Page 2 60950-1 or equivalent rating. Attempting to power non-rated devices may result in electric shock, fire, personal injury and death. WARNING! Do not use a Raritan product containing outlet relays to power large inductive loads such as motors or compressors. Attempting to power a large inductive load may result in damage to the relay.
Page 3: Safety Instructions
Safety Instructions 1. Installation of this product should only be performed by a person who has knowledge and experience with electric power. 2. Make sure the line cord is disconnected from power before physically mounting or moving the location of this product. 3.
Page 4 Raritan, Inc. © Copyright 2011 Raritan, Inc. All third-party software and hardware mentioned in this document are registered trademarks or trademarks of and are the property of their respective holders.
Page 5: Table Of Contents
Contents Safety Guidelines Safety Instructions Applicable Models xiii What's New in the Dominion PX User Guide Chapter 1 Introduction Product Models ..........................1 Product Photos ..........................1 Zero U Size.......................... 2 1U Size ..........................2 2U Size ..........................2 Product Features ........................... 3 Package Contents..........................
Page 6 Unpacking the Product and Components................15 Preparing the Installation Site....................15 Filling Out the Equipment Setup Worksheet ..............16 Connecting the Dominion PX to a Power Source................16 Configuring the Dominion PX ...................... 17 Connecting the Dominion PX to a Computer ..............17 Connecting the Dominion PX to Your Network ..............18 Initial Network and Time Configuration ................19...
Page 7 Circuit Breaker Status......................49 Outlets List......................... 50 All Outlets Control......................51 Measurement Accuracy ....................... 52 Managing the Dominion PX ......................52 Displaying Basic Device Information .................52 Displaying Model Configuration Information..............54 Naming the Dominion PX Device ..................55 Modifying the Network Settings ..................56 Modifying the Network Service Settings................58...
Page 8 Configuring the SMTP Logging ..................149 Configuring the SNMP Logging ..................150 Configuring the Syslog Forwarding .................150 Outlet Grouping..........................151 Identifying Other Dominion PX Devices ................152 Grouping Outlets Together ....................153 Viewing and Controlling Outlet Groups ................154 Editing or Deleting Outlet Groups..................155 Deleting Outlet Group Devices ..................155 Diagnostics ..........................156...
Page 9 Example 3 - CurrentReading Attribute ................184 Configuring the Thresholds for Environmental Sensors ............185 Querying the PDU's Serial Number ...................186 Resetting the Dominion PX Device....................186 Using the Help Command......................186 Example 1 - Help Information for the Show Command ...........186 Example 2 - Getting In-Depth Help Information ..............187 Chapter 8 Inline Monitors Overview ............................188...
Page 10 Associating Outlets with a Target Server ................223 Controlling a Target Server's Power................224 Controlling an Outlet's Power ..................224 Paragon Manager Application ..................225 Dominion SX ..........................225 Configuring a Dominion PX on Dominion SX ..............225 Power Control ........................227 Checking Power Strip Status...................228 Dominion KSX..........................228 CommandCenter Secure Gateway....................229...
Page 11 Contents Appendix E Using the IPMI Tool Set Channel Commands ........................230 authcap <channel number> <max priv>................230 info [channel number] ......................231 getaccess <channel number> [userid] ................231 setaccess <channel number> <userid>[callin=on|off] [ipmi=on|off] [link=on|off] [privilege=level]........................231 getciphers <all | supported> <ipmi | sol> [channel] ............231 Event Commands ........................231 <predefined event number>...
Page 12 Step A. Determine User Accounts and Groups .................249 Step B. Configure User Groups on the AD Server ..............250 Step C. Configure LDAP Authentication on the Dominion PX Device........251 Step D. Configure User Groups on the Dominion PX Device............254 Appendix H Resetting the PDU Settings Resetting to Factory Defaults ....................259...
Page 13 Applicable Models This user guide is applicable to the Raritan PDUs whose model names begin with DPXS, DPXR, DPCS, DPCR, or PX. Note: For information on PDUs whose model names begin with PX2, see the "PX-1000/2000 Series" or "PX2-3000/4000/5000 Series" User Guide or online help.
Page 14 What's New in the Dominion PX User Guide The following sections have changed or information has been added to the Dominion PX User Guide based on enhancements and changes to the equipment and/or user documentation. Product Features (on page 3)
Page 15 What's New in the Dominion PX User Guide Please see the Release Notes for a more detailed explanation of the changes applied to this version of Dominion PX.
Page 16: Chapter 1 Introduction
Package Contents ..................5 Product Models The Dominion PX comes in several models that are built to stock and can be obtained almost immediately. Raritan also offers custom models that are built to order and can only be obtained on request.
Page 17: Zero U Size
Chapter 1: Introduction Zero U Size 1U Size 2U Size...
Page 18: Product Features
Chapter 1: Introduction Product Features The Dominion PX models vary in sizes and features. In general, the Dominion PX features include:  For units with switching, the ability to power on, power off, and reboot the devices connected to each outlet.
Page 19 The ability to store a history of sampled data at all levels (unit, circuit breaker, and so on) and retrieve it via SNMP Note: Raritan's Power IQ or other external systems can retrieve the stored data (samples) from the Dominion PX.
Page 20: Package Contents
The following sub-topics describe the equipment and other material included in the product package. Zero U Products  The Dominion PX device  Screws, brackets and/or buttons for Zero U  Null-modem cable with RJ-45 and DB9F connectors on either end ...
Page 21: Chapter 2 Rack-Mounting The Pdu
Rack-Mounting the PDU Chapter 2 This chapter describes how to rackmount a Dominion PX device. Only the most common rackmount method is displayed. Follow the procedure suitable for your model. In This Chapter Rackmount Safety Guidelines ..............6 Circuit Breaker Orientation Limitation............6 Standard Rackmount.................7...
Page 22: Standard Rackmount
Chapter 2: Rack-Mounting the PDU Standard Rackmount The Zero U units are provided with high grade engineering polycarbonate isolation hardware to allow fixing in a variety of positions within the rack. For panel/flush mount, pull out fixing brackets are available on each end cap to allow mounting on suitable rails.
Page 23: Mounting Zero U Models Using L-Brackets
Orientation Limitation (on page 6) before mounting it. To mount Zero U models using L-brackets: 1. Align the baseplates on the rear of the Dominion PX device. 2. Secure the baseplates in place. Different models ship with different types of baseplates.
Page 24: For Zero U Models Using Tool-Less Button Mounting
Some Zero U PDUs ship with tool-less mounting brackets consisting of an adjustable baseplate with a large button. These work by attaching to the back side of a Zero U Dominion PX device (the side opposite of the outlets) and fitting the button into the mounting holes of the cabinet. Note that not all racks may allow the option of securing the Dominion PX device in this way.
Page 25: Mounting Zero U Models Using Button Mount
(on page 6) before mounting it. To mount Zero-U models using button mount: 1. Align the baseplates on the rear of the Dominion PX device. Leave at least 24 inches between the baseplates for stability. 2. Make the baseplates grasp the Dominion PX device lightly.
Page 26 6. Ensure that both buttons can engage their mounting holes simultaneously. 7. Press the Dominion PX device forward, pushing the mounting buttons through the mounting holes, then letting the device drop about 5/8". This secures the Dominion PX device in place and completes the...
Page 27: Mounting Zero U Models Using Claw-Foot Brackets
Orientation Limitation (on page 6) before mounting it. To mount Zero U models using claw-foot brackets: 1. Align the baseplates on the rear of the Dominion PX device. 2. Secure the baseplates in place.  To secure a baseplate with the thumbscrew, turn the thumbscrew until it is tightened.
Page 28: Mounting 1U Or 2U Models
Chapter 2: Rack-Mounting the PDU 5. Using rack screws, fasten the Dominion PX device to the rack through the claw-foot brackets. Mounting 1U or 2U Models Using the appropriate brackets and tools, fasten the 1U or 2U Dominion PX device to the rack or cabinet. If your PDU has circuit breakers...
Page 29 5. Repeat Steps 3 to 4 to secure the other end of the cable-support bar to the other rackmount bracket. 6. Mount the Dominion PX device on the rack by securing the rackmount brackets' ears to the rack's front rails with your own screws, bolts,...
Page 30: Chapter 3 Installation And Configuration
Raritan's Technical Support Department for assistance. 4. Verify that all circuit breakers on the Dominion PX device are set to ON. If not, turn them ON. For a PDU with fuses, ensure that all fuses are inserted and seated properly.
Page 31: Filling Out The Equipment Setup Worksheet
To connect a PDU to the power source: 1. Verify that all circuit breakers on the Dominion PX device are set to ON. If not, turn them ON. For a PDU with fuses, ensure that all fuses are inserted and seated properly.
Page 32: Configuring The Dominion Px
There are two alternatives to initially configure a Dominion PX device:  Connect the Dominion PX device to a computer to configure it, using a serial connection between the Dominion PX and the computer. The computer must have a communications program such as HyperTerminal or PuTTY.
Page 33: Connecting The Dominion Px To Your Network
Connecting the Dominion PX to Your Network To use the web interface to administer the Dominion PX, you must connect the Dominion PX device to your local area network (LAN).
Page 34: Initial Network And Time Configuration
After the Dominion PX device is connected to your network, you must provide it with an IP address and some additional networking information. To configure the networking parameters: 1. Go to the computer that you connected to the Dominion PX device and open a communications program such as HyperTerminal or PuTTY.
Page 35 Note: If you ever accidentally create a rule that locks you out of the Dominion PX, you can rerun the configuration program and reset this parameter to disabled to allow you to access the Dominion PX device. 8. Press Enter. You are prompted to set the LAN interface speed.
