- Page 1 OPERATOR M A N U A L Advance ™ Aquamatic Selectric Model 56263500 This parts list is for machines after serial number 470048 revised 11/00 FORM NUMBER 56041244...
-
Page 2: Table Of Contents
INDEX PAGE AFTER USE ............8 GROUNDING INSTRUCTIONS ......4 IMPORTANT SAFETY INSTRUCTIONS ....3 INTRODUCTION ............ 2 KNOW YOUR MACHINE ........6 MAINTENANCE ............. 9 OPERATION ............7 PREPARING THE MACHINE FOR USE....5... -
Page 3: Introduction
INTRODUCTION This manual will help you get the most from your Advance AquaMatic Selectric™. Read it thoroughly before operating the machine. This product is intended for commercial use only. PARTS AND SERVICE Repairs, when required, should be performed by your Authorized Advance Service Center, who employs factory trained service personnel, and maintains an inventory of Advance original replacement parts and accessories. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before use. WARNING! To reduce the risk of fire, electric shock, or injury: • Do not leave the appliance when it is plugged in. Unplug the unit from the outlet when not in use and before servicing. -
Page 5: Grounding Instructions
GROUNDING INSTRUCTIONS This appliance must be grounded. If it should electically malfunction, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 6: Preparing The Machine For Use
PREPARING THE MACHINE FOR USE FILL THE SOLUTION TANK 1. Lift the front Solution Fill Cover off the machine. 2. Read the dilution instructions on the chemical container. Then figure the proper amount of chemical to mix with 25 gallons (94.5 liters) of water. For best results, use the Advance CarpeTeam™... -
Page 7: Know Your Machine
KNOW YOUR MACHINE Reverse Button Wheel Drive Circuit Breaker (2 Amp) Decrease Speed Button Vacuum Motor Circuit Breaker (13 Amp) Speed Indicator Lights Drive Pedal Solution Button Brush Pedal Increase Speed Button Solution Hose Coupler Recovery Tank Cover Solution Filter Solution Fill Cover Recovery Tank Drain Hose Accessory Connection... -
Page 8: Operation
OPERATION 1. Follow the instructions in the Preparing the Machine for Use section of this manual. 2. Connect the Power Cord (12) to the machine, then plug the Power Cord into a properly grounded outlet. 3. Make sure the Solution Fill Cover (7) and the Recovery Tank Cover (6) are firmly in place and the Solution Shut-Off Lever (10) is in the ON position. -
Page 9: After Use
AFTER USE 1. Turn the Main Switch (22) OFF. 2. Step DOWN and lock the Brush Pedal (17) to raise the brush. 3. Put the Drive Pedal (16) UP to disengage the drive belt. 4. Unplug the Power Cord (12) from the power outlet. 5. -
Page 10: Maintenance
MAINTENANCE WARNING! Unplug the power cord before attempting any service or maintenance work to the machine. MAINTENANCE NOTE With the tanks empty and the power cord unplugged, tip the machine forward onto its nose for access to the Power Brush, Pick-Up Tool, and Spray Nozzle. POWER BRUSH Once a week, check the brush and remove any built-up string, hair or carpet fibers. - Page 11 CLEANING THE VACUUM EXHAUST FILTERS Clean the vacuum exhaust filters once a month. Remove the foam filters from Foam Filter the bottom of the machine and wash them in warm water. Let the filters dry Foam Filter completely before putting them back into the machine.
- Page 12 ADJUSTING THE BRUSH HEIGHT There is an Adjustment Plate on each side of the machine, just in front of the brush. To adjust the Brush Height, loosen the two Plate Screws on the side of the Adjustment Plates. Raise the plates to lower the brush; Lower the plates to raise the brush. Use a wrench to turn the Adjustment Screws to the desired position, then tighten the Plate Screws.
- Page 13 WHEEL DRIVE CIRCUIT BREAKER (2 AMP) When the Wheel Drive Circuit Breaker trips, check to see if there is debris wrapped around the wheel axle. Remove the debris from the axle. Have the wheel drive motor checked for worn out brushes; repair or replace the motor if necessary. Push the button to reset the circuit breaker.
- Page 14 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN, 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 ©2000 Nilfisk-Advance, Inc., Plymouth, MN 55447-3408 Printed in the U.S.A.
