Controls

OSD (On-Screen Display) control buttons on the front of the monitor function as follows:
Main Menu
EXIT Exits the OSD menu.
Note : Deactivates the OSD menu and activates the OSD menu when the OSD is turned off.
CONTROL Moves the highlighted
area left/right to select
one of the sub-menu.
Note : When the OSD menu is off, it acts as a Hot key for Brightness.
CONTROL Has no function
+/–
Note : Deactivates the OSD menu and to adjust Contrast with Hot key set "ON"
SELECT/ Enters sub-menu.
SB MODE
When the OSD is off, it will act as the SuperBright (SB) function key. User can select between SB MODE
OFF, SB MODE1, and SB MODE2. The first time this key is pressed, the current SB Mode is indicated.
Within a 3 second window, if this key is selected again, the SB MODE will change to the next SB MODE. For
example, the current mode is SB MODE OFF, the key is pressed twice within a 3 second time frame, the SB
MODE will change to SB MODE1 and so on. The color temperature at each SB Mode is adjusted by appropri
ate color control except for the sRGB mode whose color setting cannot be adjusted. When the unit is turned
off, it will reset to SB off mode.
RESET Resets all the controls within the
highlighted menu to the factory
setting.
Note: Deactivates the OSD menu and Hot Key for input connector (INPUT 1
Note: When RESET is pressed in the main and sub-menu, a warning window will appear allowing you to
select the reset function.
Brightness/Contrast Controls
Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Degauss: Eliminates the buildup of stray magnetic fields which alter the correct scan of the electron beams and affect the
purity of the screen colors, focus and convergence. When activated, your screen image will jump and waver a bit as the
screen is demagnetized.
NOTE: Please allow a minimum of 20 minutes to elapse between uses of the Degauss Control.
Constant Brightness: Sustains the brightness and screen color levels consistently over the normal life of the monitor. The
Constant Brightness function requires a 30 minute warm-up of the monitor before the feature is fully functional.
Size and Position Controls
Auto Adjust: Automatically adjust the horizontal and vertical size and position settings for the applicable timing signal.
NOTE: Auto Adjust is unavailable with no image signal or narrow size of image signal input.
Left/Right: Moves the image horizontally (left or right).
Down/Up: Moves the image vertically (up or down).
Narrow/Wide: Decreases or increases the horizontal size of the image.
Short/Tall: Decreases or increases the vertical size of the image.
Sub-Menu
Exits to the OSD controls
main menu.
Moves the highlighted area
left/right to select one of the
controls.
Moves the bar in the – or +
direction to decrease or
increase the adjustment.
Has no function.
Resets the highlighted control to
the factory setting.
English-4