Page 36 10. By default, the LAN interface duplex mode is set to auto, which allows the system to pick the optimum mode. Half duplex allows data to be transmitted to and from the Dominion PX device, but not at the same time. Full duplex allows data to be transmitted in both directions at the same time.
Page 37 NTP servers.  Manual configuration: Type n if you want to set the date and time manually later through the Dominion PX web interface. See Setting the Date and Time (on page 60).
Page 38 13. If synchronization with NTP servers is enabled in the previous step, a list of time zones is displayed and the Dominion PX prompts you to select a time zone. Type the number or the name of the desired time...
Page 39 Chapter 3: Installation and Configuration 14. When prompted to enable the daylight savings time, type yes to enable it if the daylight savings time is applicable to the selected time zone, or type no to disable it. 15. You must determine which NTP servers are used if the NTP synchronization is enabled in Step 12.
Page 40: Connecting Environmental Sensors (Optional)
PDU connected via the serial line, or even longer if configured over DHCP. Note: If the Dominion PX device is connected to a Raritan KVM switch, and you want to disable the connected KVM switch's capability of monitoring and controlling the PDU, you can disable the connected power CIM using the CLP command.
Page 41 Chapter 3: Installation and Configuration Raritan sensor hubs CANNOT be cascaded so at most a sensor hub can be connected to each SENSOR port on the Dominion PX device. This diagram illustrates a configuration with a sensor hub connected. The Dominion PX device...
Page 42: About Contact Closure Sensors
Failure to follow installation and configuration instructions can result in false alarms or no alarms. Raritan makes no statement or claim that all third-party detectors/switches will work with DPX-CC2-TR. DPX-CC2-TR is compatible with all Dominion PX models with these prefixes: DPXS, DPXR, DPCS, DPCR, PX-5nnn, PX-4nnn and PX-3nnn, where n is a number.
Page 43 Chapter 3: Installation and Configuration Note: Each button controls the spring of each corresponding termination point. 3. Fully insert each wire of both third-party detectors/switches into each termination point.  Plug both wires of a detector/switch into the two termination points to the left.
Page 44 Chapter 3: Installation and Configuration  Normally Open: The open status of the connected detector/switch is considered normal.  Normally Closed: The closed status of the connected detector/switch is considered normal. This is the default. 5. To set the Normal state for channel 2, repeat Step 4 for adjusting the other dip switch's setting.
Page 45: How To Connect Differential Air Pressure Sensors
To connect a differential air pressure sensor: 1. Plug one end of a Raritan-provided phone cable to the port labeled "Feature" on the Dominion PX device. 2. Plug the other end of this phone cable to the IN port of the differential air pressure sensor.
Page 46: Chapter 4 Using The Pdu
In This Chapter Panel Components ..................31 Circuit Breaker..................36 Beeper .....................38 Panel Components The Dominion PX comes in Zero U, 1U, and 2U sizes. All types of models come with the following components on the outer panels.  Power cord ...
Page 47: Outlets
Take the null-modem cable that was shipped with the Dominion PX device, connect the end with the RJ-45 connector to the RS-232 serial port on the front of the Dominion PX device, and connect the end with the DB9F connector to...
Page 48: Led Display
Port Used for... the serial (COM) port on the computer. The serial port is also used to interface with some Raritan access products (such as the Dominion KX) through the use of a power CIM. Feature Connection to Raritan's environmental sensors.
Page 49 Chapter 4: Using the PDU Three-Digit Row The three-digit row shows the readings for the selected component. Values that may appear include:  Current, voltage, or active power of the selected outlet  Current of the selected line or circuit breaker ...
Page 50 (on page 188). Automatic Mode When left alone, the LED display cycles through the line readings and circuit breaker readings, as available for your Dominion PX model. This is the Automatic Mode. Manual Mode You can press the Up or Down button to enter the Manual Mode so that a particular outlet, line or circuit breaker can be selected to show specific readings.
Page 51: Reset Button
The reset button is located inside the small hole near the two-digit row. Pressing this reset button restarts the Dominion PX device's software without any loss of power to outlets. It does not reset the Dominion PX device to factory defaults.
Page 52: Resetting The Button-Type Circuit Breaker
1. Locate the breaker whose ON button is up, indicating the breaker has tripped. 2. Examine your Dominion PX device and the connected equipment to remove or resolve the cause that results in the overload or short circuit. This step is required, or you cannot proceed with the next step.
Page 53: Beeper
4. Pull up the operating handle until the colorful rectangle or triangle turns RED. Beeper The Dominion PX includes a beeper to issue an audible alarm when a significant situation occurs.  The beeper sounds an alarm within 3 seconds of a circuit breaker trip.
Page 54: Chapter 5 Using The Web Interface
To log in to the web interface, you must enter a user name and password. The first time you log in to the Dominion PX, use the default user name (admin) and password (raritan). You are then prompted to change the password for security purposes.
Page 55 Chapter 5: Using the Web Interface 2. If any security alert message appears, click OK or Yes to accept. The Login page then opens. 3. Type your user name and password in the Username and Password fields. Note: Both the user name and password are case sensitive, so make sure you capitalize them correctly.
Page 56 Chapter 5: Using the Web Interface Note: Depending on your model type and hardware configuration, elements shown on your Home page may appear differently from this image. The web interface allows a maximum of 16 users to log in simultaneously. You must enable JavaScript in the web browser for proper operation.
Page 57: Changing Your Password
Chapter 5: Using the Web Interface Changing Your Password To change your password: 1. Choose User Management > Change Password. The Change Password page opens. 2. Type the current password in the Old Password field. 3. Type your new password in the New Password and Confirm New Password fields.
Page 58 Chapter 5: Using the Web Interface Alerts Alert Configuration Alert Policies Alert Policy Editor Alert Destinations User Management Change Password Users & Groups User/Group System Permissions User/Group Outlet Permissions Device Settings PDU Setup Network Security Certificate Date/Time Authentication SMTP Settings SNMP Settings Event Log External Sensors...
Page 59: Navigation Path
Note: The Home tab is not a menu. Clicking the Home tab takes you back to the Dominion PX Home page.  Position the cursor on the menu name. A list of menu items drops down from the menu.
Page 60: Status Panel
User's present state (active, idle, and so on) IP address of the user's computer Date and time of the user's last login  Information about the Dominion PX device, including: PDU name Model name and number IP address Firmware version...
Page 61 Information about all the users currently connected, including user name, IP address, and present state. Your active session is included in this list.  Status of Dominion PX's serial port, indicating whether the serial port is supplying power to the connected Raritan power CIM, such as D2CIM-PWR ...
Page 62: Status Messages
Chapter 5: Using the Web Interface Note: If any PSoC update failure occurs during the firmware upgrade process, the failure is reported in the status panel. See PSoC Firmware Upgrade Failure (on page 70). Status Messages When you perform an operation from the web interface, such as creating a user profile or changing a network setting, a message appears at the top of the page indicating whether or not the operation was successful.
Page 63: Refresh
Outlets list, and an All Outlets Control panel. The page also contains an External Sensors panel when environmental sensors are connected to the Dominion PX. The Home page refreshes every 30 seconds to keep the data displayed up to date.
Page 64: Circuit Breaker Status
For details on each circuit breaker, choose Details > CB Details. Tip: The most efficient use of the Dominion PX occurs when current loads are balanced between all circuit breakers. Using the Outlet Mapping on the CB Details page, and the Circuit Breaker status on the Home Page, you can arrange where devices are plugged into the Dominion PX in order to maintain that balance.
Page 65: Outlets List
Chapter 5: Using the Web Interface Outlets List The Outlets list displays each outlet on the Dominion PX device as a table row with a view of the power status, the RMS current, and the RMS Power through the individual outlet.
Page 66: All Outlets Control
2. Click On to turn all outlets ON, or click Off to turn all outlets OFF. 3. A dialog for confirming the operation appears. Click OK to confirm the operation. Note: Not all Dominion PX models support the outlet switching function, such as PX-4nnn or PX-3nnn, where n is a number.
Page 67: Measurement Accuracy
Active Energy (kWh), is reported. Managing the Dominion PX You can display basic device information about the Dominion PX device, give it a new device name, and modify any of the network settings that were entered during the initial configuration process. You can also set the device's date and time and configure its SMTP settings so it can send email messages when alerts are issued.
Page 68 Chapter 5: Using the Web Interface 2. The Device Information panel displays the product name, serial number, and IP and MAC addresses of the Dominion PX device, as well as detailed information about the firmware running in the PDU. 3. To open or save an XML file providing details for Raritan Technical Support, click the "View the datafile for support"...
Page 69: Displaying Model Configuration Information
Chapter 5: Using the Web Interface Displaying Model Configuration Information To display information specific to the Dominion PX device that you are using, such as inlet or outlet types, trigger the Device Information dialog. To display the Model Configuration panel: 1.
Page 70: Naming The Dominion Px Device
Chapter 5: Using the Web Interface Naming the Dominion PX Device By default, the Dominion PX has a device name of its serial number. You may want to give it a more recognizable name for identification. The PDU's default host name is identical to the device name. Assign a different host name if necessary.
Page 71: Modifying The Network Settings
SNMP system name. However, the SNMP system name becomes inconsistent with the device name when the device name is changed. To make both names identical, you must restart the Dominion PX device or restart the SNMP agent after changing the device name in the web interface.
Page 72 As Internet communications are carried out on the basis of IP addresses, appropriate DNS server settings are required for mapping domain names (host names) to corresponding IP addresses, or the Dominion PX may fail to connect to the given host.
