CAUTION: At least two installers are
required due to the weight and size of the
hood.
1. Install blower into Power Pack
AK8200AS - Blower is pre-installed
AK8300ASX - Refer to page 11 for instructions
Remove support screw from top of Power Pack
before installing into cabinet. FIG 2b
2. Install 8" round adapter to top of Power Pack. See page 11, step 3
for instuctions.
3. Install optional AK08xxAS Stainless Steel Liner. Review manual
included with liner for more details.
4. If no liner is used cut out an opening in the bottom of the cabinet by
following the dimensions in FIG 1.
5. Lift Power Pack into opening and secure to bottom of cabinet using
(4) M4 stainless steel screws, (1) in each corner; see FIG 2.
note: Wood blocking may need to be added to cabinet base if
additional support is needed.
6. Install duct work and seal with duct tape.
7. Install electrical.
8. Remove all packing materials before using Power Pack.
Switch power on and check for leaks around duct tape.
9. Install decorative mesh or *optional baffl e fi lters. Light panels must
be re-positioned if using baffl e fi lters. See FIG 3 for instructions on
converting from decorative mesh fi lters to baffl e fi lters.
note: FIG 3, Picture 1 light panel is fl ush mounted. FIG 3, Picture 4
light panel is angled inward with the baffl e fi lter.
*Baffl e fi llters are sold as an optional accessory, turn to the "List of
Parts and Accessories" page for part numbers.
1.
Spring Clip
(behind light panel)
2.
FIG 3
10
www.zephyronline.com
AK8200AS AK8300ASX
26 34
1/16" - 11/16
C/L
cabinet bottom cut-out size
FIG 1
Ductwork Ductwork
elec. elec.
minimum minimum
3/4" wood base 3/4" wood base
Front View Front View
metal or other non
(4) M4 ss wood screws
combustible material (1) in each corner
FIG 2
FIG 2b
3. 4.
"
C/L
remove support screw
