1.2 Speciications

EP2C612D16C-4L
MB Physical Status
Form Factor
Dimension
Processor System
CPU
Socket
Chipset
System Memory
Capacity
Type
Voltage
Expansion Slot
Slot 1
Slot 2
Slot 3
Slot 4
Slot 6
Storage
SATA
Controller
Additional
SATA
Controller
M.2 Socket
Ethernet
Interface
LAN
2
SSI EEB
12'' x 13'' (30.5 cm x 33.0 cm)
Intel® Xeon processor E5-2600/4600 & v3 series
Dual Socket LGA 2011 R3
Intel® C612
16 DIMM slots
- Quad Channel memory technology
- Supports DDR4 2133/1866 UDIMM, ECC
DIMM, LRDIMM, RDIMM, NVDIMM
1.2V
(Slot 6 is the closest to the CPU)
x8 (x8/x8 with Slot 2, CPU2)
x16 (CPU2)
x8 (x8/x8 with Slot 4)
x16
x16
Intel® C612 : 10 x SATA3 6.0 Gb/s, support RAID 0, 1, 5, 10
(SSATA_3 port is shared with M.2 Socket)
Marvell 9172: 2 x SATA3 6Gb/s, support RAID 0, 1
1 (supports M.2 SATA3 6.0 Gb/s module and M.2 PCI Express
module up to Gen3 x4 (32 Gb/s))
1000 /100 /10 Mbps by Intel i210
4 x RJ45 GLAN by Intel® i210
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Eicient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