Page 73: Modifying The Network Service Settings
Note: Telnet access is disabled by default because it communicates openly and is thus insecure. You can also set a bandwidth limit, and enable or disable the Raritan Setup Protocol. To configure network communication services: 1. Choose Device Settings > Network. The Network Settings page opens.
Page 74: Modifying The Lan Interface Settings
3. To change the duplex mode, select a different option in the LAN Interface Duplex Mode field.  Autodetect: The Dominion PX selects the optimum transmission mode through auto-negotiation.  Half duplex: Data is transmitted in one direction (to or from the Dominion PX device) at a time.
Page 75: Setting The Date And Time
Chapter 5: Using the Web Interface Setting the Date and Time You can set the internal clock on the Dominion PX device manually, or link to a Network Time Protocol (NTP) server and let it set the date and time for the Dominion PX.
Page 76 Chapter 5: Using the Web Interface 2. Enter a time zone by selecting an appropriate option from the Time Zone drop-down list. For example, select (GMT -3:00) Argentina if you are located in Argentina. 3. Choose one of the methods to set the date and time: ...
Page 77: Specifying The Device Altitude
4. Click Apply. The date and time settings are applied. Specifying the Device Altitude You must specify the Dominion PX device's altitude above sea level if a Raritan differential air pressure sensor is attached. This is because the device's altitude is associated with the altitude correction factor. See Altitude Correction Factors (on page 247).
Page 78: Configuring The Smtp Settings
Configuring the SMTP Settings The Dominion PX can be configured to send alerts or event messages to a specific administrator by email. To do this, you have to configure the SMTP settings and enter an IP address for your SMTP server and a sender's email address.
Page 79: Configuring The Snmp Settings
To configure the SNMP communication: 1. Choose Device Settings > SNMP Settings. The SNMP Settings page opens. 2. Select the Enable SNMP Agent checkbox to enable the Dominion PX to communicate with external SNMP managers. A number of options become available.
Page 80: Enabling Data Retrieval
8. Click Apply. The SNMP configuration is set. Enabling Data Retrieval The data retrieval feature allows the retrieval of the Dominion PX data by an SNMP manager, such as the data of PDU, outlet, line, and circuit breaker. When enabled, the Dominion PX measures all sensor data at regular intervals and stores these data samples for access over SNMP.
Page 81 After data retrieval is enabled, an external manager or application (such as Raritan's Power IQ) can access the stored data using SNMP. Download the Dominion PX MIB file to assist you in configuring third-party managers to retrieve data. See Using SNMP (on page 161) for more details.
Page 82: Resetting The Dominion Px Device
2. Click Reset. A Reset Confirmation page opens. 3. When you click Really Reset, the Dominion PX device reboots. If you change your mind, click Cancel to terminate the reset operation. If you choose to proceed with the reset, the page shown below opens and...
Page 83: Updating The Firmware
Users must either use the admin account or have both the Firmware Update and Unit Reset privileges in order to successfully update the Dominion PX firmware. The Dominion PX firmware files are available on the Raritan website's Firmware and Documentation section (http://www.raritan.com/support/firmware-and-documentation/).
Page 84 Login page re-opens. You can now log in and resume managing the Dominion PX. Note: If you are using the Dominion PX with an SNMP manager, you should re-download the Dominion PX MIB after updating the firmware.
Page 85 Chapter 5: Using the Web Interface PSoC Firmware Upgrade Failure All Raritan PDUs include two types of processors:  The main PDU processor, which controls the unit's high level functionality, such as the web server, SNMP agent, environmental sensor management and so on.
Page 86 PSoC 6 Full Disaster Recovery If the firmware upgrade fails, causing the Dominion PX device to stop working, you can recover it by using a special utility rather than returning the device to Raritan.
Page 87: Copying Configurations With Bulk Configuration
Copying Configurations with Bulk Configuration The Bulk Configuration feature lets you save the settings of a configured Dominion PX device to your PC. You can use this configuration file to:  Copy that configuration to other Dominion PX devices of the same model.
Page 88 Chapter 5: Using the Web Interface Saving a Dominion PX Configuration A source device is an already configured Dominion PX device that is used to create a configuration file containing the settings that can be shared between Dominion PX devices. These settings include user and group configurations, thresholds, alert policies, the access control list, and so on.
Page 89 Chapter 5: Using the Web Interface Copying a Dominion PX Configuration A target device is a Dominion PX device that loads another Dominion PX device's configuration file. Copying a Dominion PX configuration to a target device adjusts that Dominion PX device's settings to match those of the source Dominion PX device.
Page 90: Setting Up User Profiles
Enable Single Login Limitation checkbox. Creating a User Profile Creating new users adds a new login to the Dominion PX. To create a new user, you must have both the User/Group Management privilege and an IPMI Privilege Level of OEM.
Page 91 Field Type this... New User Name The name the user enters to log in to the Dominion PX. Full Name The user's first and last names. Password, The password the user enters to log in. Type it first in the Password field and then again in the Confirm Password field.
Page 92: Copying A User Profile
Chapter 5: Using the Web Interface 3. Select a user group from the drop-down list in the User Group field. The user group determines the system functions and outlets this user can access.  If you select None, the user is not assigned to a user group. This means you have to set the user's permissions individually.
Page 93: Deleting A User Profile
Chapter 5: Using the Web Interface 2. Select the user profile you want to modify from the Existing Users drop-down list. All information in the user profile is displayed except the password. 3. Make all necessary changes to the information shown. To change the password, type a new password in the Password and Confirm Password fields.
Page 94: Setting Up User Groups
Setting Up User Groups The Dominion PX is shipped with one user group built in: the Admin user group. This user group provides full system and outlet permissions. It can be neither modified nor deleted.
Page 95: Creating A User Group
Chapter 5: Using the Web Interface Creating a User Group It is better to create a user group with appropriate permissions before creating new user profiles that will have these permissions. To create a user group: 1. Choose User Management > Users & Groups. The User/Group Management page opens.
Page 96 Chapter 5: Using the Web Interface 2. Select the user group from the Group drop-down list. The permissions that apply to this group appear. If this is the first time you are setting the permissions for this group, all permissions are set to No. 3.
Page 97: Setting The Outlet Permissions
Chapter 5: Using the Web Interface Note: The "User (not in group)" field on this page is used to set individual user permissions. If you are setting group permissions, you may ignore this field. Some permissions must be enabled with other permissions for the effects to apply.
Page 98: Copying A User Group
Chapter 5: Using the Web Interface 3. Set the permissions as necessary. Click on the drop-down list to select a permission level for each outlet. 4. When you are finished, click Apply. The permissions are applied to the user group. Note: The "User (not in a group)"...
Page 99: Deleting A User Group
Chapter 5: Using the Web Interface Note: To modify a user group's system or outlet permissions, repeat the procedure for setting the system or outlet permissions and make any necessary changes. See Setting the System Permissions (on page 80) Setting the Outlet Permissions (on page 82).
Page 100: Setting The Global Default Outlet State
Chapter 5: Using the Web Interface Setting the Global Default Outlet State Set a global default for the power state of the outlets when the Dominion PX device is powered on. Setting an individual outlet's startup state to something other than Device Default overrides this default state for that outlet.
Page 101: Setting The Global Power Cycling Delay
When an outlet is power cycled, it is turned off and then back on. The number you enter on the PDU Setup page determines the length of time (in seconds) it takes for ALL outlets on the Dominion PX device to turn back on after being shut down during the power cycle.
Page 102: Setting The Outlet Power-On Sequence
1 to the highest-numbered outlet when turning ON or power cycling all outlets on the Dominion PX device. You can change the order in which the outlets power ON. This is useful when there is a specific order in which the connected IT equipment should be powered up.
Page 103: Naming And Configuring Outlets
4. Select an outlet state from the drop-down list in the "Outlet state on device startup" field. This determines if the outlet is ON or OFF when the Dominion PX device powers up. If set to Device Default, the state for this outlet is determined by the Default Outlet State on the PDU Setup page.
Page 104: Viewing Outlet Details
Chapter 5: Using the Web Interface Viewing Outlet Details To display details about a particular outlet: 1. Choose Details > Outlet Details. The Outlet Details page opens. 2. Select an outlet from the "Show details of outlet" drop-down list. The page shows these details about the outlet: ...
Page 105: Power Cycling An Outlet
Outlet On, Off, or Cycling the Power (on page 50). Note: The length of time between the off and on states in a power cycle can be set on the Dominion PX device as a whole, and for individual outlets. See Setting PDU Thresholds and Hysteresis...
Page 106: Setting Up Power Thresholds And Hysteresis
Chapter 5: Using the Web Interface Setting Up Power Thresholds and Hysteresis The Dominion PX is shipped with certain PDU and outlet power thresholds already defined, and with a hysteresis value already set for all thresholds. You can change the default Dominion PX thresholds and hysteresis values.
Page 107: Setting Outlet Thresholds And Hysteresis
You can set the thresholds for outlet RMS current, and by default, the Dominion PX assigns a hysteresis value for the outlet threshold. Note: If you are using a Dominion PX inline monitor, the outlet voltage threshold and hysteresis are also available on the same page.
Page 108: Monitoring Line And Circuit Breaker Status
Therefore, it is strongly recommended to change the default hysteresis to 0.5A or less when resetting or configuring outlet thresholds. Monitoring Line and Circuit Breaker Status The Dominion PX provides details for additional information on Line and Circuit Breaker status.
