- Page 1 DVI•2000HD U S E R M A N U A L www.gefen.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The DVI•2000 is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Back Panel Descriptions Front Panel Descriptions How To Connect The DVI•2000 DVI•2000 Wiring Diagram Specifi cations Warranty... -
Page 4: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE IN STALL ING OR OPERATING THE DVI•2000 • The fi ber optics cable must be treated carefully when connectors are exposed. They are susceptible to dust which can contribute to loss of pixels. • The DVI•2000 works for all DVI displays and supports resolutions up to 3840x2400 •... -
Page 5: Introduction
INTRODUCTION Thank you for purchasing Gefen’ s ex•tend•it DVI•2000. The DVI•2000 allows extension of DVI Dual Link up to 1640 feet without losing any quality. CONTENTS The DVI•2000 consists of: (1) DVI•2000S (1) DVI•2000R (2) DVI Dual Link cable (6FT) - Page 6 REAR PANELS DESCRIPTIONS DVI•2000 Sender (Rear View Only) Power LED indicates the unit is powered HDCP & DDC Green 1 Blue 2 Hot Plug Detect Clock 1 Red 2 Signals Blue 1 Green 2 Red 1 Clock 2 Status LED indicates a link between the sender and receiver DVI•2000 Receiver (Rear View Only)
-
Page 7: Front Panel Descriptions
FRONT PANELS DESCRIPTIONS DVI•2000 Sender (Front View Only) Power Connector DVI In DVI•2000 Receiver (Front View Only) Power Connector DVI Out... -
Page 8: How To Connect The Dvi•2000
HOW TO CONNECT THE DVI•2000 Connect the DVI•2000 sender unit to the DVI source using the supplied cables. Connect the DVI•2000 receiver unit to your DVI display. Connect the eight fi ber optics and one CAT5 cable between the sender and receiver. -
Page 9: Dvi•2000 Wiring Diagram
DVI•2000 WIRING DIAGRAM... -
Page 10: Specifi Cations
SPECIFICATIONS DVI 2000HD Video Amplifi er Bandwidth ..............2x 1.65 GHz Input Video Signal ................... 1.2 volts p-p Input DDC Signal ................5 volts p-p (TTL) Dual Link Range ..................3840 x 2400 DVI Input/Output Connector Type ..............DVI-D Link Connector ....................RJ-45 Power Consumption ................
