Data of the water
tank (FB/IN)

Setting to work

The data of the FB/IN water tank is listed in the table below:
Description
Capacity
Heating capacity:
standard
Heating capacity:
optional (for max. 10 A load)
Valves
Inlet valves
Boil over sensor:
Triggering temperature:
Water tank temperature sensor:
Default setting:
Follow the steps below to set the machine to work:
Step Action
1. Ensure that the water cock has been opened and that the machine has
been turned on at the main switch.
2. Check all safety elements:
3. Make sure that there are no leaks.
Open the door and check the machine for moisture.
4. Check the manufacturer's settings.
Program the machine as required by the customer.
5. Adjust cup platform to ensure that the cup sensor can detect the placement
of a cup.
ES only: Depending on the cup size, the oblique ES coffee outlet as well as
the height of the cup platform have to be adjusted to ensure the correct dis-
pensing into the cup.
6. If necessary adjust the machine type (adjustment of the general machine
configuration).
7. Set date and time.
8. Check dispensing of all products and hot water dispensing by carrying out
tests.
Data
3.5 l
2700W/230V (Europe)
2000W/230V
24VDC - NW 8
24VDC
80° C ± 5° C
96° C ± 1.5° C
• Open the door - no brewer dispensing
possible
• Close the door - brewer dispensing
possible
• Check the water level sensor in the
drip tray
