Phantom 3 Advanced User Manual

Aircraft Status Indicator Description

Normal
Red, Green and Yellow Flash
Alternatively
Green and Yellow Flash Alternatively
Green Flashes Slowly
X2 Green Flashes Twice
Yellow Flashes Slowly
Warning
Fast Yellow Flashing
Slow Red Flashing
Fast Red Flashing
Red Flashing Alternatively
— Solid Red
Red and Yellow Flash Alternatively

Return-to-Home (RTH)

The Return-to-Home (RTH) function brings the aircraft back to the last recorded Home Point. There are
three types of RTH procedures: Smart RTH, Low Battery RTH, and Failsafe RTH. This section describes
these three scenarios in detail.
Home Point

Smart RTH

Use the RTH button on the remote controller (refer to "RTH button" on page 26 for more information) or
tap the RTH button in the DJI Pilot app and follow the on-screen instructions when GPS is available to ini-
tiate Smart RTH. The aircraft will then automatically return to the last recorded Home Point. You may use
the remote controller's control sticks to control the aircraft's position to avoid a collision during the Smart
RTH process. Press and hold the Smart RTH button once to start the process, and press the Smart RTH
button again to terminate the procedure and regain full control of the aircraft.
12
©
2015 DJI. All Rights Reserved.
GPS
If a strong GPS signal was acquired before takeoff, the Home Point
is the location from which the aircraft was launched. The GPS signal
strength is indicated by the GPS icon (
indicator will blink rapidly when the home point is recorded.
Turning On and Self Diagnostic Testing
Warming Up
Safe to Fly (P-mode with GPS and Vision
Positioning)
Safe to Fly (P-mode with Vision Positioning but
without GPS)
Safe to Fly (A-mode but No GPS and Vision
Positioning)
Remote Controller's Signal Lost
Low Battery Warning
Critical Battery Warning
IMU Error
Critical Error
Compass Calibration Required
Description
). The aircraft status
