GLASS DOOR REFRIGERATOR
(BEVERAGE DISPLAY CASE)
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. (on back of unit) here:
________________________________
Model SCR1275
Instruction Manual
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit SCR1275
Summary of Contents for Summit SCR1275
- Page 1 GLASS DOOR REFRIGERATOR (BEVERAGE DISPLAY CASE) Model SCR1275 Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. (on back of unit) here: 770 Garrison Avenue Bronx, NY 10474 ________________________________...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety ................. Important Safeguards ..............Location of Parts ................ Technical Information ..............Installation Instructions ............. Moving and Installing Your Appliance ........Electrical Connection .............. Extension Cord ............... Operating Your Appliance ............Turning On the Unit ..............Storing Items in the Unit ............ -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 Do not connect or disconnect the electric plug when your hands are wet. Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in electrical shock or death. Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual.
-
Page 5: Location Of Parts
(on back of unit) Shelves (7 total) Evaporator (on rear interior wall) Cabinet Ventilation grid Door assembly Caster TECHNICAL INFORMATION Model: SCR1275 Installation: Free-standing Capacity: 9.5 cubic feet Electrical Input: 115V AC / 60Hz Rated Current: 1.4A Temperature Range: 35°F to 50°F... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS This appliance is meant for free-standing installation; it should not be built-in. Do not put heavy items on top of the unit. Do not store or install the appliance outdoors. This appliance is designed for storing and cooling beverages and drinks. Do not use it to store perishable food, medicine or other medical products. -
Page 7: Extension Cord
Extension Cord Because of potential safety hazards under certain conditions, it is strongly recommended that you do not use an extension cord with this appliance. However, if you must use an extension cord it is absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes. -
Page 8: Defrosting The Unit
Defrosting the Unit Defrosting is automatic in the SCR1275. During the defrost cycle, melting ice drips off the evaporator coils at the rear of the cabinet and flows through the hole at the back of the floor of the cabinet into a holding tray above the compressor. -
Page 9: Care And Maintenance
3. Replace the bulb or bulbs and reinsert the logo panel. 4. Replace the left side cover. NOTE: Replacement bulbs can be purchased directly from SUMMIT by calling us at 1-800-932-4267 or by going to our website at www.summitappliance.com/support. Have the model number, SCR1275, handy. -
Page 10: Moving Your Appliance
Moving Your Appliance 1. Remove all items from the shelves. 2. Securely tape down all loose items (shelves) inside your appliance. 3. Tape the door shut. 4. Be sure the appliance stays secure in the upright position during transportation. Also, protect the outside of the appliance with a blanket or similar covering. -
Page 11: Troubleshooting
If the unit develops problems that cannot be solved by referring to the chart above, do not try to dismantle the unit yourself. This could void your warranty. Instead, refer to an authorized service center or call SUMMIT Customer Service at 1-800-932-4267. -
Page 12: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