Page 109: Monitoring Unbalanced Loads
Chapter 5: Using the Web Interface Monitoring Unbalanced Loads In a three-phase Dominion PX device, a load imbalance occurs when the current on a line differs from the average current of all three lines. The largest absolute difference in current is expressed as a percentage of the average current.
Page 110 Chapter 5: Using the Web Interface Configuring Unbalanced Load Thresholds Configuring these thresholds determines when the Unbalanced Load indicator changes colors from white to yellow or red. It also configures the unbalanced load event thresholds used in Alert Notifications. Unbalanced Load Detection must be enabled before these thresholds take effect.
Page 111: Line Details Page
To open the Line Details page, choose Details > Line Details. The page opens and displays for each line the present current draw, the largest amount of current drawn since the Dominion PX device's last boot, and the amount of available current that can be drawn.
Page 112: Access Security Control
Forcing HTTPS Encryption HTTPS uses Secure Sockets Layer (SSL) technology to encrypt all traffic to and from the Dominion PX device so it is a more secure protocol than HTTP. You can force users to access the Dominion PX web interface through the HTTPS protocol only.
Page 113: Configuring The Firewall
Chapter 5: Using the Web Interface Configuring the Firewall The Dominion PX has a firewall that you can configure to prevent specific IP addresses and ranges of IP addresses from accessing the Dominion PX device. When the Dominion PX was initially configured, you were prompted to enable or disable IP access control.
Page 114 4. Click Apply. The new default policy is applied. Creating Firewall Rules Firewall rules determine whether to accept or discard traffic intended for the Dominion PX, based on the IP address of the host sending the traffic. When creating firewall rules, keep these principles in mind: ...
Page 115 Chapter 5: Using the Web Interface To create firewall rules: 1. Choose Device Settings > Security. The Security Settings page opens. Locate the panel labeled IP Access Control. 2. Ensure the Enable IP Access Control checkbox is selected. 3. Create specific rules. See the table for different operations. Action Do this...
Page 116: Creating Group Based Access Control Rules
Chapter 5: Using the Web Interface 4. When finished, the rules appear in the IP Access Control panel. 5. Click Apply. The rules are applied. Deleting Firewall Rules When any firewall rules become obsolete or unnecessary, remove them from the rules list. To delete a firewall rule: 1.
Page 117 Chapter 5: Using the Web Interface 2. Set the default action. See Changing the Default Action (on page 102). 3. Create rules that accept or drop traffic sending from specific addresses when they are associated with a specific user group. See Creating Group Based Access Control Rules (on page 103).
Page 118 Creating Group Based Access Control Rules Group based access control rules accept or drop traffic intended for the Dominion PX device, based on the user's group membership. Like firewall rules, the order of rules is important, since the rules are executed in numerical order.
Page 119: Setting Up User Login Controls
You can set up login controls to make it more difficult for hackers to access the Dominion PX and the devices connected to it. You can arrange to lock persons out after a specified number of failed logins, limit the number of persons who log in using the same user name at the same time, and force users to create strong passwords.
Page 120 Enabling User Blocking User blocking determines how many times a user can attempt to log in to the Dominion PX and fail authentication before the user's login is blocked. To enable user blocking: 1. Choose Device Settings > Security. The Security Settings page opens.
Page 121 4. To adjust how long users can remain idle before they are forcibly logged out by the Dominion PX, enter a time in minutes in the Idle Timeout field. The default value is 15 minutes.
Page 122 At least one numeric character = Required At least one printable special character = Required Number of restricted passwords Note: The maximum password length accepted by the Dominion PX is 32 characters. 3. Make any necessary changes to the default settings.
Page 123: Disabling The Pdu's Ping Response
4. When you are finished, click Apply. The changes are applied. Disabling the PDU's Ping Response The Dominion PX device responds to the ICMP ping request by default. You can have the PDU stop responding to any ICMP ping request if necessary.
Page 124: Creating A Certificate Signing Request
Chapter 5: Using the Web Interface Creating a Certificate Signing Request Follow this procedure to create the CSR for your Dominion PX device. To create a CSR: 1. Choose Device Setting > Certificate. The first page of the SSL Server Certificate Management page appears.
Page 125 Chapter 5: Using the Web Interface Field Type this... Locality/City The city where your company is located. State/Province The full name of the state or province where your company is located. Country (ISO Code) The country where your company is located. Use the standard ISO country code.
Page 126: Installing A Certificate
1. Choose Device Settings > Certificate. The second page of the Server Certificate Management page opens. 2. Type the path and name of the certificate file in the SSL Certificate File field, or click Browse and select the file. 3. Click Upload. The certificate is installed on the Dominion PX device.
Page 127: Setting Up External User Authentication
When configured for LDAP authentication, all Dominion PX users must have an account on the LDAP server. Local-authentication-only users will have no access to the Dominion PX except for the admin, who always can access the Dominion PX. Gathering Information for LDAP Configuration It requires knowledge of your LDAP server and directory settings to configure the Dominion PX for LDAP authentication.
Page 128 Chapter 5: Using the Web Interface  The network port used by the LDAP server  The type of the LDAP server, usually one of the following options:  A generic LDAP server  Novell Directory Service  ® Microsoft Active Directory (AD) ...
Page 129: Setting Up Ldap Authentication
Chapter 5: Using the Web Interface Setting Up LDAP Authentication To set up LDAP authentication: 1. Choose Device Settings > Authentication. The Authentication Settings page opens.
Page 130 Chapter 5: Using the Web Interface 2. Select the LDAP radio button to enable the LDAP section of the page. 3. Type of external LDAP/LDAPS server. Choose from among the options available:...
Page 131 6. SSL Enabled - Select this checkbox if you would like to use SSL. Secure Sockets Layer (SSL) is a cryptographic protocol that allows the Dominion PX to communicate securely with the LDAP/LDAPS server. 7. Port - The default Port is 389. Either use the standard LDAP TCP port or specify another port.
Page 132: Setting Up Radius Authentication
Directory Administrator for a specific domain name. 17. Click Apply. LDAP authentication is now in place. Note: If the Dominion PX clock and the LDAP server clock are out of sync, the certificates are considered expired and users are unable to authenticate using LDAP.
Page 133: Environmental Sensors
4. Type the shared secret in the Shared Secret field. The shared secret is necessary to protect communication with the RADIUS server. 5. By default, the Dominion PX uses the standard RADIUS port 1812 (authentication) and 1813 (accounting). If you prefer to use non-standard ports, change the ports.
Page 134: Identifying Environmental Sensors
Chapter 5: Using the Web Interface 2. Log in to the Dominion PX web interface. The Dominion PX should have detected the connected sensors, and display them in the web interface. 3. Identify each sensor through the sensor's serial number. See Identifying Environmental Sensors (on page 119).
Page 135 Chapter 5: Using the Web Interface The serial number for each sensor appears listed in the web interface after each sensor is detected by the Dominion PX. Match the serial number from the tag to those listed in the sensor table.
Page 136: Managing Environmental Sensors
The Dominion PX starts to retrieve an environmental sensor's reading and/or state and records the state transitions after the environmental sensor is managed. The Dominion PX device can manage a maximum of 16 environmental sensors. When there are less than 16 managed sensors, the Dominion PX automatically brings detected environmental sensors under management.
Page 137: Configuring Environmental Sensors
For numeric sensors, you can also configure thresholds that enable the Dominion PX to generate an alert or notification when environmental conditions detected by the sensors move outside of your ideal values.
Page 138 Chapter 5: Using the Web Interface 2. If the sensor selected in the previous step is a Raritan contact closure sensor connected with third-party detectors/switches, the On/Off Sensor Subtype field is displayed for you to select the detector/switch type: ...
Page 139 5. Configure the upper and lower thresholds for numeric sensors.  The Upper Critical and Lower Critical values are points at which the Dominion PX considers the operating environment critical and outside the range of the acceptable threshold.  Once critical, the sensor reading must drop below the Upper Non-critical or raise above the Lower Non-critical value before the Dominion PX considers the environment to be acceptable again.
Page 140 Note: The maximum ambient operating temperature (TMA) for the Dominion PX varies between 40 to 60 degrees Celsius, depending on the model and certification standard (CE or UL). If necessary, contact Raritan Technical Support for this information for your model.
Page 141 (on page 126). Note: To configure and retrieve these coordinate values over SNMP, see the Dominion PX MIB. Using Rack Units for the Z Coordinate Value You can use the number of rack units to describe the vertical location (Z coordinate) of an environmental sensor.
Page 142: Viewing Sensor Readings And States
To view the readings and states from any other page, click Home in the navigation path at the top of the page. Sensor Measurement Accuracy Raritan environmental sensors are with the following factory specifications. Calibration is not required for environmental sensors. ...
Page 143 Note: When the sensor is deemed unavailable, the existing sensor configuration remains unchanged. For example, the ID number assigned to the sensor remains associated with it. The Dominion PX continues to ping unavailable sensors, and moves out of the unavailable state after detecting the sensor for two consecutive scans.
Page 144 Chapter 5: Using the Web Interface "normal" State This state indicates the sensor is in the normal state. For a contact closure sensor, this state is the normal state you have set.  If the normal state is set to Normally Closed, the normal state means the contact closure switch is closed.
Page 145: Unmanaging Environmental Sensors
When it is unnecessary to monitor a particular environmental factor, you can unmanage or release the corresponding environmental sensor so that the Dominion PX device stops retrieving the sensor's reading and/or state. To release a managed sensor: 1. Choose External Sensors > External Sensors Details. The External Sensor Details page opens.
Page 146: Assigning Or Changing The Id Number
Chapter 5: Using the Web Interface Assigning or Changing the ID Number Instead of letting the Dominion PX assign an ID number to the sensor, you can manually assign any ID number (1 to 16) to a detected or managed sensor.
