NUT2
NUT1
Step 3
Move the standof based on the
module type and length.
he standof is placed at the nut
location D by default. Skip Step 3 and
4 and go straight to Step 5 if you are
going to use the default nut.
Otherwise, release the standof by
hand.
Step 4
Peel of the yellow protective ilm on
the nut to be used. Hand tighten the
standof into the desired nut location
on the motherboard.
Step 5
Align and gently insert the M.2
(NGFF) SSD module into the M.2
slot. Please be aware that the M.2
(NGFF) SSD module only its in one
orientation.
Step 6
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw as
this might damage the module.
