Specifications

Monitor Specifications
Picture Tube
Viewable Image Size: 20 inch/508 mm
Input Signal
Display Colors Analog input: Unlimited number of Colors
Synchronization Range Horizontal: 30 kHz to 140 kHz
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area Horizontal: 396 mm/15.6 inches
(Factory Setting)
Active Display Area (Full Scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature: +5°C to +35°C/+41°F to +90°F
Storage Temperature: -20°C to +60°C/-4°F to +140°F
Regulations
Diagonal: 22 inch/550 mm
Radius: 50000 mm
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Negative) (TTL Level)
Sync on Green video (Positive) 0.7 Vp-p and sync
Negative 0.3 Vp-p
Vertical: 48 Hz to 160 Hz
640 x 480 @ 48 to 160 Hz
800 x 600 @ 48 to 160 Hz
1024 x 768 @ 48 to 160 Hz
1280 x 1024 @ 48 to 127 Hz
1600 x 1200 @ 48 to 109 Hz
1800 x 1350 @ 48 to 98 Hz
1800 x 1440 @ 48 to 92 Hz
1856 x 1392 @ 48 to 95 Hz
2048 x 1536 @ 48 to 86 Hz
Vertical: 297 mm/11.7 inches
406 mm/16.0 inches
304.6 mm/12.0 inches
AC 100-120 V/220-240 V, 50/60 Hz
1.35A @ 100-120 V / 0.65A @ 220-240 V
495 mm (W) x 486 mm (H) x 477 mm (D)
19.5 inches (W) x 19.1 inches (H) x 18.8 inches (D)
29.3 kg
64.6 lbs
Humidity: 10% to 90%
Humidity: 10% to 90%
Safety: UL1950 (UL) , CSA C22.2 No.950 (c-UL),
EN60950 (TÜV-GS)
CCC, KETI
EMC: FCC Class-B, DOC Class-B,
EN55022 Class-B, VCCI Class-B,
EN61000-3-2, EN61000-3-3, EN55024
CCC, MIC, BSMI
X-Ray: DHHS, HWC, Röv vom 8.1, 1987
Other: CE-Marking, MPR-II/TCO'91
ISO9241-3, ISO9241-7, ISO9241-8
TCO'95
International E
NERGY
Notes
90° deflection, 0.24 mm grille pitch,
medium short persistence phosphor,
aperture grille CRT, G-WARAS coating
Depends on display card used.
Automatically
Automatically
Some systems may not support all
modes listed.
Dependent upon signal timing used, and
does not include border area.
Dependent upon signal timing used, and
does not include border area.