Page 147: Components Of An Alert
Environmental thresholds are assigned on the External Sensor Setup page. Destinations are configured as part of the Alert creation process. E-mail alert destinations require that the Dominion PX be set up for SMTP communication. See Configuring the SMTP Settings (on page 63).
Page 148 Chapter 5: Using the Web Interface Creating Alert Destinations To set up new Alerts, first create the necessary destinations on the Alert Destinations page. Choose Alerts > Alert Destinations to open the page.
Page 149  Event Log: One of the system default destinations. Adding the event log destination to a policy causes the Dominion PX to record alert notifications in the system log. This destination cannot be deleted and additional ones of this type cannot be created.
Page 150 SNMP is configured on the Event Log Settings page. For SNMP alert destinations, the Dominion PX sends IPMI-PET (platform event traps) traps to the SNMP manager. The traps are generated in the alert configuration and sent out in IPMI-specific formats containing raw data.
Page 151 Chapter 5: Using the Web Interface Creating Alert Policies Once your destinations are created, you can create policies based on notifying these destinations. This is done on the Alert Policies Editor, which you can reach by choosing Alerts > Alert Policy Editor. On this page, you can select an existing policy to modify, or create a new policy.
Page 152 Chapter 5: Using the Web Interface  Event Log: causes the Dominion PX to record alert notifications in the system log.  Addresses listed under eMail: causes the Dominion PX to send alert notifications to the specified e-mail address. ...
Page 153 Chapter 5: Using the Web Interface Creating Alerts The Alert Configuration page is where you specify how the Dominion PX responds to certain events. First describe an event that triggers an alert and then select the policy the Dominion PX should take in response.
Page 154 "Current Outlet" because the "cycle current outlet" destination may generate the infinite output cycle loop. 7. Click Add. Added alerts are now tracked by the Dominion PX. When an alert's event conditions are met, the associated policy executes. Note: If Environmental Temperature or Environmental Humidity is selected as part of the Event, an alert event is created for each Temperature or Humidity sensor.
Page 155: Sample Alerts
Sample Alerts Sample Outlet-Level Alert In this example, we want the Dominion PX to notify us when the current draw on a specific outlet (Outlet 6) approaches the critical limit. To do that we would set up an alert like this: ...
Page 156 Chapter 5: Using the Web Interface Sample Unit-Level Alert In this example, we want the Dominion PX to shut down most of its outlets if the Dominion PX device becomes too hot. However, since mission-critical servers are plugged into Outlets 1 and 2, we want to leave them running.
Page 157: A Note About Untriggered Alerts
In some cases, a measurement exceeds a threshold causing the Dominion PX to generate an alert. The measurement then returns to a value within the threshold, but the Dominion PX does not generate an alert message for the Deassertion event. Such scenarios can occur due to the hysteresis tracking the Dominion PX uses.
Page 158 How to Disable the Hysteresis By default, the Dominion PX assigns a hysteresis value for each setting in the Thresholds panels on the Outlet Setup and PDU Setup pages. You can disable the hysteresis for any setting.
Page 159: Setting Up Event Logging
11A, triggering a Current Critical alert. The current then continues to fluctuate between 9.8A and 11A. With the hysteresis set to 0.9A, the Dominion PX continues to indicate that the current in Outlet 1 is above critical. With the hysteresis disabled (that is, set to zero), the Dominion PX would de-assert the condition each time the current dropped to 9.9A, and re-assert the condition each time the...
Page 160: Configuring The Local Event Log
Chapter 5: Using the Web Interface Configuring the Local Event Log Follow this procedure to determine whether the local logging function is enabled and which types of events are logged in the local log. To configure the local event log: 1.
Page 161 Chapter 5: Using the Web Interface 5. By default, when the local event log is enabled, seven event types appear in the Event Log Assignments panel to the right. All are enabled by default. To disable any of these event types, deselect the appropriate checkboxes.
Page 162 Chapter 5: Using the Web Interface Viewing the Local Event Log To display the internal event log, choose Maintenance > View Event Log. Each event entry in the local log consists of:  Date and time of the event  Type of the event ...
Page 163: Configuring The Nfs Logging
Chapter 5: Using the Web Interface Configuring the NFS Logging This procedure describes how to enable the Network File System (NFS) logging function and determine which types of events are recorded in the NFS log file. To configure the NFS logging: 1.
Page 164: Configuring The Smtp Logging
Chapter 5: Using the Web Interface Configuring the SMTP Logging You can enable the Simple Mail Transfer Protocol (SMTP) logging function and determine which types of events are recorded in the SMTP log file. To configure the SMTP logging: 1. Ensure the SMTP server settings have been configured properly. See Configuring the SMTP Settings (on page 63).
Page 165: Configuring The Snmp Logging
(on page 161) for instructions on enabling SNMP Event Logging. Configuring the Syslog Forwarding To make the Dominion PX automatically forward events to a specific destination, enable the syslog forwarding function and determine which types of events should be logged in the syslog record.
Page 166: Outlet Grouping
Outlet Group. Only locally authenticated users may perform actions on outlet groups. Note: Outlet Grouping supports adding outlets from up to four other Dominion PX devices. All PDUs must be accessible over IP and must be running firmware version 1.1 or higher.
Page 167: Identifying Other Dominion Px Devices
2. Type a name to identify the Dominion PX device you want to add in the Name field. 3. Type the IP Address of the Dominion PX device you want to add in the IP Address field. 4. Type the admin username and password in the Username and Password fields.
Page 168: Grouping Outlets Together
Outlets that are grouped together power on and power off in unison, using a control panel from the Dominion PX device where the outlet group was created. To group outlets together: 1.
Page 169: Viewing And Controlling Outlet Groups
Chapter 5: Using the Web Interface 5. A list of available Dominion PX devices and their outlets appears under Collection of Real Outlets. Select the checkbox representing the desired physical outlet to make it part of the outlet group. All outlets that are selected are grouped together when you click Create.
Page 170: Editing Or Deleting Outlet Groups
2. Click Delete for the Dominion PX device you want to remove from outlet grouping. Note: If you delete a Dominion PX device that still has outlets in a group, it removes the associated outlets from that group, but the group still exists.
Page 171: Diagnostics
Chapter 5: Using the Web Interface Diagnostics The Dominion PX provides the following tools in the web interface for diagnosing potential networking issues.  Network Interface  Network Statistics  Ping Host  Trace Route to Host  Device Diagnostics...
Page 172: Network Statistics Page
Chapter 5: Using the Web Interface Network Statistics Page The Dominion PX provides statistics about your network interface. To view statistics about your network interface: 1. Choose Diagnostics > Network Statistics. The Network Statistics page opens. 2. Click Refresh. The relevant information is displayed in the Result field.
Page 173: Ping Host Page
Ping is a network tool used to test whether a particular host or IP address is reachable across an IP network. Using the Ping Host page, you can determine if a target server or another Dominion PX is accessible. To ping the host: 1.
Page 174: Saving A Device Diagnostics File
3. Click Save to save the file onto your computer. Using Online Help The Dominion PX User Guide is also provided in the form of online help, and accessible over the Internet. To use online help, Active Content must be enabled in your browser. If you are using Internet Explorer 7, you must enable Scriplets.
Page 175 "Email this page" icon in the toolbar. 9. To email your comments or suggestions regarding the user guide to Raritan, click the "Send feedback" icon 10. To print the currently selected topic, click the "Print this page" icon...
Page 176: Chapter 6 Using Snmp
Using SNMP Chapter 6 This SNMP section helps you set up the Dominion PX for use with an SNMP manager. The Dominion PX can be configured to send traps to an SNMP manager, as well as receive GET and SET commands in order to retrieve status and configure some basic settings.
Page 177: Enabling Snmp
To enable SNMP: 1. Choose Device Settings > SNMP Settings. The SNMP Settings page opens. 2. Select the Enable SNMP Agent checkbox to enable the Dominion PX to communicate with external SNMP managers. A number of options become available. 3. Select the Enable SNMP v1 / v2c Protocol checkbox to enable communication with an SNMP manager using SNMP v1 or v2c protocol.
Page 178 6. Type the SNMP MIBII sysContact value in the System Contact field. 7. Click on the link at the bottom of the page to download an SNMP MIB for your Dominion PX to use with your SNMP manager. 8. Click Apply. The SNMP configuration is set.
Page 179: Configuring Users For Encrypted Snmp V3
The SNMP v3 protocol allows for encrypted communication. To take advantage of this, users need to have an Encryption Phrase, which acts as a shared secret between them and the Dominion PX. This encryption phrase can be set on the User Management page.
Page 180: Restarting The Snmp Agent After Adding Users
Restarting the SNMP Agent after Adding Users If you have just added or re-configured a user for SNMP v3 access, you must restart the Dominion PX SNMP agent before the user can log in with SNMP v3 access. To restart the SNMP agent after adding users: 1.
Page 181: Configuring The Snmp Traps
Chapter 6: Using SNMP Configuring the SNMP Traps The Dominion PX automatically keeps an internal log of events that occur. Setting Up Event Logging (on page 144). These events can also be used to send SNMP traps to a third party manager. Note that the Dominion PX sends traps via SNMP v2c protocol only.
Page 182: Suggestion For Snmp Trap Configuration
7. Click Apply. SNMP logging is configured. 8. From the Maintenance tab, select Unit Reset to reset the Dominion PX device. You must reset the Dominion PX when enabling SNMP logging or changing the Destination IP address.
