dji Phantom 3 Advanced User Manual page 18

Phantom 3 Advanced User Manual
10. Battery Cell Damage Protection: The DJI Pilot app displays a warning message when a damaged
battery cell is detected.
11. Battery Error History: Browse the battery error history in the DJI Pilot app.
12. Sleep mode: To save power, the battery enters sleep mode after 20 minutes of inactivity.
13. Communication: Information pertaining to the battery's voltage, capacity, current, etc. is transmitted to
the aircraft's main controller.
Refer to Phantom 3 Professional / Advanced Intelligent Flight Battery Safety Guidelines before
use. Users take full responsibility for all operations and usage.
Using the Battery
Turning ON/OFF
Press the Power Button once, then press again and hold for 2 seconds to turn on. The
Turning On:
Power LED will turn red and the Battery Level Indicators will display the current battery level.
Turning Off: Press the Power Button once, then press again and hold for 2 seconds to turn off. The
battery power LED will flash when powering off the Phantom to allow automatically stopping
of a recording during the event recording wasn't stopped.
Low Temperature Notice:
1. Battery capacity is significantly reduced when flying in low temperature (< 0°C) environments.
2. It is not recommended that the battery be used in extremely low temperature (< -10°C) environments.
Battery voltage should reach the appropriate level when operating environment with temperatures
between -10°C and 5°C.
3. End the flight as soon as the DJI Pilot app displays the "Low Battery Level Warning" in low temperature
environments.
4. Keep the battery indoors to warm it before flying in low temperature environments.
5. To ensure optimal performance of the battery, keep the battery temperature above 20°C.
6. The charger will stop charging the battery if the battery cell's temperature is not within the operating
range (0°C ~ 40°C ).
In cold environments, insert the battery into the battery compartment and allow the aircraft for
approximately 1-2 minutes to warm up before taking off.
Checking the Battery Level
The Battery Level Indicators display how much power remains. When the battery is turned off, press
the Power Button once. The Battery Level Indicators will light up to display the current battery level. See
below for details.
18
©
2015 DJI. All Rights Reserved.
LED1
LED2
LED3
LED4
Power Button (Bulit-in LED)
Battery Level Indicators
