Summit SCR1536B Instruction Manual

Beverage merchandiser
Hide thumbs Also See for SCR1536B:
Table of Contents

Advertisement

Quick Links

BEVERAGE MERCHANDISER
Model No.: SCR1536B / SCR1005W / SCR1155W / SCR1400W
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. (on lower left corner of
inside cabinet) here:
____________________________________________
INSTRUCTION MANUAL
c
F
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCR1536B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Summit SCR1536B

Summary of Contents for Summit SCR1536B

  • Page 1 BEVERAGE MERCHANDISER INSTRUCTION MANUAL Model No.: SCR1536B / SCR1005W / SCR1155W / SCR1400W BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Serial No. (on lower left corner of Felix Storch, Inc. 770 Garrison Avenue inside cabinet) here:...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using Your Appliance Installation of Your Appliance Electrical Connection Extension Cord Reversing the Door Swing of Your Appliance Installing the Stainless Steel Handle Operating Your Appliance 9-10 Control Panel 9-10 ON/OFF Power / Light / Up / Down...

  • Page 3: Appliance Safety

    APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others.

  • Page 4: Risk Of Child Entrapment

     Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL ...

  • Page 5: Location Of Parts

    LOCATION OF PARTS MODEL SCR1536B Digital Control Panel Door Shelves (3) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet MODEL SCR1005W Condenser Digital Control Panel Door Shelves (4) Handle Security Lock Adjustable Legs Cabinet...
  • Page 6 MODEL SCR1155W Digital Control Panel Door Shelves (4) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet MODEL SCR1400W Digital Control Panel Door Shelves (6) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet...

  • Page 7: Installation Instructions

     Install the handle on the door. (See page 9.) INSTALLATION OF YOUR APPLIANCE  Models SCR1536B, SCR1155W and SCR1400W are designed for either built-in or free-standing installation, while model SCR1005W is suitable for free-standing installation only.  WARNING: Do not store or install the appliance outdoors.

  • Page 8: Extension Cord

    115 volts and at least 10 amperes. REVERSING THE DOOR SWING OF YOUR APPLIANCE (ONLY for SCR1536B) This unit has the capability of the door opening from either the left or right side. The unit is delivered to you with the door opening from the left side.

  • Page 9: Installing The Stainless Steel Handle

    5. Screw the alternative left top hinge 8, included in the fittings, on the left hand side of cabinet. (Fig. 3) 6. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left designated position and tighten it after the door is leveled. (Fig. 1) 7.

  • Page 10: ºf/ºc Selector

    ºF/ºC Selector Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Setting the Temperature Control  You can set the temperature by touching the UP and DOWN symbols. When you push the two buttons for the first time, the LED readout will show the original temperature set previously.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE CLEANING YOUR BEVERAGE MERCHANDISER  Turn off the power, unplug the appliance, and remove all items, including shelves.  Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). ...

  • Page 12: Troubleshooting

    TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY  Appliance is not connected to a power ...
  • Page 13  The gasket is dirty.  Clean the door gasket.  The shelves are out of position.  Check the shelves and refit correctly.  The air temperature sensor has failed.  Call for service. Display “E1” or “E2”.  Has the appliance door been open for ...

  • Page 14: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.

This manual is also suitable for:

Scr1005wScr1155wScr1400w