Page 183: A False Circuit Breaker Trip Trap
If the Dominion PX generates an SNMP trap of voltage measurement failure for the circuit breaker, it indicates a false circuit breaker trip caused by the hardware failure. In that case, you have to return the PDU to Raritan for fixing the problem. Contact Raritan Technical Support when such a trap is generated.
Page 184: Snmp Sets And Configurable Objects
For example, the unitSensorsGroup group contains objects for sensor readings of the Dominion PX as a whole. One object listed under this group, unitCurrent, is described later in the MIB as "The value for the unit's current sensor in millamps"--the measure of the current drawn by the...
Page 185: Configuring The Hysteresis
Configuring the Hysteresis You can configure the hysteresis values using the SNMP set command. Different from the Dominion PX web interface, SNMP accepts only integer values as the hysteresis values so decimal point values will be rejected. To set a decimal point value, you must use the web interface to change the hysteresis values.
Page 186: Changing Id Numbers Of Environmental Sensors
Chapter 6: Using SNMP Changing ID Numbers of Environmental Sensors All ID numbers of existing environmental sensors can be rearranged at a time by using the SNMP MIB variable "reorderexternalSensorsTableEntries" and a comma-separated list. Below are the guidelines of using this variable: ...
Page 187: A Note About Measurement Units
Chapter 6: Using SNMP  6 to 9  7 to 16  11 remains unchanged Since the original ID numbers are not consecutive because of missing numbers 1, 3, 4, 8, 9 and 10, you must mark each missing number with a comma in the comma-separated list.
Page 188: Chapter 7 Using The Clp Interface
Resetting the Dominion PX Device ............186 Using the Help Command ..............186 About the CLP Interface The Dominion PX provides a command line interface that enables data center administrators to perform some basic management tasks. The interface is based on the Systems Management Architecture for Server Hardware (SMASH) Command Line Protocol (CLP).
Page 189: With Hyperterminal
This section illustrates HyperTerminal, which is part of Windows operating systems prior to Windows Vista. To log in using HyperTerminal: 1. Connect your computer to the Dominion PX device via a local connection. 2. Launch HyperTerminal on your computer and open a console window.
Page 190: With Ssh Or Telnet
7. You are now logged in to the command line interface and can begin administering the Dominion PX device. With SSH or Telnet You can remotely log in to the command line interface using an SSH or Telnet client, such as PuTTY.
Page 191: Closing A Serial Connection
Close the window or terminal emulation program when you finish accessing a Dominion PX device over the serial connection. When accessing or upgrading multiple Dominion PX devices, do not transfer the serial cable from one device to another without closing the serial connection window first.
Page 192: Syntax
Chapter 7: Using the CLP Interface Syntax The following is the syntax for the show command: clp:/-> show /system1/outlet<outlet number> where <outlet number> is the number of the outlet. To display information for all outlets, type the wildcard asterisk (*) instead of a number. Attributes You can use the name and powerState attributes to filter the output of the show command.
Page 193 Chapter 7: Using the CLP Interface Example 1 - No Attributes The diagram shows the output of the show command without any attributes entered. Example 2 - Name Attribute The diagram shows the output of the show command with the name attribute.
Page 194: Showing In-Depth Outlet Information
Chapter 7: Using the CLP Interface Showing In-Depth Outlet Information Use the show command to display the RMS Current, Power Factor, Max Current, Active Power and Apparent Power of a specific outlet. To show in-depth outlet information: 1. Perform the show command on an outlet. This displays the sensors associated with the designated outlet.
Page 195: Examples Of Showing In-Depth Outlet Information
Chapter 7: Using the CLP Interface Examples of Showing In-Depth Outlet Information 1. Perform the show command on the outlet without additional attributes. 2. Perform the show command on the associated sensors. Switching an Outlet The set command can turn an outlet on or off.
Page 196: Turning An Outlet On
Chapter 7: Using the CLP Interface Turning an Outlet On Using the keyword on turns the outlet on. clp:/-> set /system1/outlet<outlet number> powerState=on where <outlet number> is the number of the outlet. Turning an Outlet Off Using the keyword off turns the outlet off. clp:/->...
Page 197: Showing Environmental Sensor Information
<ID number> is the ID number assigned to the environmental sensor while having the environmental sensor managed. The maximum number is 16 since the Dominion PX device can manage up to 16 environmental sensors. To display information for all environmental sensors, type the wildcard asterisk (*) instead of a number.
Page 198: Example 1 - No Attributes
Chapter 7: Using the CLP Interface Example 1 - No Attributes This diagram shows the output of the show command without any attributes entered for a humidity sensor, whose ID number is 1.
Page 199: Example 2 - Name Attribute
Chapter 7: Using the CLP Interface The diagram shows the output of the show command without any attributes entered for a contact closure sensor, whose ID number is 3. Example 2 - Name Attribute The diagram shows the output of the show command with the name attribute for the environmental sensor 1.
Page 200: Configuring The Thresholds For Environmental Sensors
<ID number> is the ID number assigned to the environmental sensor while having the environmental sensor managed. The maximum number is 16 since the Dominion PX device can manage up to 16 environmental sensors. <LC_value> is the numeric value assigned to the lower critical threshold.
Page 201: Querying The Pdu's Serial Number
Dominion PX device. clp:/-> Show -d properties=serialNumber /system1 Resetting the Dominion PX Device The reset command restarts the Dominion PX management application only. The power state of individual outlets remains unchanged. This command is not a factory reset. clp:/->...
Page 202: Example 2 - Getting In-Depth Help Information
Chapter 7: Using the CLP Interface Example 2 - Getting In-Depth Help Information To show detailed help information, add the option -output verbose between the help command and the queried command. The diagram shows the output of the help information for the show command in details.
Page 203: Chapter 8 Inline Monitors
Inline Monitors Chapter 8 The model name of a Dominion PX inline monitor follows this format: PX-3nnn, where n is a numeric digit. Unlike most of the Dominion PX devices, an inline monitor may have multiple inlets. Each inlet is connected to an outlet only, so an inlet's rating is the same as an outlet's rating.
Page 204: Models With Power Sockets
Chapter 8: Inline Monitors Models with Power Sockets This diagram shows an inline monitor whose inlets and outlets are in the form of power sockets or receptacles. The total number of inlets and outlets varies depending on the model you purchased. Number Description Inlets (the side labeled LINE)
Page 205: Cord Installation
STOP and contact Raritan Technical Support if you are unsure of any answers, or have additional questions.
Page 206: Installation Guidelines
Chapter 8: Inline Monitors Installation Guidelines Keep in mind that electricity is transmitted only between the inlet and outlet labeled with the same number. That is, electricity flows from the inlet labeled "CH1" to the outlet labeled "CH1," from the inlet labeled "CH2" to the outlet labeled "CH2,"...
Page 207 Y-wired three-phase models, including PX-3370 and PX-3270 Note: For models not described or listed in this section, the cord installation procedure is similar but you have to contact Raritan Technical Support for appropriate torque settings and diameter values. To install power cords on an inline monitor: 1.
Page 208 Remove the dome nut from the cable gland. b. Insert the Raritan-provided sealing ring into the one already seated inside the cable gland so that the inner diameter becomes smaller.
Page 209 Chapter 8: Inline Monitors Thread the power wires into the opening of the cable gland. A Y-wired three-phase model requires a 5-wire power cord. 5. A single-phase model requires a 3-wire power cord. 6. Fasten power wires to appropriate wire terminals. a.
Page 210 Chapter 8: Inline Monitors  Single-phase model:  Y-wired three-phase model: b. Remove the clear plastic cover from the terminal block adjacent to the ground terminal. c. Connect the cord's remaining wires to the terminal block.
Page 211 Chapter 8: Inline Monitors  Single-phase model: Connect the L1 wire to the terminal labeled L1, and the L2 wire to the one labeled L2. Ensure both are tightened securely with screws to a torque of 1.96 N·m.  Y-wired three-phase model: Connect the L1 wire to the terminal labeled L1, the L2 wire to the one labeled L2, the L3 wire to the one labeled L3, and the N wire to the one labeled N.
Page 212: Inline Monitor's Led Display
125% greater than the inlet's rating. For example, the branch circuit rating for PX-3370 can be up to 40A. Inline Monitor's LED Display The LED display of an inline monitor is the same as a regular Dominion PX model. See LED Display (on page 33).
Page 213: Manual Mode
Inline Monitor's Web Interface An inline monitor's web interface is similar to a regular Dominion PX model's web interface. Using the Web Interface (on page 39) for login instructions and...
Page 214: Menus
An inline monitor is NOT implemented with the overcurrent protection mechanism and outlet-switching function, so its menu items are slightly different from those of a regular Dominion PX PDU. The following list shows each menu with their own set of menu items.
Page 215: Home Page
Network Statistics Ping Host Trace Route to Host Device Diagnostics Help About Dominion PX Home Page The power status of each outlet on an inline monitor is displayed in the Monitors section of the Home page, including:  Voltage (Volts) ...
Page 216: Snmp And Clp Interfaces
Chapter 8: Inline Monitors SNMP and CLP Interfaces Same as regular Dominion PX models, an inline monitor allows remote access through either SNMP or CLP interface. See Using SNMP page 161) and Using the CLP Interface (on page 173).
Page 217: Appendix A Specifications
Dominion PX Feature RJ-12 Port Pinouts..........202 Maximum Ambient Operating Temperature The maximum ambient operating temperature (TMA) for the Dominion PX varies between 40 to 60 degrees Celsius, depending on the model and certification standard (CE or UL). If necessary, contact Raritan Technical Support for this information for your model.
