Phantom 3 Advanced User Manual
When the Critical battery level warning is triggered and the aircraft begins to land automatically,
you may push the throttle upward to make the aircraft hover at its current altitude, giving you an
opportunity to navigate to a more appropriate landing location.
The colored zones and markers on the battery level indicator bar reflect the estimated
remaining flight time. They are automatically adjusted according to the aircraft's current location
and status.

Failsafe RTH

If the Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH will
be automatically activated if the remote controller signal is lost for more than three seconds. The Return-
to-Home process may be interrupted and the operator may regain control of the aircraft if the remote
controller signal connection is re-established.
Failsafe Illustration
1 Record Home Point
Blinking Green
4 Signal Lost Lasts (after 3 sec.)
>3S
×
Fast Blinking Yellow
The aircraft cannot avoid obstruction during the Failsafe RTH, therefore, it is important to set an
suitable Failsafe altitude before each flight. Launch the DJI Pilot app and enter "Camera" and
select "MODE > Advanced Settings > Failsafe mode" to set the Failsafe altitude.
The aircraft will stop its ascent and return to the Home Point immediately if the throttle stick is
moved during the Failsafe RTH procedure.

Vision Positioning System

The DJI Vision Positioning System uses ultrasound and image data to help the aircraft maintain its current
position. With the help of Vision Positioning, your Phantom 3 Advanced can hover in place more precisely
and fly indoors or in other environments where a GPS signal is not available. The main components of the
Vision Positioning System are located on the bottom of your Phantom 3 Advanced; they include [2] two
ultrasonic sensors and [1] one monocular camera.
14
©
2015 DJI. All Rights Reserved.
2 Confirming Home Point
Blinking Green
5 RTH (adjustable altitude)
Height over HP>20m
×
Elevate to 20m
20m
Height over HP<=20m
Fast Blinking Yellow
3 Remote Controller Signal Lost
×
Fast Blinking Yellow
6 Landing (after hovering for 5 secs)
×
Fast Blinking Yellow
[1]
[2]
