet environment. -
Page 29: Rs-232 With User-Configurable Relays
Use the following Modem Mode configuration screen to control modem operations: Modem Mode: IN 1-(000) 000-0000 Site ID: Your Location The options of the first line of this screen are IN, OUT, BOTH, or OFF. IN calls are from a remote terminal operator to the UPS. -
Page 30: External Battery Cabinets
External Battery Cabinets WARNING: Remove UPS battery fuses and open the Battery Cabinet circuit breaker before removing the battery cable connectors cover plate. These connectors contain lethal voltages when the circuit to the battery is complete. Standard External Battery Cabinets Matching stand-alone cabinet(s) can be provided with additional string(s) of low-maintenance batteries for additional back-up time in conjunction with the UPS internal battery. -
Page 31: Routine Maintenance
The Liebert UPStation S™ UPS should operate for years with minimum maintenance. Keep UPS clean and cool to enhance system reliability. Occasionally vacuum dust from around ventilation grilles and wipe UPS with a dry cloth. Do not use liquid or aerosol cleaning fluids. -
Page 32: Appendix
Allowable Ampacities of Insulated Conductors Rated 0 – 2000 Volts, 60° to 90°C (140° to 194°F), not more than three conductors in Raceway or Cable or Earth (Directly Buried), Based on Ambient Temperature of 30°C (86°F) Size AWG kcmll 60 C° (140°F) 75°C (167°F) Types: TW*, UF* Types: FEPW*,... -
Page 33: Kva Battery Run Times
UPStation S 3.5 kVA Battery Run Times #1 Internal Batteries +(1) VBD061 Cabinet Internal Batteries +(1) VBS062 Cabinet Internal Batteries +(1) VBS 061 Cabinet Internal Batteries Only PERCENT LOAD UPStation S 4.5 kVA Battery Run Times #1 Internal Batteries +(1) VBD061 Cabinet Internal Batteries +(1) VBS062 Cabinet Internal Batteries... -
Page 34: Kva Battery Run Times
UPStation S 6 kVA Battery Run Times #1 Internal Batteries +(1) VBD061 Cabinet Internal Batteries +(1) VBS062 Cabinet Internal Batteries +(1) VBS 061 Cabinet Internal Batteries Only PERCENT LOAD UPStation S 8 kVA Battery Run Times #1 Internal Batteries +(1) VBD122 and (1) VBD121 Cabinet Internal Batteries +(1) VBS121 Cabinet... -
Page 35: 10 - 12 Kva Battery Run Times
UPStation S 10 kVA Battery Run Times #1 Internal Batteries +(1) VBS122 and (1) VBD121 Cabinet Internal Batteries +(1) VBD121 Cabinet Internal Batteries +(1) VBS122 Cabinet Internal Batteries Only PERCENT LOAD UPStation S 12 kVA Battery Run Times #1 Internal Batteries +(1) VBS122 and (1) VBD121 Cabinet Internal Batteries... -
Page 36: Kva Battery Run Times
UPStation S 15 kVA Battery Run Times #1 Internal Batteries +(1) VBD181 Cabinet Internal Batteries Only PERCENT LOAD UPStation S 18 kVA Battery Run Times #1 Internal Batteries +(1) VBD181 Cabinet Internal Batteries Only PERCENT LOAD 18 kVA Battery Run Times UPStation S 15 kVA Battery Run Times #2 UPStation S 18 kVA... -
Page 37: Alarm Messages, Meanings, And Corrective Actions
Upon return of power, start up UPS. The UPS starts up by itself if Auto-Restart is enabled. Contact Liebert at 1-800-222-5877 if this condition persists for more than 2 minutes. If automatic transfer to bypass, load returns to UPS power control for most temporary conditions. -
Page 38: Power Protection
Worldwide Support Worldwide FAX tech support The Company Behind The Products With more than 500,000 installations around the globe, Liebert is the world leader in computer protection systems. founding in 1965, Liebert has developed a complete range of support and protection systems for sensitive electronics: §...