Page 218 Appendix A: Specifications RJ-12 Pin/signal definition ― +12V Power (500mA, fuse protected) ― Signal Ground RS485 bi-direction Data Line + (Data +) RS485 bi-direction Data Line - (Data -) ― Signal Ground 1-wire Used for Feature Port...
Page 219: Appendix B Equipment Setup Worksheet
Appendix B Equipment Setup Worksheet Dominion PX Series Model ____________ Dominion PX Series Serial Number ____________ OUTLET 1 OUTLET 2 OUTLET 3 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 4 OUTLET 5 OUTLET 6 MODEL MODEL MODEL...
Page 220 Appendix B: Equipment Setup Worksheet OUTLET 7 OUTLET 8 OUTLET 9 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 10 OUTLET 11 OUTLET 12 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 13 OUTLET 14 OUTLET 15 MODEL MODEL MODEL...
Page 221 Appendix B: Equipment Setup Worksheet OUTLET 16 OUTLET 17 OUTLET 18 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 19 OUTLET 20 OUTLET 21 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER...
Page 222 Appendix B: Equipment Setup Worksheet OUTLET 22 OUTLET 23 OUTLET 24 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER Types of adapters _________________________________________________________ Types of cables _________________________________________________________ Name of software program _________________________________________________________...
Page 223: Appendix C Enabling Or Disabling The Power Cim
CIM can be disabled. Note that after disabling the serial port support for the power CIM, the KVM switch cannot receive any data from the Dominion PX or control it even if a power CIM is in place. To enable or disable the connected power CIM: 1.
Page 224: Appendix D Integration
Appendix D Integration Product Direct Access Access Through Connectivity Max # of PX Interfaces CC-SG Interfaces Units Supported Association Control Association Control Dominion SX >= 3.1: SX RSC into CC GUI CC GUI CSCSPCS-1 Max = number GUI; PX serial of serial ports port CSCSPCS-10...
Page 225 Appendix D: Integration Product Direct Access Access Through Connectivity Max # of PX Interfaces CC-SG Interfaces Units Supported Association Control Association Control Paragon II Paragon IP-Reach + IP-Reach + P2CIM-PWR Max = number Manager, of channel ports (UST) Paragon II Paragon RRC, PIISC +...
Page 226: Power Iq Configuration
5. Enter data in Custom Field 1 and Custom Field 2. Optional. The labels may have been changed in Power IQ to identify these fields. 6. If the PDU is a Dominion PX, enter a valid Username and Password for the PDU in the Dominion PX Credentials section. Re-enter the password in the Password Confirm field.
Page 227 Appendix D: Integration  For SNMP version 1/2c PDUs, enter an SNMP Community String that has at least READ permissions to this PDU. This enables polling the PDU for data. Enter an SNMP community string that has both READ and WRITE permissions to the PDU to enable power control, outlet renaming, and buffered data retrieval.
Page 228: Dominion Kx Ii Power Strip Configuration
KX II rack PDU configuration is done from the KX II Port Configuration page. Connecting a Rack PDU Raritan PX series rack PDUs (power strips) are connected to the Dominion device using the D2CIM-PWR CIM. To connect the rack PDU: 1.
Page 229 Note: PX rack PDUs (power strips) can be named in the PX as well as in KX II and LX. Once a Raritan remote rack PDU is connected to the KX II or LX, it will appear on the Port Configuration page. Click on the power port name on that page to access it.
Page 230 Appendix D: Integration 3. Click OK.
Page 231 Port Access page. To use this feature, you will need:  Raritan remote rack PDU(s)  Power CIMs (D2CIM-PWR) To make power associations (associate rack PDU outlets to KVM...
Page 232: Dominion Kx I Power Strip Configuration
Dominion PX devices, if needed. Setup Preparation You must have a power strip and the P2CIM-PWR Computer Interface Module (CIM). By default the P2CIM-PWR is not included with Raritan power strips. To receive the P2CIM-PWR CIM with the power strip, you must order the power strip with a part number that ends in PK (for example, PCR8-15-PK).
Page 233: Connecting The Power Strip
Appendix D: Integration Connecting the Power Strip 1. Connect the male RJ-45 of the P2CIM-PWR to the female RJ-45 connector on the serial port power strip. 2. Connect the female RJ-45 connector of the P2CIM-PWR to any of the available female system port connectors on the Dominion KX using a straight through Cat 5 cable.
Page 234: Kx Manager Application
KX Manager Application Use Raritan's KX Manager application to configure associations. To configure associations: 1. Select the target. 2. Edit the Properties and choose the outlets to associate. The outlets are automatically renamed to the associated target server's name.
Page 235 Appendix D: Integration 2. Select up to eight Dominion PX devices from drop-down list. 3. Select up to a total of four outlets from the Dominion PX devices.
Page 236: Controlling A Target Server's Power
Appendix D: Integration 4. Notice the target icon change to indicate power. 5. Notice the outlet icon change to indicate association. 6. Notice the outlet name automatically changes to the target's name. Controlling a Target Server's Power 1. Select the target server associated with outlets.
Page 237: Paragon Ii
Paragon II integration requires P2CIM-PWR and straight CAT5 cable. You can associate up to four outlets to a target server, and all four outlets can be from separate Dominion PX devices, if necessary. For more information on Paragon II, see either of the following: ...
Page 238: Adding A Dominion Px In Paragon Ii
Appendix D: Integration Adding a Dominion PX in Paragon II Add a Dominion PX device exactly as you would add any second-tier device. Your Paragon II auto-detects the Dominion PX device and changes the device type to PCR8, PCS12, PCS20, DPX16, or DPX24. On the OSD screen, press F5 to enter the Channel Configuration page.
Page 239: Controlling A Target Server's Power
Use the Selection Menu, except for Selection Menu by Name, to navigate to individual Dominion PX ports and control power. To control an outlet's power: 1. Select the Dominion PX device from the Selection Menu. 2. The Outlet Selection page opens, and the following message should appear.
Page 240: Paragon Manager Application
Dominion SX By connecting to a Dominion SX device, you can associate one or more outlets on a Dominion PX device to specific Dominion SX ports. Configuring a Dominion PX on Dominion SX 1. Choose Setup > Power Strip Configuration.
Page 241 Appendix D: Integration 2. Click Add. The Power Strip Configuration screen appears. 3. Type a name and description in the Name and Description fields. 4. Select the number of outlets from the Number of Outlets drop-down menu. 5. Type the port number in the Port field. 6.
Page 242: Power Control
Appendix D: Integration Power Control 1. Choose Power Control > Power Strip Power Control. The Outlet Control screen appears. 2. Check the box of outlet number you wish to control, and click On/Off buttons to power on/off the selected outlet(s). 3.
Page 243: Checking Power Strip Status
PX, including power state of each outlet on the device. Dominion KSX Dominion KSX does not support connectivity with Dominion PX. However, Dominion PX can be managed as a serial target on one of KSX's serial ports, interacting through CLP interface. Dominion KSX 2 supports Dominion PX integration.
Page 244: Commandcenter Secure Gateway
Paragon II See the CC-SG Administrators Guide for more details. Note: If you have to reboot or power OFF the Dominion PX device while it is integrated with a Raritan product under CC-SG management you should PAUSE MANAGEMENT of the integrated product until the Dominion PX device fully powers ON again.
Page 245: Appendix E Using The Ipmi Tool Set
Appendix E Using the IPMI Tool Set The IPMI tool set is command-line that allows users to display channel information, print sensor data, and set LAN configuration parameters. The following explains the available IPMI commands. Note: The open source IPMI tool can be downloaded from sourceforge, and compiled on Linux system .Then users can interact with the Dominion PX via IPMI protocol through this tool.
Page 246: Info [Channel Number]
Appendix E: Using the IPMI Tool Set info [channel number] Displays information about the selected channel. If no channel is given it displays information about the currently used channel: Example $ ipmitool -I lan -H 192.168.51.58 -U admin -a channel info getaccess <channel number>...
Page 247: Predefined Event Number
Appendix E: Using the IPMI Tool Set <predefined event number> Sends a pre-defined event to the System Event Log. The Currently supported values for are:  Temperature: Upper Critical: Going High  Voltage Threshold: Lower Critical: Going Low  Memory: Correctable ECC Error Detected Note: These pre-defined events usually do not produce "accurate"...
Page 248: Set
Appendix E: Using the IPMI Tool Set set <channel> <parameter> Sets the given parameter on the given channel. Valid parameters are:  ipaddr <x.x.x.x> Sets the IP address for this channel.  netmask <x.x.x.x> Sets the netmask for this channel. ...

Page 249: Sensor Commands
Appendix E: Using the IPMI Tool Set  Cipher Suite Unused  CALLBACK  USER  O OPERATOR  ADMIN  O OEM Sensor Commands The Sensor commands allow you to display detailed sensor information. list Lists sensors and thresholds in a wide table format. Example $ ipmitool -I lan -H allen-dpxpcr20-20 -U admin -a sensor list...
Page 250: Oem Commands
Appendix E: Using the IPMI Tool Set OEM Commands You can use the OEM commands to manage and control the operation of the Dominion PX device. OEM Net-Fn is as defined below: #define IPMI_NETFN_OEM_PP 0x3C The table lists each OEM command and gives its ID. The sections that follow explain each command in greater detail.
Page 251: A Note About Group Commands
For example, sending the following is incorrect: #ipmitool -H 192.168.80.43 -U admin -P pass raw 0x3c 0x14 grp2 0 The Dominion PX ignores this command. A Note about Outlet Numbers An outlet command uses decimal numerals to represent outlets. Each decimal numeral must be converted into a binary one consisting of 8 numeric digits for indicating 8 outlets.
