Configuring and Orienting the SMART
Board
Configuring the SMART Board involves specifying the COM port used to
link the computer to the SMART Board and indicating whether or not you
are using a projector with the SMART Board.
If you are using the SMART Board with a projector, you must orient the
computer image on the SMART Board. This orientation process ensures
that the Board accurately tracks your finger or any Pen Tray tool.
Orienting the SMART Board involves pressing on orientation points
displayed on the screen. If the projected image becomes misaligned, you
must perform the orientation procedure again.

Configuring the SMART Board

The first time you run the Board driver, you may need to ensure your
hardware connections are secure and then select a COM port for the
SMART Board attached to your computer. At the end of this procedure,
the Ready light on the Pen Tray will be lit, indicating an active SMART
Board.
To select a COM port for the SMART Board:
1. Choose Select Ports from the Board menu (from the Main
Menu or the Right Mouse menu).
or
Press the Select Ports button on the initial SMART Board screen.
The Check Board Connections dialog box will appear.
2. Ensure all hardware elements are securely connected.
3. Press the Next button.
The Pick a Port dialog box will appear.
4. If you know the COM port that is connected to your SMART
Board, select it from the list of ports provided.
SMART Board Installation Guide 25
