LED Indicators & Buttons
The LED indicators on the computer display helpful
information about the current status of the computer.
Icon Color
Green
Blinking Green The computer is in Sleep Mode
The AC/DC Adapter is Plugged in
Orange
& the Computer is Powered Off
Green
Table D - 1 - LED Indicators
Description
The computer is On
System Activity
The buttons located under the front panel icons allow
you to make screen and input adjustments.
Figure D - 1 - Front Icons
Icon
Decrease/Increase Buttons - Use the buttons
to decrease/increase the brightness/volume
Function Menu Toggle - Use this button to
display the On Screen Display (see
Screen Display Indicators/Buttons" on
Screen Power Toggle - Use this button to
toggle the LCD on/off
Table D - 2 - Function Buttons
LED Indicators & Buttons D - 3
Windows 7
Description
"On
page D - 4)
