dji Phantom 3 Advanced User Manual page 19

The Battery Level Indicators will also show the current battery level during charging and
discharging. The indicators are defined below.
: LED is on.
: LED is off.
Battery Level
LED1 LED2
Battery life
Battery life refers to how many more times the battery can be discharged and recharged before it must
be replaced. When the battery is turned off, press and hold the Power Button for 5 seconds to check the
battery life. The Battery Level Indicators will light up and/or blink for two seconds, as shown below:
Battery Life
LED1 LED2
When battery life reaches 0%, it can no longer be used.
For more information about the battery, launch the DJI Pilot app and check the information that is
listed under the battery tab.
: LED is flashing.
LED3 LED4
LED3 LED4
Phantom 3 Advanced User Manual
Battery Level
87.5%~100%
75%~87.5%
62.5%~75%
50%~62.5%
37.5%~50%
25%~37.5%
12.5%~25%
0%~12.5%
=0%
Battery Life
90%~100%
80%~90%
70%~80%
60%~70%
50%~60%
40%~50%
30%~40%
20%~30%
below 20%
©
2015 DJI. All Rights Reserved.
19