Page 252: Set Power On Delay Command
Appendix E: Using the IPMI Tool Set Decimal Binary Decimal Binary 0000 0010 0000 1110 0000 0011 0000 1111 0000 0100 0001 0000 0000 0101 0001 0001 0000 0110 0001 0010 0000 0111 0001 0011 0000 1000 0001 0100 0000 1001 0001 0101 0000 1010 0001 0110...
Page 253: Get Power On Delay Command
Appendix E: Using the IPMI Tool Set Get Power On Delay Command Request Data Response Data Completion Code delay in 1/10 seconds Set Receptacle State Command This command is used to switch on/off and recycle individual receptacles. Request Data # of receptacle [7 - 5] reserved [4 - 0] # of receptacle, 0 based, highest valid # depends on device model new state...
Page 254: Get Receptacle State And Data Command
Appendix E: Using the IPMI Tool Set Get Receptacle State and Data Command Request Data # of receptacle [7 - 5] reserved [4 - 0] # of receptacle, 0 based, highest valid # depends on device model Response Data Completion Code current receptacle state and visual state [7] reserved [6] 1b = blinking, 0b = steady...
Page 255: Set Group Membership Command
Appendix E: Using the IPMI Tool Set Set Group Membership Command Request Data # of group [7 - 5] reserved [4 - 0] group #, valid numbers: 0 - 23, 255 [7 - 1] reserved [0] 1b = enable group, 0b = disable group [7] 1b = receptacle 7 belongs to group [0] 1b = receptacle 0 belongs to group [7] 1b = receptacle 15 belongs to group...
Page 256: Set Group Power On Delay Command
Appendix E: Using the IPMI Tool Set [0] 1b = receptacle 16 belongs to group Set Group Power On Delay Command Request Data # of group [7 - 5] reserved [4 - 0] group #, valid numbers: 0 - 23, 255 delay in 1/10 seconds This delay overwrites the global delay for all receptacles in that group.
Page 257: Get Receptacle Acl
Appendix E: Using the IPMI Tool Set Response Data Completion Code Get Receptacle ACL Request Data # of receptacle Response Data Completion Code number of ACL entries to follow ACL entry [7] 0b = deny, 1b = allow [6] 0b = user id, 1b = privilege level [5 - 0] user id or privilege level depending on [6] Test Actors Used for hardware testing during production...
Page 258: Get Power Cycle Delay Command
Completion Code Delay (seconds), 1-255, 0 if not set (receptacle only) Note: Values greater than 255 cannot be sent to the Dominion PX via IPMI. To set the Power Cycle Delay to longer than 255 seconds, use the web interface.
Page 259 Appendix E: Using the IPMI Tool Set IPMI Privilege Level: Callback User Operator Administrator Access Yes/No Yes/No Yes/No Yes/No Yes/No SSL Certificate Management Security Yes/No Yes/No Yes/No Yes/No Yes/No Settings Unit Reset Yes/No Yes/No Yes/No Yes/No Yes/No User/Group Management User Group Yes/No Yes/No Yes/No...
Page 260: Appendix F Additional Pdu Information
This table describes the default hysteresis values for each type of measurement. Values must recede past the threshold by the hysteresis value before the Dominion PX de-asserts the condition. You can disable the hysteresis feature for outlet current while the feature for other measurements continue to apply.
Page 261 Appendix F: Additional PDU Information Event Type Examples Outlet Control Outlet(#) switched on by user Outlet(#) switched off by user Outlet(#) cycled by user Outlet/Unit/Environmental Assertion: Environmental Temperature (#) above upper Sensors non-critical threshold Deassertion: Environmental Temperature (#) above upper critical threshold User/Group Administration User added successfully...
Page 262: Mac Address
Appendix F: Additional PDU Information MAC Address A label is affixed to a Dominion PX device, near the LED display, showing both the serial number and MAC address of the PDU. If necessary, you can find the PDU's IP address through the MAC address by using commonly-used network tools.
Page 263: Data For Btu Calculation
Appendix F: Additional PDU Information Data for BTU Calculation If you need to calculate the heat (BTU/hr) generated by the Dominion PX device, use the following power data in the BTU calculation formula. Model name Maximum power (Watt) PX-nnnn, DPXS, DPXR, DPCS and DPCR series The letter "n"...
Page 264: Appendix G Ldap Configuration Illustration
Determine user accounts and groups intended for the Dominion PX b. Create user groups for the Dominion PX on the AD server c. Configure LDAP authentication on the Dominion PX device d. Configure user groups on the Dominion PX device In This Chapter Step A.
Page 265: Step B. Configure User Groups On The Ad Server
Appendix G: LDAP Configuration Illustration Step B. Configure User Groups on the AD Server You must create the groups for the Dominion PX on the AD server, and then make appropriate users members of these groups. In this illustration, we assume: ...
Page 266: Step C. Configure Ldap Authentication On The Dominion Px Device
1. Choose Device Settings > Authentication. The Authentication Settings page opens. 2. Select the LDAP radio button to enable the LDAP section of the page. 3. Provide the Dominion PX with the information about the AD server.  Type of external LDAP server - Select "Microsoft Active Directory"...
Page 267 Appendix G: LDAP Configuration Illustration  Base DN of user LDAP server - Type dc=techadssl,dc=com as the starting point where your search begins on the AD server.  Name of login-name attribute - Type sAMAccountName because the LDAP server is Microsoft Active Directory. ...
Page 268 Appendix G: LDAP Configuration Illustration  Active Directory Domain - Type techadssl.com. Note: For more information on LDAP configuration, see Setting Up LDAP Authentication (on page 114). 4. Click Apply. The LDAP authentication is activated.
Page 269: Step D. Configure User Groups On The Dominion Px Device
Appendix G: LDAP Configuration Illustration Note: If the Dominion PX clock and the LDAP server clock are out of sync, the certificates are considered expired and users are unable to authenticate using LDAP. To ensure proper synchronization, administrators should configure the Dominion PX and the LDAP server to use the same NTP server.
Page 270 Appendix G: LDAP Configuration Illustration 2. Select PX_User from the Group drop-down list. The permissions that apply to this group appear. Since this is the first time you are setting the system permissions for this group, all permissions are set to No. 3.
Page 271 Appendix G: LDAP Configuration Illustration 5. Repeat Steps 2 to 4 to set the permissions for the PX_Admin group. In this example, all system permissions are set to Yes (or Read-Write). To set the outlet permissions for each group: 1. Choose User Management > User/Group Outlet Permissions. The User/Group Outlet Permissions page opens.
Page 272 Appendix G: LDAP Configuration Illustration 3. Set the permissions as necessary. Click on the drop-down list to select a permission level for each outlet. In this example, all outlet permissions are set to No. 4. Click Apply. The permissions are applied to the PX_User group.
Page 273 Appendix G: LDAP Configuration Illustration 5. Repeat Steps 2 to 4 to set the permissions for the PX_Admin group. In this example, all outlet permissions are set to Yes.
Page 274: Appendix H Resetting The Pdu Settings
When resetting to factory defaults, do not use a DB9-to-USB adapter to connect the Dominion PX serial cable to your PC. This may result in misinterpreted characters at the special prompt. Connect the Dominion PX serial cable to a PC with a DB9 serial port instead.
Page 275: Resetting The Administrator Password
Dominion PX to a Computer (on page 17). 2. Launch a terminal emulation program such as HyperTerminal, Kermit, or PuTTY, and open a window on the Dominion PX. Make sure the serial port settings use this configuration:  Bits per second = 9600 ...
Page 276: Index
Configuring Environmental Sensors • xiv, 119, Access Security Control • 97 122, 127 Adding a Dominion PX in Paragon II • 223 Configuring Rack PDU (Power Strip) Targets • Adding PDUs to Power IQ Management • 211 Additional PDU Information • xiv, 245 Configuring the Dominion PX •...
Page 277 Index Connecting the Dominion PX to a Computer • Displaying Model Configuration Information • 17, 18, 259, 260 53, 54 Connecting the Dominion PX to a Power Dominion KSX • 228 Source • xiv, 16 Dominion KX I Power Strip Configuration • 217 Connecting the Dominion PX to Your Network •...
Page 278 Introduction • 1 Naming and Configuring Outlets • 85, 86, 88, IPMI Privilege Levels • 230, 243 Naming the Dominion PX Device • 55, 56 Naming the Rack PDU in the KX II or LX (Port KX Manager Application • 219 Page for Power Strips) •...
Page 279 Resetting the Administrator Password • 260 Setting Up LDAP Authentication • xiv, 57, 114, Resetting the Button-Type Circuit Breaker • 37 Resetting the Dominion PX Device • 67, 186 Setting Up Power Thresholds and Hysteresis • Resetting the Handle-Type Circuit Breaker • 37 91, 169 Resetting the PDU Settings •...
Page 280 Step D. Configure User Groups on the What is Threshold Hysteresis? • 91, 92, 142 Dominion PX Device • 254 What's New in the Dominion PX User Guide • Successful Messages • 47 Suggestion for SNMP Trap Configuration • 134, With HyperTerminal •...
Page 281 For CommandCenter Secure Gateway: Press 6, then Press 2 Phone: +31-10-2844040 Fax: 732-764-8887 Email: tech.europe@raritan.com Email for CommandCenter NOC: tech-ccnoc@raritan.com Email for all other products: tech@raritan.com United Kingdom Monday - Friday 8:30 a.m. to 5 p.m. GMT China Phone +44(0)20-7090-1390...
